- Page 1 MUL-331 Sealer for POLYESTER Operation Manual Strap Type Polyester (PET) Strap Width 5/8" (16 mm) Strap Thickness Up to 0.040" (1 mm) Joint Type Seal Weight 4.5 lbs (2 kg) Handle Length 17.5"...
- Page 2 Fig. 1 – Starting Position 1. Place the Outer Jaws 16 and Inner Jaws 17 of the tool across the middle of the Seal 102 as shown on Fig. 2. Fig. 2...
- Page 3 2. Keeping the sealer in vertical position press the Handles 01 together till they cannot be squeezed no further as shown on Fig. 3. Fig. 3 3. Unclench the Handles 01 and remove the sealer from the seal 102 as shown on Fig. 4. Operation cycle is now complete.
