Intelligent Alarm System
User Manual
Ver 1202 2012-02-14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LY-GSM200KIT and is the answer not in the manual?

Questions and answers

Related Manuals for LY-TECH LY-GSM200KIT

Summary of Contents for LY-TECH LY-GSM200KIT

  • Page 1 Intelligent Alarm System User Manual Ver 1202 2012-02-14...
  • Page 2 Dear users, Thank you for having selected the intelligent alarm systems. Please read through this manual before installation so as to operate properly. The intelligent alarm system adopts the newest GSM network and Digital Signal Processing technology, and is widely used in security fields, such as protect your home, store, office, factory etc.

  • Page 3: Table Of Contents

    Contents 1．Description ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ．1 ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ．1 Main functions 1.2 Specification．...
  • Page 4 ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． 6.9. Inquiring AC power status of alarm host ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ．...

  • Page 5: Main Functions

    1. Description The alarm system adopts SMS data transmission and voice platform of GSM network to send control command and receive alarm message remotely. The system can be armed according to user’s requirements, when a signal is detected by sensors, the sensors will send alarm signal to alarm host immediately, then the alarm host will send alarm SMS to pre-set mobile phone numbers, and meanwhile dials its preset telephone/mobile phone numbers automatically.

  • Page 6: Specification． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ．2

    1fire alarm zone), and 2 wired zones (with anti-cut function); 1.2 Specification 1. Wireless frequency: 315MHz/433MHz; 2. GSM frequency: 900/1800/850/1900MHz 3. Alarm response time: ≤8s (GSM signal in normal) 4. Power requirements: AC 220V 50Hz/60Hz Working consumption：< 0.6W Backup battery: DC7.4V/850MA Backup battery working hours: ≥10 hours 5.Working condition humidity: ≤95% (non-condensation)

  • Page 7: 2．Structure． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ．3

    2．Structure As shown above: 1. Emergency button: used for emergency alarm 2. WIRLESS LED indicator: when receiving wireless signal from wireless sensor or remote controller, the LED will be on, otherwise is off. 3. RUN LED indicator: blinking every 2s when the GSM signal is normal, when the GSM signal is failure it blinks every 1s.
  • Page 8 5. Independent arm LED indicator: When there is one zone in the independent arm status, the LED is on. 6. ARM LED indicator: After system armed, it will be on; it will be off when disarm. 7. Power LED indicator: External AC power is connected, the LED is on;...
  • Page 9 2. Power switch: Switch to right is on, Switch to left is off. Shown as above: 1、SIM card socket 2、Learning button 3、Recording button 4、Setting button 5、Siren socket 6、Power supply socket...

  • Page 10: 3．Installation And Operation

    Shown as above: 1、Recording MIC 2、Listen in MIC 3. Installation and operation 3.1、Installing the SIM card The alarm host transmits alarm information by GSM SMS & voice platform, so you should prepare a SIM card before the installation. (If you use a new SIM card, you should check the new SIM card carefully whether it can send SMS and make calls normally or not.) Notes: Please turn off the power before insert SIM card and make sure the direction is correct.
  • Page 11 two-way communication functions (both wired alarm zone with anti-cut function.) The wiring method is as following: 1） After open the host case with screwdriver, you will see 6 wires inside the host. Shown as below: Of which: Red wire: anode of the intercom speaker; black wire: the cathode of the intercom speaker.
  • Page 12 3.3、Start the alarm host Make sure the power supply well connection, switch on the power; you will see that the ALARM indicator light, ARM indicator light, POWER indicator light keep brightening, the RUN indicator light is blinking. After 25s, the host gets into initialization & gets into the status of GSM network searching, after that it will make two “di di”...

  • Page 13: Running

    4. Record alarm voice message Press “REC” button, during the host working status, the host will make “di ” sound, then it begins to 10 seconds record. It will make “di, di ” sounds after finishing the recording. If you’ve connected the intercom speaker before, the host will broadcast your recorded message automatically.

  • Page 14: Programming Phone Numbers For Voice Calling Alarm

    Input: Serial number + mobile phone number + # Example: set 13688888888 as the first SMS alarm phone number. Input 113688888888#, then you will hear “di, di ”sounds for confirmation. Repeat the process to set the other two mobile phone numbers. Note: serial number can only be 1,2,3 and the number “1”...

  • Page 15: Modifying Alarm Host Id

    The factory default password is 1234. The password must be four digits. In setting status, then input “7 + new password + #” by wireless keypad, you will hear click sounds for confirmation. Example: set 4321 as new password, then you can input: 7+4321+#, you will hear two “di di ”...

  • Page 16: 6． Programming By Sms Command

    number. 6. Programming by SMS Command 6.1 Programming 3 mobile phone numbers for SMS alarm Input SMS: 4 digits password + DD + serial number + SMS alarm phone number, then send to alarm host. Example: The host’s password is 1234; set 13888888888 as the first SMS alarm phone number.

  • Page 17: Arm/Disarm

    Send SMS: 1234DD1 Note: The serial number shows alarm sequence (must be 1, 2, 3, 4, 5, 6) 6.4 Change host’s password Input SMS: 4 digits password + DD + 7 + 4 digits new password Example: The host’s original password is 1234. If you want to set 5678 as new password Send SMS: 1234DD75678 After setting successfully, the new password will be sent to the first SMS...
  • Page 18 Input SMS: “4 digits password”+ “DM00”+ “user defined name” After modifying successfully, the modified name will be sent to the preset 3 SMS alarm mobile phone numbers. 6.8 Inquire host’s arm/disarm status Send SMS: 4 digits password + W1 Return SMS: The host’s arm/disarm status 6.9 Inquire host’s external power status.

  • Page 19: Cancel Independent Arm

    “AA”+” zone series number” Notes: “zone series number” stands for 10 zones (from zone 01 to zone10), it’s allow to set multi-zones as independent zones. Example: If you want to set zone 1, zone 3, and zone 4 as independent zones, the host password is 1234, then you can send a SMS to alarm host, input SMS: 1234AA01, 03, 04 Notes: Between each zone, you must use a comma “...
  • Page 20 7. Remote control alarm host by phone You can use any telephone or mobile phone to dial the phone number of the host, the host will automatically get through after 15 seconds detecting and remind you of inputting password with voice. If the entered password is wrong for 3 times, the host will hand up the phone automatically;...

  • Page 21: Emergency Alarm

    When the LOCAL LED and REMOTE LED are twinkling, you can press the button “ ” to enter into arm status quickly. b. Press the button “ ” can disarm, the host make “di,di” sound, and LOCAL LED and REMOTE LED are off. 8.2 Emergency alarm function When an emergency alarm occurs, press the button “...
  • Page 22 into monitoring the sound at site. At this moment, the user presses the phone keypad: “1”-------------------armed “2”-------------------disarmed “3”-------------------start the Siren remotely “4”……………….Switch off siren If the phone line is busy or can’t get through, the system will auto-dial the next phone number circularly till the one of them is answered. If nobody answers the phone, the system will stop dialing after auto-dialing circularly for three times.
  • Page 23 operation. Wireless address code from Name D0（13） D1（12） D2（11） D3（10） A0 to A7（1~8） 9. Operation Cautions 1. Make sure the equipments have no water. 2. Install the system in a hidden place, but normal GSM network. 3. Turn off the power supply before insert/take out the SIM card. 4.
  • Page 24 Series number from right to Alarm host left A0~A7 1. PIR Zone 01 Motion Zone 02 sensor Zone 03 2.Magnetic Zone 04 contact The series numbers from Zone 05 A0 to A7 3.Beam Zone 06 should be matched the detectors alarm host one by one Zone 07 Zone 08...
