MyCableMart HCHDT5R User Manual

SPECIFICATION

Input Video Signal 0.5-1.0 volts p-p
Input DDC Signal 5 volts p-p (TTL)
Input connection HDMI A female(19pin)
Output connection YPbPr, R/L
Input/output Resolution 480i~1080p
Audio output format 2 channel LPCM
Video Amplifier Bandwidth 1.65Gpbs/165MHz
Length 1 meter
Weight 74g
Operating Temperature 0 ℃ to +70℃
Power Supply USB Power

SAFETY PRECAUTIONS

Please read the following safety precautions carefully before you unpack
and install this equipment.
1.Do not expose the unit to rain, moisture or any other dripping liquids. And
keep it away from any wet locations such as fishing tanks, vases.
2.Do not install the unit close to fire or any other heat sources.
3.Keep the unit in dry and ventilated area. Do not install in bookcase,
cabinet or any other confined space.
4.Stop using the unit during thundering or lightening storms.
5.Avoid the power cable to be stepped on or pinched. Position the unit
carefully to avoid damage or accident.
6.Clean the unit only with dry cloth.
7.Only use accessories specified by the manufacturer.
8.Unplug the equipment when unused for a long period of time.
9.Do not try to open any non-serviceable parts. Contact your authorized
servicing center and personnel.
Keep Away
Keep Dry
from Heat
HDMI to YPbPr+R/L
Danger Electric
Shock Risk

Audio Adapter

HCHDT5R
User Manual
