Step 3; Step 4 - 4D Concepts 71550 Assembly Instructions Manual

ATTENTION : DO NOT TIGHTEN ALL OF THE NUTS UNTIL THE FINAL STEP IS COMPLETED. IMPORTANT TO FULLY TIGHTEN BEFORE SITTING ON CHAIR.

Step 3

H
C
5 1
5
6
Turn the connected seat panel over and place the seat frame
support (K) on the bottom of the seat as shown in diagram.
Secure the seat frame support with the seat panel with bolt
(1), washer (5) and nut (6).
Item Drawing Qty
1 4
5 8
6 4
D
1 5
K
6 5

Step 4

K
C
Attach the seat bottom to the hooks of the support frame.
D
H
page 4
