TAGG
FLEX
Portable Bluetooth Speaker
USER'S MANUAL
Thank you so much for buying TAGG FLEX Bluetooth Speaker.
Our main goal is to provide you with a quality product combined
with ease of use. Here is a detailed user's manual that will help
you understand the features & functions of the speaker Please
read the manual carefully before using the product.
Function Introduction
Bluetooth Specification
Bluetooth V4.2 + EDR
Power Output
2 x 3W
Frequency Response
80Hz-20KHz
Rechargeable Lion Battery
3.7V DC/ 1200mAh
Power Input
Micro USB
Audio Input
TF Card, Bluetooth
Microphone Talking Range
within 3 - 100cm
Charging Time
2-3 hrs
Play Time
4 hrs
Talk time
2 hrs
Stand by Time
12 hrs
Panel Function Introduction
2
3
1
4
6
7
FUNCTION
OPERATION
1.
Play/ Pause/ Call
Volume Down/ Previous Song
2.
3.
Volume Increase/ Next Song
4.
Mode Function
5.
Micro USB Charging Point
6.
TF Card Slot
7.
On/Off Button
Connecting with your Device:
Keep your Bluetooth Device with in 3 Ft. while Pairing.
Press the Power button of TAGG FLEX.
Blue and Red LED will blink and it means that the speaker is in
the pairing mode.
Now search for Available bluetooth devices in your
Mobile/Laptop/iPad and select TAGG FLEX from the list of
available devices.
If prompted, enter password or PIN required "0000".
If prompted by your mobile phone to connect, click "YES".
After successfully connecting Blue LED will flash twice after
every 4 secs.
5
How to Charge:
Connect the speaker to the power using Micro USB cable.
To better protect the battery life, kindly use only the charging
cable provided with the headset < 5V, 100 mAH - 240 mAH.
Allow 2-3 hours to completely charge the speaker.
LED Indications:
While Charging - Red LED is On.
When completely charged - RED LED is Off.
When battery is low, Red LED blinks every four seconds twice
and the voice prompt will let you know that battery status.
Pairing Mode- Blue and Red LED starts Flashing.
Reconnect the Speaker:
If the connection is lost, TAGG FLEX will try to reconnect
automatically.
If it does not reconnect, kindly press the Power button for 3 secs
and reconnect manually through your mobile Bluetooth.
