  • Page 1 EOS-1300 Series EOS-1300/EOS-1310/EOS-1320/EOS-1330 4CH GigE Vision System User’s Manual 2.00 Manual Rev.: Nov. 4, 2016 Revision Date: 50-1Z222-2000 Part No: Advance Technologies; Automate the World.
  • Page 2 Revision History Revision Release Date Description of Change(s) Nov. 4, 2016 2.00 Initial Release...

  • Page 3: Preface

    EOS-1300 Preface Copyright 2016 ADLINK Technology, Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 4 Conventions Take note of the following conventions used throughout this manual to make sure that users perform certain tasks and instructions properly. Additional information, aids, and tips that help users perform tasks. NOTE: NOTE: Information to prevent minor physical injury, component dam- age, data loss, and/or program corruption when trying to com- plete a task.

  • Page 5: Table Of Contents

    EOS-1300 Table of Contents Revision History..............ii Preface ..................iii List of Tables................. vii List of Figures ................ ix 1 Introduction ................ 1 Features................2 Specifications............... 3 Mechanical Drawings............5 Front Panel I/O Connectors ..........6 1.4.1 LED Indicators ............7 1.4.2...
  • Page 6 Installing Memory............... 23 Installing a Hard Disk or SS Drive........25 Installing the Internal USB Dongle ........28 Installing Wall-mount Brackets........... 29 Installing DIN Rail Bracket ..........30 Cooling Considerations............31 Driver Installation ............... 32 A Appendix: BIOS Setup............33 Main ................... 34 A.1.1 System Management..........

  • Page 7: List Of Tables

    EOS-1300 List of Tables Table 1-1: LED Indicator Legend..........7 Table 1-2: DC Power Supply Connector Signals......8 Table 1-3: GigE Camera Port Pin Assignments ......10 Table 1-4: LED Indicator Legend..........10 Table 1-5: I/O1, DB-26P Connector Pin Assignments....11 Table 1-6: I/O2 DB-37P Connector Pin Assignments....
  • Page 8 This page intentionally left blank. viii List of Tables...

  • Page 9: List Of Figures

    EOS-1300 List of Figures Figure 1-1: Top View................5 Figure 1-2: Front View................ 5 Figure 1-3: Rear View ................ 6 Figure 1-4: (Right) Side View ............. 6 Figure 1-5: Front Panel I/O ..............6 Figure 1-6: Power Supply Connector Pin Assignments ..... 8 Figure 1-7: GigE Camera Port ............
  • Page 10 This page intentionally left blank. List of Figures...

  • Page 11: Introduction

    TCO. With its highly integrated DI/O function, GigE vision, and PoE technology, the EOS-1300 is the ideal choice for machine produc- tion or factory automation operations requiring compact size, 2 to 4 GigE-enabled cameras, and DI/O & Encoder control.

  • Page 12: Features

    1.1 Features 6th Gen Intel® Core™ i7/i5/i3 processors  FPGA-based DI/O, trigger I/O and encoder functions, fixed  and low latency 232W x 180.8D x 82.8H mm (9.1 x 7.1 x 3.4 in) with front-  mounted I/O Internal USB port and onboard SHA-256 License Security ...

  • Page 13: Specifications

    EOS-1300 1.2 Specifications EOS-1300 EOS-1310 EOS-1320 EOS-1330 System Core Intel® Core™ Intel® Core™ Intel® Core™ Processor Intel® G3900 i7-6700 i5-6500 i3-6100 Memory DDR4 2133 4GB (up to 32 GB) Supported OS W7P/W8.1/W10 64bit Graphics Display Port Camera Interface 4-CH Gigabit, support for PoE (power over Ethernet), GigE Vision IEEE 802.3af compliant...
  • Page 14 EOS-1300 EOS-1310 EOS-1320 EOS-1330 Operating 0.5 Grms, 5-500 Hz, 3 axes w/HDD Vibration Operating 1 Grms, 5-500 Hz, 3 axes w/ SSD Shock Operating 20G, half sine 11 ms duration CE & FCC Class A Safety CE/LVD, UL, CB Power Consumption 1.2W...

  • Page 15: Mechanical Drawings

    EOS-1300 1.3 Mechanical Drawings All dimensions shown are in millimeters (mm) unless otherwise stated. NOTE: NOTE: 180.8 190.5 Figure 1-1: Top View 81.5 82.8 Figure 1-2: Front View Introduction...

  • Page 16: Front Panel I/O Connectors

    Figure 1-3: Rear View 4.25 Figure 1-4: (Right) Side View 1.4 Front Panel I/O Connectors Figure 1-5: Front Panel I/O Introduction...

  • Page 17: Led Indicators

    EOS-1300 I/O connectors and controls on the EOS-1300 front panel, as labeled, are as follows LED Indicators  Power button  Reset button  DC power connector  GigE camera port  I/O 1, DB-26P Digital I/O connector  Audio connectors, 7.1 channel audio via 5 jacks and S/PDIF ...

  • Page 18: Reset Button

    1.4.3 Reset Button Executes hard reset. 1.4.4 DC Power Connector Consists of V+, chassis ground, and V- pins. V+ and V- pins accept DC power input and chassis ground pin enhances EMC compatibility. The DC power input accepts 24 VDC input. Figure 1-6: Power Supply Connector Pin Assignments Signal V+(DC_IN)

  • Page 19: Gige Camera Port

    EOS-1300 1.4.5 GigE Camera Port CH1 to CH4 connect GigE cameras and support PoE (Power over Ethernet) functions, with support as follows. 4x fully-integrated Gigabit Ethernet Media Access Control  (MAC) and physical layer (PHY) ports IEEE 802.3.af compliant for up to 8 W/channel with power ...

  • Page 20: Digital I/O And Encoder Connectors (I/O1 And I/O2)

    Signal MDI3- (PoE_DC0V) Table 1-3: GigE Camera Port Pin Assignments Color Activity Unlit 10Mbps LED1 Green/ Green 100Mbps (Speed) Yellow Yellow 1000Mbps Unlit Ethernet port is disconnected LED2 Green Ethernet port is connected with no activity (Active/Link) Flashing Ethernet port is connected and active Table 1-4: LED Indicator Legend 1.4.6 Digital I/O and Encoder Connectors (I/O1 and I/O2)

  • Page 21: Table 1-5: I/O1, Db-26P Connector Pin Assignments

    EOS-1300 Signal Signal IDI_0H IDO_2 IDI_1H IDO_2_COM IDI_2H IDO_3 IDI_3H IDO_3_COM IDI_0_1_2_3L IDI_4_5_6_7L IDI_4H IDO_4 IDI_5H IDO_4_COM IDI_6H IDO_5 IDI_7H IDO_5_COM IDO_0 IDO_6 IDO_0_COM IDO_6_COM IDO_1 IDO_7 IDO_0_COM IDO_7_COM Table 1-5: I/O1, DB-26P Connector Pin Assignments I/O2 is a DB-37P connector receiving 4CH isolated digital input (DI...

  • Page 22: Table 1-6: I/O2 Db-37P Connector Pin Assignments

    Pin Signal Pin Signal IDI_8H IDI_9H IDI_10H IDI_11H IDI_8_9_10_11L 22 IDO_8 IDO_8_COM IDO_9 IDO_9_COM IDO_10 IDO_10_COM IDO_11 IDO_11_COM IDO_12 IDO_12_COM IDO_13 IDO_13_COM IDO_14 IDO_14_COM IDO_15 IDO_15_COM EA1+ EA0+ EA1- EA0- EB1+ EB0+ EB1- EB0- EZ1+ EZ0+ EZ1- EZ0- Table 1-6: I/O2 DB-37P Connector Pin Assignments DI/O and Encoder Electrical Specifications 12CH Isolation DI Logic high...

  • Page 23: Serial Ports (Com1 And Com2)

    EOS-1300 16CH Isolation D0 Logic high Max. 30V Logic low Max. 3.5V @ 100mA Sink/Source current Max. 100mA Isolation voltage 1.5kV DC channel 0 to 15 Opto-isolator turn on: 25µs Maximum delay Opto-isolator turn off: 300µs 2CH Encoder Input voltage 5V ±...

  • Page 24: Table 1-7: Com1 And Com2 Connectors Pin Assignments

    Signal RS232 RS422 RS485 DCD# TXD422- 485DATA- TXD422+ 485DATA+ RXD422+ DTR# RXD422- DSR# RTS# CTS# Table 1-7: COM1 and COM2 Connectors Pin Assignments Setting COM1 COM1 can be set to RS-232/422/485 using switch SWS1M1, located on the mainboard as shown. Figure 1-11: SWS1M1 Switch Introduction...

  • Page 25: Lan Ports

    EOS-1300 Figure 1-12: SWS1M1 Switch Location Switch settings are as follows. RS-232 (Default) RS-422 RS-485 Table 1-8: SWS1M1 Switch Setting 1.4.8 LAN Ports Two LAN Ethernet controllers based on Intel® i219LM/i211AT both support up to 1Gb/s. Introduction...

  • Page 26: Table 1-9: Lan Port Pin Definitions

    LED1 LED2 Figure 1-13: LAN Port 10BASE-T/100BASE-TX 1000BASE-T LAN_MDI0+ LAN_MDI0- LAN_MDI1+ LAN_MDI2+ LAN_MDI2- LAN_MDI1- LAN_MDI3+ LAN_MDI3- Table 1-9: LAN Port Pin Definitions Activity No Link LED1 Orange Link Active (Active/Link) Blinking Data Activity 10 Mb connection LED2 Green 100 Mb connection (Speed) Orange 1 Gb connection...

  • Page 27: Displayport Connectors

    EOS-1300 1.4.9 DisplayPort Connectors Two DisplayPort v1.1 connections support up to 3840x2160 @ 30Hz. Figure 1-14: DisplayPort Connector Signal Signal CN_DP0_P CN_DP0_N CN_DP1_P CN_DP1_N CN_DP2_P CN_DP2_N CN_DP3_P CN_DP3_N CN_CAD-L CN_CEC CN_AUX_P CN_AUX_N DDP_HPD P3V3 Table 1-11: DisplayPort Pin Assignment 1.4.10 USB Ports 4 USB 3.0 and 4 USB 2.0 ports each provide 5V power for con-...

  • Page 28: Table 1-12: Usb 2.0 Pin Assignments

    Figure 1-15: USB 2.0 Pin Signal UV0- UV0+ Table 1-12: USB 2.0 Pin Assignments Figure 1-16: USB 3.0 Signal USB3.0_P5VA USB2_CMAN USB2_CMAP USB3A_CMRXN USB3A_CMRXP Introduction...

  • Page 29: Di/O And Encoder Sample Circuits

    EOS-1300 Signal USB3A_CMTXN USB3A_CMTXP Table 1-13: USB 3.0 Pin Assignments 1.5 DI/O and Encoder Sample Circuits 1.5.1 Isolated Digital Input Circuits The input can accept voltages up to 24V, with extra 2.4kΩ input resistors (Rs). Connections between outside signals are as fol- lows.

  • Page 30: Isolated Encoder Input Circuits

    Opto- IDO_COM isolators 2.26k Device 2.26k Figure 1-18: Digital Output Sample Application Circuit for Sink Type IDO_COM Opto- isolators 2.26k Device 2.26k Figure 1-19: Digital Output Sample Application Circuit for Source Type 1.5.3 Isolated Encoder Input Circuits Encoder inputs can connect to either a single-ended or differential encoder.

  • Page 31: Figure 1-20: Encoder Input Sample Application Circuit

    EOS-1300 External Encoder with line driver Opto- EA+/EB+/EZ+ output isolators R=330 EA/EB/EZ A/B/Z phase C=100pF signal EA-/EB-/EZ- Figure 1-20: Encoder Input Sample Application Circuit for Line Driver External Power Opto- EA+/EB+/EZ External Encoder isolators R=330 with open collector EA/EB/EZ output...
  • Page 32 This page intentionally left blank. Introduction...

  • Page 33: Getting Started

    EOS-1300 Getting Started 2.1 Unpacking Checklist Before unpacking, check the shipping carton for any damage. If the shipping carton and/or contents are damaged, inform your dealer immediately. Retain the shipping carton and packing materials for inspection. Obtain authorization from your dealer before returning any product to ADLINK.
  • Page 34 2. Remove the top cover. 3. Insert the memory module into the DDR4 SO-DIMM socket and press down until the module is properly seated and the retaining clips close on the module. Getting Started...

  • Page 35: Installing A Hard Disk Or Ss Drive

    EOS-1300 2.4 Installing a Hard Disk or SS Drive 1. Remove the top cover as detailed previously. 2. Unplug the SATA cable. 3. Remove the two screws from the case underside. Getting Started...
  • Page 36 4. Remove the two screws fixing the drive bracket. 5. Withdraw the bracket and remove the four bracket screws. Getting Started...
  • Page 37 EOS-1300 6. Remove and/or replace the drive, secure the drive, and note the orientation. Getting Started...

  • Page 38: Installing The Internal Usb Dongle

    7. Replace the four bracket screws. 8. Replace and secure the SSD or HDD bracket, and fas- ten the fixing screws. 9. Replace the case underside screws. 10.Insert and secure the SATA cable. 11. Replace the top cover. 2.5 Installing the Internal USB Dongle 1.

  • Page 39: Installing Wall-Mount Brackets

    EOS-1300 2.6 Installing Wall-mount Brackets Secure the provided wall-mount brackets in the four screw holes in the underside of the chassis, as shown. Getting Started...

  • Page 40: Installing Din Rail Bracket

    2.7 Installing DIN Rail Bracket Secure the provided DIN rail bracket via the two screw holes on the rear side of the chassis, as shown. Getting Started...

  • Page 41: Cooling Considerations

    EOS-1300 2.8 Cooling Considerations To maximize the efficiency of fan-based heat dissipation, maintain a minimum 3cm (1.2 inches) clearance from the top vents and 5cm (2 inches) from the side vents. Getting Started...

  • Page 42: Driver Installation

    2.9 Driver Installation Due to lack of controller support under Windows 7, successful OS installation may be prevented. For available solutions, please contact your ADLINK representative. NOTE: NOTE: Download requisite drivers, as follows, for your system from http:// www.adlinktech.com and install. Chipset ...

  • Page 43: A Appendix: Bios Setup

    EOS-1300. The BIOS setup program includes menus for configuring settings and enabling features of the EOS-1300 series. Most users do not need to use the BIOS setup program, as the EOS-1300 ships with default settings that work well for most configurations.

  • Page 44: Main

    A.1 Main BIOS Setup...
  • Page 45 EOS-1300 System Information Shows current system project version, build date and time. Processor Information Shows current system brand string, frequency, processor id, stepping, number of processors, GT info, IGFX VBIOS version, and total memory. PCH Information Shows current system Name, PCH SKU, stepping, LAN PHY revision, ME FW version and ME firmware SKU.

  • Page 46: System Management

    System Time/System Date Changes system time and date. Highlight System Time or System Date using up or down Arrow keys. Enter new values using the keyboard then Enter. Use Tab to move between fields. A.1.1 System Management BIOS Setup...
  • Page 47 EOS-1300 Board Information BIOS Setup...
  • Page 48 Shows current system SEMA firmware, SEMA firmware build date, SEMA bootloader, SEMA bootloader build date, hardware version, serial number, manufacturing date, last repair date, MAC ID and SEMA features. BIOS Setup...
  • Page 49 EOS-1300 Temperatures and Fan Speed Shows current system CPU and board temperatures and CPU fan speed. BIOS Setup...
  • Page 50 Power Consumption Shows current system VCORE, VGFX, VMEM, 5VSB, VIN (12V), 5V, 3.3V, 3.3VSB, RTC and input current. BIOS Setup...
  • Page 51 EOS-1300 Runtime Statistics Shows current system total runtime, current runtime, power cycles, boot cycles, and boot reason. BIOS Setup...
  • Page 52 Flags Shows current system BMC flags, BIOS select, ATX/AT-mode and exception code. BIOS Setup...
  • Page 53 EOS-1300 Power Up Enables/disables Power Up Watchdog reset of the system a certain amount of time after power up. Pressing F12 during startup disables Power Up Watchdog. BIOS Setup...
  • Page 54 Smart Fan Sets CPU fan mode from AUTO (Smart Fan) or Full Speed. BIOS Setup...

  • Page 55: Advanced

    EOS-1300 A.2 Advanced Setting incorrect or conflicting values in Advanced BIOS Setup may cause system malfunction CAUTION: Accesses advanced options of the EOS-1300. BIOS Setup...

  • Page 56: Cpu

    A.2.1 BIOS Setup...
  • Page 57 EOS-1300 Limit CPUID Maximum Disabled for Windows XP. Execute Disable Bit XD can prevent certain malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Win- dows XP SP2, SuSE Linux 9.2, or Red Hat Enterprise 3 Update ®...
  • Page 58 VT-d Enables/disables VT-d capability. ® Intel SpeedStep(tm) Allows more than two frequency ranges to be supported. Turbo Mode Enables/disables Intel ® TurboBoost Technology. CPU C states Enables/disables CPU C states. Enhanced C-states Enables/disables C1E. When enabled, CPU will switch to mini- mum speed when all cores enter C-State.

  • Page 59: Sata

    EOS-1300 A.2.2 SATA SATA Speed Selection Indicates the maximum speed the SATA controller can support. BIOS Setup...

  • Page 60: Memory

    A.2.3 Memory Shows current system memory RC version and values for memory frequency, total memory, VDD, DIMM#0, DIMM#1 and Memory Timings (tCL-tRCD-tRP-tRAS). BIOS Setup...

  • Page 61: Graphics

    EOS-1300 A.2.4 Graphics Graphics Turbo IMON Current Graphics turbo IMON current values supported (14-31). GTT Size Sets GTT size. Aperture Size Sets aperture size. OVer 4GB MMIO BIOS assignment is auto- matically enabled when selecting 2048MB aperture, when CSM support is disabled.

  • Page 62: Usb

    DVMT Pre-Allocated Sets DVMT 5.0 Pre-allocated (Fixed) graphics memory size used by the internal graphics device. DVMT Total Gfx Mem Sets DVMT5.0 Total graphic memory size as used by the internal graphics device. Gfx Low Power Mode Applicable for SFF only. A.2.5 BIOS Setup...
  • Page 63 EOS-1300 Legacy USB Support Enables Legacy USB support, with AUTO disabling legacy sup- port if no USB devices are connected and DISABLE keeping USB devices available only for EFI applications. XHCI Hand-Off A workaround for OS without XHCI hand-off support, with XHCI ownership change claimed by XHCI driver.

  • Page 64: Super Io

    A.2.6 Super IO Shows current system Super IO Chip, Serial Port 1 Configuration and Serial Port 2 Configuration. BIOS Setup...
  • Page 65 EOS-1300 Serial Port 1 Configuration BIOS Setup...
  • Page 66 Serial Port 2 Configuration BIOS Setup...

  • Page 67: Serial Port Console

    EOS-1300 A.2.7 Serial Port Console Console Redirection Enables console redirection on COM 1 to 2 and EMS COM. Console Redirection Settings Sets miscellaneous parameters for COM Ports 1 to 2 and EMS COM. Legacy Console Redirection Settings Selects a COM port to display redirection of Legacy OS and Legacy OPROM Messages.

  • Page 68: Network

    A.2.8 Network Network Stack Enables/disables UEFI network stack. PCH LAN i219LM Controller Enables/disables onboard NIC i219LM. i219-LM Wake on LAN Enables/disables integrated LAN to wake the system. (The Wake On LAN cannot be disabled if ME is on at Sx state.) PCH LAN i211 Controller Enables/disables onboard NIC i211.

  • Page 69: Security

    EOS-1300 A.2.9 Security Displays current system BIOS security configuration and Trusted Computing settings. BIOS Setup...
  • Page 70 BIOS Security Configuration RTC Lock When enabled, locks bytes 38h-3Fh in the lower/upper 128- byte bank of RTC RAM. BIOS Lock Enables/disables PCH BIOS Lock Enable (BLE bit). BIOS Setup...
  • Page 71 EOS-1300 Trusted Computing Security Device Support Enables/disables BIOS support for security device, with OS not showing Security Device and TCG EFI protocol and INT1A interface unavailable. TPM State Enables/disables Security Device. Computer will reboot during restart in order to change State of the Device.

  • Page 72: Security

    Device Select TPM 1.2 restricts support to TPM 1.2 devices, TPM 2.0 restricts support to TPM 2.0 devices, Auto supports both with the default set to TPM 2.0 devices if not found, and TPM 1.2 devices are enumerated. A.3 Security If only the Administrator’s password is set, access to Setup is lim- ited and the password requested when entering.

  • Page 73: Boot

    EOS-1300 User Password Sets User Password. A.4 Boot Setup Prompt Timeout Number of seconds before setup activation key is launched, with 65535(0xFFFF) generating indefinite waiting. Bootup NumLock State Sets keypad Number Lock status following boot. BIOS Setup...
  • Page 74 Quiet Boot When Disabled, directs BIOS to display POST messages, and when Enabled, directs BIOS to display the OEM logo. Boot Option Priorities Specifies the priority of boot devices, all detected during POST and displayed. Select Boot Option # and select the desired device. Fast Boot Enables or disables boot initializing the minimum devices required to launch active boot option.

  • Page 75: Csm Configuration

    EOS-1300 A.4.1 CSM Configuration CSM Support Enables/disables CSM Support. GateA20 Active UPON REQUEST disables GA20 using BIOS services, and ALWAYS prevents GA20 from being disabled, indicated when any RT code exceeding 1MB is executed. Option ROM Messages Sets display mode for Option ROM.
  • Page 76 INT19 Trap Response BIOS reaction on INT19 trapping by Option ROM, with IMMEDI- ATE executing trap immediately, and POSTPONED executing trap during legacy boot. Boot option filter Controls Legacy/UEFI ROM priority. Network Controls execution of UEFI and Legacy PXE OpROM. Storage Controls execution of UEFI and Legacy Storage OpROM.

  • Page 77: Save & Exit

    EOS-1300 A.5 Save & Exit Save Changes and Exit Exits system setup after saving changes. Discard Changes and Exit Exits system setup without saving any changes. Save Changes and Reset Resets the system after saving the changes. BIOS Setup...
  • Page 78 Discard Changes and Reset Resets the system without saving any changes. Save Changes Saves changes made to that point to any Setup options. Discard Changes Discards changes made to that point to any Setup options. Restore Defaults Restores/loads default values for all Setup options. Save as User Defaults Saves changes made to that point as User defaults.

  • Page 79: Important Safety Instructions

    EOS-1300 Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/operating the device, to avoid injury or damage. S'il vous plaît prêter attention stricte à tous les avertissements et mises en garde figurant sur l'appareil , pour éviter des blessures...
  • Page 80 Never attempt to repair the device, which should only be  serviced by qualified technical personnel using suitable tools A Lithium-type battery may be provided for uninterrupted  backup or emergency power. Risk of explosion if battery is replaced with one of an incorrect type;...
  • Page 81 EOS-1300 BURN HAZARD Touching this surface could result in bodily injury. To reduce risk, allow the surface to cool before touching. RISQUE DE BRÛLURES Ne touchez pas cette surface, cela pourrait entraîner des blessures. Pour éviter tout danger, laissez la surface refroidir avant de la toucher.
  • Page 82 This page intentionally left blank. Important Safety Instructions...

  • Page 83: Getting Service

    San Jose, CA 95138, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-360-0222 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. Address: (201203) 300 Fang Chun Rd., Zhangjiang Hi-Tech Park Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com...
  • Page 84 84 Genting Lane #07-02A, Cityneon Design Centre Singapore 349584 Tel: +65-6844-2261 Fax: +65-6844-2263 Email: singapore@adlinktech.com ADLINK Technology Singapore Pte. Ltd. (Indian Liaison Office) Address: #50-56, First Floor, Spearhead Towers Margosa Main Road (between 16th/17th Cross) Malleswaram, Bangalore - 560 055, India Tel: +91-80-65605817, +91-80-42246107 Fax:...
