Alfa Network Onyx4G User Manual

● PIN code se�ngs
"Se�ng"->"PIN" menu is used to enable/disable, change, modify and unlock locked PIN
code via PUK. When inser�ng a PIN-enabled SIM card, modem will be prompt for PIN code
before using it. If the PIN codes were modified, please unplug/replug modem. The modem
u�lity will prompt for the new PIN code.
< NOTE >
A�er three failed a�empts to enter the PIN code, the SIM card will be locked. To unlock the SIM
card, you will be required to enter the correct PUK to retrieve the default PIN code. Please
contact your service provider to obtain the PUK code informa�on. With incorrect PIN code
input, the modem is unable to register on the network; All network service will be unavailable.
● Reset modem
"Se�ngs"->"Reset" menu is used to restore the device to factory default se�ngs and
reboot the device.
Addi�onal Informa�on
This product is suitable for indoor network access applica�ons, not applicable for outdoor
usage. For up-to-date product informa�on, descrip�ons, documenta�on, applica�on
updates, and support informa�on, please visit www.alfa.com.tw
HARDWARE INSTALLATION
Insert SIM Card Before Using Onyx4G
Slide off the cover on the back of the device.
Insert SIM card as shown in the diagram below.
< Op�onal > microSD card installa�on:
Onyx4G provides a microSD slot for file sharing feature.
To install a microSD card, please upturn the card and insert
it into the card slot as shown in the diagram. A "click" sound
indicates the card is installed properly. (Push the microSD
card again, it will be ejected from the memory card slot.)
Install Onyx4G to Your Computer
Onyx4G is powered by USB host port, and designed to work with
USB 2.0/3.0 port on your computer. To start using Onyx4G,
insert Onyx4G into an available USB port on your computer.
< NOTE >
If the computer does not have Onyx4G drivers installed, Onyx4G will prepare the u�lity program
installa�on.
If the u�lity program is already installed, Onyx4G will be detected, and u�lity program will start
automa�cally.
SOFTWARE INSTALLATION
Install Onyx4G U�lity Program
Onyx4G contains the necessary drivers for Windows 7/8/10
computer ; an installa�on CD is not required. The first �me
connec�ng Onyx4G to a Windows computer, Onyx4G u�lity
program will start the u�lity program installa�on automa�cally.
Please permit the program installa�on if there is a prompt
window during the installa�on. Follow the on-screen instruc�ons
to complete the setup of the Onyx4G u�lity program.
< NOTE >
● If the installa�on does not start automa�cally, please turn on the CD Auto Run feature in your
computer or manually browse the new CD-ROM drive added by Onyx4G in "My Computer",
the setup.exe file of Onyx4G program can be found in the CD-ROM drive.
Manual installa�on: Double-click the "Setup.exe" file and follow the on-screen instruc�ons to
●
complete the Installa�on. (Please permit the program installa�on if there is any prompt
message during the installa�on process.)
4G LTE USB Dongle
User's Manual
