- Page 1 Quick Start Guide TWR-S08DC-PT60 Tower System Daughter Card for the 5-Volt 8-bit MC9S08P Family TOWER SYSTEM...
- Page 2 Debugger Interface Accelerometer TWR-S08DC-PT60 Daughter Card Freescale Tower System The TWR-S08DC-PT60 daughter card, in conjunction with the TWR-S08UNIV MCU module, is part of the Freescale Tower System, a modular development platform that enables rapid prototyping and tool re-use through reconfigurable hardware.
- Page 3 TOWER SYSTEM TWR-S08DC-PT60 Daughter Card Features TWR-S08DC-PT60 demonstrates the capability of the 5-volt, 8-bit MC9S08P family of MCUs, targeted for industrial and home appliance applications. It can function as a stand-alone, low-cost platform for evaluation of MC9S08PT60 devices or used in conjunction with the TWR-S08UNIV Tower System module.
- Page 4 Quick Start Guide Step-by-Step Installation Instructions This quick start guide is designed to provide step-by-step guidelines to get you ready to develop your applications using the MC9S08PT60 within minutes. Download and Install Software and Tools 1. Download and install CodeWarrior • In the “Add Repository” dialog, insert your favorite site name as the Development Studio for Microcontrollers update location in the “Name”...
- Page 5 USB port on your osbdm/index.cfm and click computer to the mini-B USB connector “OSBDM Virtual Serial Toolkit” on the TWR-S08DC-PT60 daughter card. to download). Allow the PC to automatically configure 4. Create a local workspace (folder) on the USB drivers as needed. USB drivers your computer, for example, PT60Lab.
- Page 6 Quick Start Guide Step-by-Step Installation Instructions (cont.) Run CodeWarrior 3. Click “File > Import…” menu item to open Import dialog. In the Import Software V10.2 or Later dialog, double click “General” and and Debug Environment select the “Existing Projects into Workspace”...
- Page 7 TOWER SYSTEM Run and Debug Lab 7. Click the lab project name to highlight it. Click the “Project > Clean…” menu Code on TWR-S08DC- item to bring up the Clean dialog. In this PT60 Daughter Card dialog, check “Clean projects selected below.”...
- Page 8 Learn More and stop program execution after the routine returns to its caller. This After completing the steps in this command causes execution to return quick start guide, please take a look at up the call chain. the TWR-S08DC-PT60 Labs Tutorial document (TWR-S08DC-PT60_LAB) to learn more about the key benefits that MC9S08PT60 provides to your application.
- Page 9 Note: Other jumpers are open. For some labs, special connections are required. For more information on the special connections, consult TWR-S08DC-PT60 Labs Tutorial. Populated when connected to TWR-S08UNIV (Populate R53: when VDD_U is 5V; Populate R54: when VDD_U is 3.3V) and de-populated when disconnected from TWR-S08UNIV.
- Page 10 Quick Start Guide...
- Page 11 TOWER SYSTEM...
-
Page 12: Warranty
Join the online Tower community at towergeeks.org Freescale, the Freescale logo and CodeWarrior are trademarks or registered trademarks of Freescale Semiconductor, Inc. Reg. U.S. Pat. & Tm. Off. All other product or service names are the property of their respective owners. © 2012 Freescale Semiconductor, Inc.
