Contemporary Controls USB22 Series Installation Manual

Arcnet network interface modules with usb interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USB22 Series
®
ARCNET
Network Interface Modules with USB Interface

INTRODUCTION

The USB22 Series of ARCNET Network Interface Modules (NIMs)
links Universal Serial Bus (USB) computers with the ARCNET Local
Area Network (LAN). USB has become popular for connecting desktop
or laptop computers to peripherals because of its very high-speed interface
(up to 480 Mbps) and its convenience of a powered exterior interface with
no need to open the computer.
Each USB22 includes a COM20022 ARCNET controller that can
support data rates up to 10 Mbps and a microcontroller to transfer data
between the ARCNET and either USB 2.0 or USB 1.1 devices. The NIM
is powered from a computer USB port or a USB hub. Models exist for the
most popular ARCNET physical layers. A USB cable is also provided.
NOTE: The USB22 Series of NIMs are for users who are willing and
able to modify their application-layer software. Some OEM companies
have modified their software to work with the USB22. If your
application is not provided by one of these companies, you cannot use
the USB22 — unless you rewrite your application software or hire a
Software engineer to do it. (See the SOFTWARE section of this
installation guide for information about the Software Developer Kit.)
If USB22-compliant software is provided by your OEM and you
encounter installation difficulties, you should contact your OEM for
resolution of your issue — because Contemporary Controls has no
knowledge of the OEM software.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USB22 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Contemporary Controls USB22 Series

Summary of Contents for Contemporary Controls USB22 Series

  • Page 1 USB port or a USB hub. Models exist for the most popular ARCNET physical layers. A USB cable is also provided. NOTE: The USB22 Series of NIMs are for users who are willing and able to modify their application-layer software. Some OEM companies have modified their software to work with the USB22.
  • Page 2 Trademarks Contemporary Controls, ARC Control, ARC DETECT, BASautomation, CTRLink, EXTEND-A-BUS, RapidRing are trademarks or registered trademarks of Contemporary Control Systems, Inc. Specifications are subject to change without notice. Other product names may be trademarks or registered trademarks of their respective companies.

  • Page 3: Specifications

    SPECIFICATIONS Electrical Current demand: 400 mA (max) Environmental Operating temperature: 0°C to +60°C –40°C to +85°C Storage temperature: Humidity: 10% to 95%, non-condensing ARCNET Data Rates Shipping Weight 1 lb. (.45 kg) Compatibility ANSI/ATA 878.1 USB 1.1 and USB 2.0 Regulatory Compliance CE Mark, RoHS CFR 47, Part 15 Class A...
  • Page 4 RJ-45 Connector Pin Assignments 4000 Line – Line – Line Line Line + Line + Figure 1 — RJ-45 Connector (All other pins are unused.) Screw Terminal Pin Assignments 4000 Line – Line Shield Shield Figure 2 — 3-pin Connector Line Line + Mechanical...
  • Page 5 INSTALLATION ® SOFTWARE (Windows 2000/XP/Vista/7) When a USB cable first connects the NIM to a PC and you are prompted for a driver, follow the instructions that appear when you click on the Software Developer Kit link at the following URL: www.ccontrols.com/support/usb22.htm INDICATOR LIGHTS ARCNET: This will flash green in response to any ARCNET activity.
  • Page 6 -TB5 Twisted-pair Bus The -TB5 transceiver accommodates twisted-pair cabling via a pair of RJ-45 jacks which allow the unit to be daisy-chained at any location on the bus segment. Usually IBM type 3 unshielded twisted-pair cable (UTP) is used, but shielded cable (STP) can also be used to provide continuous shielding between devices.
  • Page 7 -4000 AC-Coupled EIA-485 The AC-coupled EIA-485 transceiver offers advantages over the DC-coupled version. No bias adjustments are needed and wiring polarity is unimportant. Much higher common mode voltage levels can be achieved with AC coupling because the transformer coupling has a breakdown rating of 1000 VDC.

  • Page 8: Declaration Of Conformity

    When contacting our offices by telephone, ask for Technical Support. WARRANTY Contemporary Controls (CC) warrants this product to the original purchaser for two years from the product shipping date. Product returned to CC for repair is warranted for one year from the date the repaired product is shipped back to the purchaser or for the remainder of the original warranty period, whichever is longer.
