Quintel QS Series MultiServ Installation Manual

The Quintel QS Series MultiServ
technology uniquely delivers multiple independent services in single slim-line antennas. This
enables existing antenna constrained network sites to be upgraded to add new services such as
LTE in the 700, AWS & WCS bands with the replacement of one antenna.
TM
The Quintel MultiServ Multiband Multi Port Antennas are an ideal solution for independently
optimizing multiple services when rapidly introducing new technologies. Technology agnostic,
each band provides flexibility for existing and future technologies such as GSM, CDMA, UMTS,
LTE and advanced 2Tx4Rx and 4Tx4Rx MIMO implementations.
The tilt of each band is controlled independently via internal RET actuators compliant to AISG1.1, AISG2.0 and 3GPP protocols.
Depending on the model, the antenna provides a total of 2, 3, 4 or 6 independent tilts. Detailed specifications for each antenna model
can be found in their
http://www.quintelsolutions.com/datasheets-patterns.html
Features
Antenna component with:
•
Product families providing multiple frequency
options refer to specific data sheets per technical
specifications.
•
Simple Antenna swap out.
•
Variable electrical tilt.

Table of Contents

1 INSTALLATION OVERVIEW ............................................................................................................... 2
1.1 M H
OUNTING ARDWARE
1.2 S M
UPPLIED OUNTING
1.3 M H
OUNTING ARDWARE
2 HEALTH & SAFETY ............................................................................................................................ 3
3 UPPER ARM & MOUNT ASSEMBLY: AS-001182, SUPPLIED AS PART OF AS-000977 .......................... 4
4 TILT ANGLE INDICATOR GUIDE FOR MULTIPLE ANTENNA PRODUCTS........................................6, 7 & 8
5 LOWER MOUNT ASSEMBLY: AS-001184, SUPPLIED AS PART OF AS-000977 ............................ 9 & 10
6 OPTIONAL LIGHTNING FINIAL AS-001034 ...................................................................................... 11
7 AISG & RF CONNECTIONS FOR 6-PORT ANTENNAS, SBT AND NON-SBT VERSIONS ........................ 12
8 AISG & RF CONNECTIONS FOR 8-PORT ANTENNAS, SBT AND NON-SBT VERSIONS ........................ 13
9 AISG & RF CONNECTIONS FOR 10-PORT ANTENNAS SBT AND NON-SBT VERSIONS ....................... 14
10 AISG & RF CONNECTIONS FOR 12-PORT ANTENNAS, SBT AND NON-SBT VERSIONS ...................... 15
11 AISG CONTROLLER DISPLAY ........................................................................................................... 16
11.1 E 4-T
XAMPLE OF
11.2 E 6-T
XAMPLE OF
12 AISG CONTROLLER DISPLAY - QSX65X-3 MODELS..................................................................................18
12.1 E 4-T
XAMPLE OF
13 RET CONTROL ................................................................................................................................ 19
INS-AS-004024_E
TM
Multiband Multi Port Antennas with patented QTilt™
respective datasheets.
F : ...................................................................................... 2
EATURES INCLUDE
H ................................................................................................... 2
ARDWARE
M S
ECHANICAL PECIFICATIONS
QS66512-2 D ....................................................................................... 16
ILT ISPLAY
QS66512-3 D ....................................................................................... 17
ILT ISPLAY
QS6658-3 D ......................................................................................................18
ILT ISPLAY
MultiServ Multiband Antennas
QS Series Antenna Installation Guide
Datasheets are available
 Supports MIMO services with 2Tx4Rx & 4Tx4Rx capability
depending on model
 AISG & 3GPP compliant internal Remote Electrical Tilt (RET)
 RET configurable for AISG 1.1/2.0 and 3GPP software via
upload
 Provides Multi antenna Ports in a slim-line form factor
 Models with -5 suffix support AISG over RF through internal
Smart Bias-T's (SBT)
......................................................................... 2
Quick Facts:
Product #: QS Family
6,8,10 & 12 Ports
SBT & Non-SBT Variants
Polarisation: XXX
Height: 52", 72" & 96"
Beam Width: 65°
for download at the following
Page 1
link:
