Reference model name: Toshiba L730
10
11
Slide the HDD/SSD into the IB-
Connect the sata Interface, through
AC649.
further pushing.
Schieben sie die Festplatte in das
Verbinden sie die Sata Anschlüsse,
IB-AC649 ein.
durch weiteres Einschieben
13
14
Take apart the iron slice from the
Fasten the iron slice on the back of
back of DVD drive.
IB-AC649.
Entfernen Sie die metallene Monta-
...und befestigen es an der Rückseite
geschiene an der Rückseite des DVD
des IB-AC649.
Laufwerks...
16
17
Please ensure it connects with the
Fasten the DVD screws near the
notebook tightly again.
middle back of the notebook.
Überprüfen Sie nochmals den
Im mittleren Bereich des Notebooks
richtigen Sitz des IB-AC649 im
befindet sich nun die Befestigung des
Notebook.
IB-AC640. Setzen Sie die entspre-
chende Befestigungsschraube wieder
ein.
Installation
12
Attach the HDD/SSD with provided
screws
Befestigen sie die HDD/SSD mit den
mitgelieferten Schrauben.
15
After finishing above motions, slip
IB-AC640 into the notebook DVD
slot.
Nachdem Sie die eben beschriebenen
Schritte durchgeführt haben, schie-
ben Sie die IB-AC649 vorsichtig in
den DVD Schacht des Notebooks.
18
Finally put the cover back and fasten
the screws to the notebook.
Abschließend setzen Sie die Abde-
ckung des Notebooks wieder ein und
befestigen es mit den zuvor entnom-
menen Schrauben.
© Copyright 2016 by RaidSonic Technology GmbH. All Rights Reserved
The information contained in this manual is believed to be accurate and reliable. RaidSonic Technology GmbH assumes no responsibility for any errors con-
tained in this manual. RaidSonic Technology GmbH reserves the right to make changes in the specifications and/or design of the above mentioned product wi-
thout prior notice. The diagrams contained in this manual may also not fully represent the product that you are using and are there for illustration purposes
only. RaidSonic Technology GmbH assumes no responsibility for any differences between the product mentioned in this manual and the product you may have.
