TECHNICAL DATA
Telescope:
Magnification:
Leveling accuracy:
Working range:
Minimum focus:
Clear objective aperture:
Field of view:
Number of lenses:
Level vial:
Horizontal Circle Diameter:
Graduations:
Number:
Vernier:
Weight:
Mounting:
CARE AND HANDLING
Care must be taken to maintain the accuracy of the instrument.
•
After each use, the instrument should be wiped clean and kept in its carrying case.
•
Remove dust from the lenses with a soft brush or a nonabrasive wipe. Never tough the lenses
with your fingers.
•
Store the instrument in a dust-free area with low humidity.
© Dave White's SitePro, LLC
UM-25TL20X
2/12
Erect, 10.5" (26.5cm)
22X
± 1/4"@100 ft. (±5mm@30m)
Up to 200' (60m)
4' (1.2m)
22mm
± 2'/100 ft. (±0.6m/30m)
5
4' per 2mm
110mm
1º
Each 10º, 0-90-0º
Double direct to 15 min.
2.204 lbs (1Kg)
Screw 5/8-11 Thread
Otterbein, IN
Toll Free: (855) 354-9881
Printed in China
Operating / Safety Instructions
Consignes de fonctionnement / sécurité
Instrucciones de funcionamiento y seguridad
