- Page 1 MUL-381 Sealer for POLYESTER Operation Manual Strap Type Polyester (PET) Strap Width 3/4" (19 mm) Strap Thickness Adjustable: 0.040, 0.050, 0.060" (1, 1.27, 1.52 mm) Joint Type Seal Weight 7.6 lbs (3.4 kg) Handle Length 27.5"...
- Page 2 Fig. 1 – Starting Position 1. Make sure that the sealer is set up for appropriate strap thickness. (See adjustment guide for more information). By moving up Upper Handle Lever 14 open Jaws 26 to place them on the middle of the Seal 102 as shown on a Fig.2 Fig.
- Page 3 2. Keeping the Jaws 26 placed on the middle of the seal move the Upper Handle Lever 14 to the starting position to close the Jaws 26 as shown on Fig.3 Fig. 3 4. Unclench the Handle Lever 14 to take the sealer off the seal. The operation cycle is now complete. Fig.
