GSD 2 Door Pin and Proximity Installation & User Manual

GSD 2 Door Pin and Proximity Installation & User Manual

Advertisement

Quick Links

Other products from GSD
"Wireless Network
GSD Wi-Enterprise/Wi-Plus System
next generation in access control solutions.
It provides a Wireless Network throughout
the premises, giving the convenience and
security of a fully networked system for a
fraction of the cost.
For more information on the Wireless Network System visit our
website www.globalsecurity.ie
Global Security Devices Ltd: No.3 Broomhill Business Complex, Tallaght,
Dublin 24, Ireland, Phone: +353 (1) 524 2691, Email: info@globalsecurity.ie
www.globalsecurity.ie
System"
Contents
is the
Operation Instructions
Installation Diagrams
Wiring Diagrams
Quick Reference
Administration Notes
YOUR SECURITY IS OUR PRIORITY
2
6
8
17
18
2 Door Pin and Proximity
Installation & User Manual
V1.00
