Honeywell HD4D3H Quick Install Manual

4 inch dome camera
Hide thumbs

Advertisement

Regulatory Notices
FCC Compliance Statement: HD4UH(X) models
Information to the User: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Note
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
Canadian Compliance Statement: HD4UH(X) models
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
.
FCC Compliance Statement: HD4D3H(X) and HD4DIRH(X) models
Information to the User: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
Note
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Canadian Compliance Statement: HD4D3H(X) and HD4DIRH(X) models
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada
Manufacturer's Declaration of Conformance
The manufacturer declares that the equipment supplied with this guide is compliant with the
essential protection requirements of the EMC directive 2004/108/EC and the General Product Safety
Directive (GPSD) 2001/95/EC, conforming to the requirements of standards EN 55022 for emissions,
EN 50130-4 for immunity, and EN60950 for Electrical Equipment safety.
© 2015 Honeywell International Inc. All rights reserved. No part of this publication may be reproduced by any means without written permission from Honeywell Systems. The information in this publication is
believed to be accurate in all respects. However, Honeywell Systems cannot assume responsibility for any consequences resulting from the use thereof. The information contained herein is subject to change
without notice. Revisions or new editions to this publication may be issued to incorporate such changes.
Operating Notes
Power Supply
This dome camera can operate on 24 V AC or 12 V DC.
UTP Video and Power
UTP video and power may share the same Category 5 cable
Using Same CAT5 Cable
subject to the following conditions:
UTP video shall use a single pair within the CAT5 cable.
Power can utilize one or more of the remaining pairs as
long as the power is always fed using twisted cable pairs in
a differential mode.
On long runs, crosstalk between 24 V AC power and video
may appear in the video. This can be eliminated by using a
DC power source.
Voltage drop in the power feed will limit the maximum
length of a combined UTP and power configuration to
approximately 328 ft (100 m).
Avoid viewing bright objects (for example, light fixtures) for
Operating Conditions
extended periods.
Avoid operating or storing the unit in the following locations:
Extremely humid, dusty, hot, or cold environments where
the operating temperature is outside these recommended
ranges, with the heater on:
• HD4D3H(X)/HD4DIRH(X):−40°F to 131°F [−40°C
to 55°C]
• HD4UH(X):−40°F to 122°F [−40°C to 50°C]
Close to sources of powerful electromagnetic radiation,
such as radio or TV transmitters
Close to fluorescent lamps or objects reflecting light
Under unstable light sources (may cause flickering)
Warnings
Installation and servicing should be performed only by qualified and experienced
technicians to conform to all local codes and to maintain your warranty.
The use of CSA Certified/UL Listed Class 2 power adapters is required to ensure
compliance with electrical safety standards.
WEEE (Waste Electrical and Electronic Equipment).
Correct disposal of this product (applicable in the European Union and other
European countries with separate collection systems)
This product should be disposed of, at the end of its useful life, as per
applicable local laws, regulations, and procedures.
www.honeywell.com/security
+1 800 323 4576 (North America only)
https://honeywellsystems.com/ss/techsupp/index.html
Document 800-20478V2 – Rev A – 06/2015
4-Inch Dome Camera
Quick Install Guide
Document 800-20478V2 – Rev A – 06/2015
Model Numbers
HD4D3H(X)
HD4DIRH(X)
HD4UH(X)

Package Contents

Flush mount
Fully assembled camera
Mounting templates
Adapter plate
Hardware kit
Document 800-20478V2 – Rev A – 06/2015
Surface mount
This guide
