Summary of Contents for Rosemor T10i
- Page 1 Operation and Maintenance Instructional Manual Automatic Travelator/Escalator Deep Cleaner (Horizontal Only) T10i ROSEMOR INTERNATIONAL LIMITED UNIT F MOSES WINTER WAY WALLINGFORD OXFORDSHIRE OX10 9FE TELEPHONE (+44)01491 838011 FAX (+44)01491 832010 info@rosemor.com www.rosemor.net...
- Page 2 It is therefore vital that the operator receives instruction and training from Rosemor International Ltd specialists before the cleaning machine is started for the first time. The present operation and maintenance instruction manual represent additional assistance for the operator in obtaining the information necessary for correct and safe use of the cleaning machine.
-
Page 3: Table Of Contents
2.3 Location of components ........................10 3 Operation .........................11 3.1 Before start-up............................ 11 Replacing and Maintaining the T10i Brushes ..................11 3.3 Filling the water tanks......................... 11 3.4 Starting the machine......................... 12 3.5 Lowering and Raising the transport wheels..................12... -
Page 4: Safety Instructions
• The automatic travelator deep cleaning machine T10i is not intended, nor suitable for cleaning hazardous or flammable dirt. • The machine is not fire-proof. • The machine is also not licensed for use in cleaning public streets and paths. -
Page 5: Modifications And Changes To The Machine
Automatic Travelator Deep Cleaning Machine – T10i V1.0 1.6 Modifications and changes to the technical data provided by the manufacturer machine must be observed and only original spare parts used; otherwise safety of the machine could be It is forbidden for reasons of safety to carry out impaired. -
Page 6: Warning Signs And Stickers
1.10 Warning signs and stickers 1.13 Sources of Danger Be aware of the potential trip hazards that are Markings, warning signs and present when using the T10i. There are trailing stickers may never be hoses and cables when operating the T10i, extra removed! -
Page 7: Description
Automatic Travelator Deep Cleaning Machine – T10i V1.0 2 Description 2.1 Technical data Working width: 600 mm Continuous cleaning Max. air volume of suction: 162 m³ / h Low pressure: 300 mbar A.C. current Type of current/ frequency: 50 Hz... -
Page 8: List Of Reference Numbers
Automatic Travelator Deep Cleaning Machine – T10i V1.0 2.2 List of reference numbers Water Tank Cover Service hours counter Control Panel Suction machine OFF/ON Clean Tank Dirty Tank Retractable Wheels STOP key ON/OFF Key switch Touch operation of pump Automatic ON... - Page 9 Automatic Travelator Deep Cleaning Machine – T10i V1.0 2.3 Overview of components Fig. 1: Overview of components Created by Rosemor International Ltd Page 9...
- Page 10 Automatic Travelator Deep Cleaning Machine – T10i V1.0 Fig. 2: Control panel Created by Rosemor International Ltd Page 10...
-
Page 11: Operation
3.2 Replacing and Maintaining the T10i Brushes To maintain or replace the 10 brushes on the T10i, turn the machine over (See Fig. 3). Shaft Fig. 3: Water Tanks To remove the dirty tank, simply remove the hose as per Fig. -
Page 12: Starting The Machine
Auto start button (11) will flash Green when ready Move the T10i into position on the travelator Fig. 5: Control panel Once the T10i is in place, you can lower the wheels. 3.5 Lowering and Raising the Transport Wheels Fig. 6 & 7 Ready to clean Fig.
