palintest DigiPAsS Operation Manual

DigiPAsS Operation Manual
Operation Equipment Key
Graduated
Flask
Filter Paper (arsenic test)
(Labelled Black)
Stage 1: Loading bung device
Take one Hydrogen Sulphide Removal Filter
and insert into the bottom end of the bung.
Take Red Filter (Removal) Slide
and open.
Stage 2: Calibrating the DigiPAsS
Take the DigiPAsS and press any key to switch on.
This will then say 'Insert Slide'.
Then DigiPAsS will instruct to 'Remove Slide', once slide is removed this
then instructs to 'Run Test', which automatically activates timer on the DigiPAsS.
Tri-Filter Arsenic Trap Hydrogen Sulphide
(Bung)
A 1
Powder Sachet
A2
Filter Paper (removal)
(Labelled Red) Tablets A2
Take Black Arsenic Filter Slide and open.
Take one Filter Paper from red labelled pot, use forceps and/or
gloves to insert into position. (repeat filter paper insertion as before)
#
*
Red Filter Slide
(Removal)
Black Filter Slide
Removal Filters (Detection)
Dilution Tube
DigiPAsS
Cleaning Colour Chart
Brush
Take one Filter Paper from black labelled pot, use
forceps and/or gloves to insert into position ensuring
the filter paper is evenly covering the hole.Then
firmly close slide holder, taking care to locate the pins
in the slide holder correctly.
Get Bung device and ONLY insert
the Red Filter (Removal) Slide into the top slot.
Take the pre-loaded Black Arsenic Filter Slide
(the one that has just been fitted with filter paper) and insert slide.
Then take the Black Filter Slide and insert
into the bottom slot of the bung.
Screwdriver
Waste Disposal Bag,
Gloves & Forceps
