WeatherHawk Skymate Plus SM-19 User Manual

Skymate Plus Users Manual V1.0

Getting Started

Your Skymate Plus package contains one Lithium CR2032 battery (already installed), calibration numbers (on a
small white paper included with the manual), and a lanyard. It is very important that you keep the calibration
numbers with your manual. Do not throw the calibration paper away! To install the lanyard, feed one end
through the hole at the bottom of the handle and tie it to the other end. Open case and click into fully opened
position or, if using a tripod, click to the 90-degree position. Your Skymate Plus has sensitive sensors. Hold the
Skymate Plus at the bottom of the handle, away from your face and body, to avoid getting false readings.
General Indicators
Modes:
Current Windspeed:
In current windspeed mode, only the unit of measure
will be shown. You can hold gusts by pressing and
holding the hold button.
Maximum Windspeed:
Displays maximum speed recorded since the unit was
turned on.
Units of Measure:
The Skymate Plus measures windspeed in six different units of measure. Knots, Beaufort, Feet Per Minute, Miles Per
Hour, Meters Per Second, and Kilometers Per Hour. To switch between units of measure please see the Units of
Measure section for instruction
(Rev. 10/08)

Operating Modes:

Turn the unit on using the left button. Use the right
button to scroll to the desired wind function. To
change between humidity, dew point (TD), wind-chill
and temperature press & hold down the on/off button
and press mode. To turn off the unit, press and hold the
on/off button for about 3 seconds, then release.
Units of Measure:
With the Skymate Plus off, press and hold the on/off
key for 3 seconds. The display will flash. While
flashing, press the mode to select wind measurements.
Press On/Off and Mode together to select between
Celsius and Fahrenheit.
Average Windspeed:
Displays a running average over 5, 10 or 13 seconds
Wind-Chill:
Displays the effect that air temperature combined with
windspeed has on human skin.
