GS-13 ROTARY SCRUBBER
OPERATIONS MANUAL AND TROUBLESHOOTING GUIDE
Thank you for purchasing ​ M itchell​ ​ P rofessional Floor Cleaning Equipment. ​ P lease
be sure to read the manual before operation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS-13 and is the answer not in the manual?

Questions and answers

Related Manuals for Mitchell GS-13

Summary of Contents for Mitchell GS-13

  • Page 1 GS-13 ROTARY SCRUBBER OPERATIONS MANUAL AND TROUBLESHOOTING GUIDE Thank you for purchasing ​ M itchell​ ​ P rofessional Floor Cleaning Equipment. ​ P lease be sure to read the manual before operation.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING (THIS APPLIANCE) WARNING - To reduce the risk of fire, explosion, electric shock, or injury: 1. Do not use appliance with flammable or combustible liquids/fumes such as gasoline or use in areas where they may be present.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS This machine is intended for commercial use. It is designed exclusively to scrub hard floors in an indoor environment and is not intended for any other purposes. Use only recommended scrubbing brushes and commercially available floor cleaners and waxes intended for machine application.

  • Page 4: Grounding Instructions

    4. Before leaving or servicing machine: - Turn off machine. - Unplug cord from wall outlet. 5. When servicing machine: - Unplug cord from wall outlet. - Avoid moving parts. Do not wear loose jackets, shirts, or sleeves. - Use manufacturer supplied or approved replacement parts. - All repairs must be performed by a qualified service person.
  • Page 5 Machine Maintenance 1. Remove and clean the pad driver/brush after each use. 2. Clean the machine base after each use. 3. Rinse solution tank and solution supply hose with clear water. 4. Inspect power cord for damage after each use. If worn or damaged, replace immediately. 5.

  • Page 6: Troubleshooting Guide

    Troubleshooting guide PROBLEM POSSIBLE CAUSE SOLUTION Faulty power cord. Contact Service Centre Tripped circuit breaker. Reset circuit breaker on machine. Tripped building circuit breaker. Reset circuit breaker in building. Machine does not operate Faulty machine wiring. Contact service centre. Faulty on/off handle switch Contact service centre.
  • Page 8 GS-13 Parts Diagram DESCRIPTION CODE HANDLE SAFETY SWITCH KAR201 HANDLE ADJUSTMENT LEVER KAR202 MOTOR COWL KAR203 WHEEL KAR204 BUMPER KAR205 BRUSH MOTOR KAR206 START CAPACITOR KAR207 RUN CAPACITOR KAR208 PADHOLDER FOR GS-13 KAR209 13” CARPET BRUSH KAR210 13’ FLOOR BRUSH...

  • Page 9: Warranty

    The warranty covers only the replacement, repair or adjustment of any part which in the opinion of Mitchell fails as a result of a fault in manufacture assembly. Note 2 year warranty applies to drive motors and gearbox assemblies on electrical machines.
