GO Industries 44669 Installation Instructions

420 N. Grove, Richardson, TX 75081
Tele: (800) 527 - 4345 Fax: (800) 442 - 5263
Web site: www.goindustries.com
E-mail: gosupport@goindustries.com

Note: Completely read instructions before beginning installation!

1. Remove the contents from the box and check for missing pieces or damage. If parts are missing or damaged, contact the original place of purchase.
2. If The truck not equipped with tow hooks skip to the next step. If the truck in equipped with tow hooks, remove the four bolts holding each tow hook
in place and remove the tow hooks. These are shown in Diagram 2.
3. Place the factory tow hook onto the driver side bracket #46669-5 and position bracket and tow hook onto the bumper, aligning the four holes. The
bracket will be sandwiched between the bumper and tow hook. Using (4)
attach the bracket and tow hook to the bumper.
four holes. Attach the bracket to the bumper using (4)
this time. Repeat the above procedure to install the passenger bracket #46669-6, as shown in Diagrams 3 & 4.
4. Using two people align the grille guard up to the brackets installed on the truck. Place (1) 1/2" x 1 1/4" bolt with (1) 1/2" flat washer through each of
the six holes in the guard and brackets.. Place (1) 1/2" flat washer, (1) 1/2" lock washer, and (1) 1/2" nut onto each of the 1/2" x 1 1/4" bolts. Hand tighten
at this time.
5. Tighten the brackets to the vehicle first, then tighten all bolts on the grille guard ensuring that the grille guard remains centered on the vehicle.
Page 1 of 2 page 2/17

Diagram 1

7/16" x 1 3/4" bolts, (8) 7/16" flat washers, and (4) 7/16" nylon lock nuts
If the truck is not equipped with tow hooks position the bracket onto the bumper aligning the
7/16" x 1 3/4" bolts, (8) 7/16" flat washers, and (4) 7/16" nylon lock nuts.
Thank you for choosing Go Industries' products. For additional installation
assistance, please call Technical Support (800) 527-4345 or (972) 783-7444
Rancher Grille Guard

Installation Instructions

44669 / 46669
Dodge Ram 2500/3500 '10 - '17
Ram Chassis Cab 3500/4500/5500 '11-'17

Parts List:

1 - Rancher Grille Guard
1 - Driver Bracket #46669-5
1 - Passenger Bracket #46669-6
6 - 1/2" x 1 1/4" Bolts
12 - 1/2" Flat Washers
6 - 1/2" Lock Washers
6 - 1/2" Nuts
8 - 7/16" x 1 3/4" Bolts
16 - 7/16" Flat Washers
8 - 7/16" Nylon Lock Nuts
*May include extra hardware.
Hand tighten at
