TAGG LOOP User Manual

TAGG
loop
Bluetooth Speaker
USER'S MANUAL
Thank you so much for buying TAGG LOOP Bluetooth Speaker.
Our main goal is to provide you with a quality product combined
with ease of use. Here is a detailed user's manual that will help
you understand the features & functions of the speaker Please
read the manual carefully before using the product.

Function Introduction

Bluetooth Specification : Bluetooth Version 4.0
Power Output : 2 x 8W
Line In : 3.5mm
Rechargeable Lion Battery : 7.4V DC/ 2400mAh
Power Input : Micro USB
AC/DC Charger : DC 5V/ 500mAh
Charging Time : 2-3 hrs
Microphone Talking Range : within 3 - 100cm
Play Time : 4 hrs
Talk time : 2 hrs
Stand by Time : 18 hrs

Panel Function Introduction

TAGG
TF
AOX DC 5V
OFF/ON
USB
FUNCTION OPERATION
1. Play/ Pause/ Call
Volume down/ Previous song
2.
3. Volume increase/ Next song
4. Mode Function
5. AUX-in Port
6. TF Slot
7. USB Slot
8. Micro USB Charging Point
9.
Power On/Off Button
Connecting with your Device:
Keep your Bluetooth Device with in 3 Ft. while Pairing.
Press the Power button of TAGG LOOP.
Blue and Red LED will blink and it means that the headset is in
the pairing mode.
Now search for Available bluetooth devices in your
Mobile/Laptop/iPad and select TAGG LOOP from the list of
available devices.
If prompted, enter password or PIN required "0000".
If prompted by your mobile phone to connect, click "YES".
After Successfully connecting Blue LED will flash twice after
every 4 secs.

How to Charge:

Connect to power using Micro USB.
To better protect the battery life, kindly use only the charging
cable provided with the headset < 5V, 100 mAH - 240 mAH.
Allow 2-3 hours to completely charge the headset.

LED Indications:

While Charging - Red LED is On.
When completely charged - RED LED is Off.
When battery is low, Red LED blinks every four seconds twice
and the voice prompt will let you know that battery status.
Pairing Mode- Blue and Red LED starts Flashing.

Reconnect the Speaker:

If the connection is lost, TAGG LOOP will try to reconnect
automatically.
If it does not reconnect, kindly press the Power button for 3 secs
and reconnect manually through your mobile Bluetooth.
