Aervoe SIERRA WAVE 9654 Operating Instructions

TECHNICAL INFORMATION

SPECIFICATIONS

POWER CENTER BATTERY Lithium Ion 6-pc, 18650, 2200mAh (13,200mAh),
50-Wh, 5V, 12V, 16V, & 19V output
CHARGE PROTECTION Overcharge, over discharge, overload protection and
short circuit protection
POWER CENTER INPUT 5V DC/1A
POWER CENTER OUTPUT 5V 2A (USB)
12V, 16V, 19V DC, 4A max
OPERATING TEMPERATURE 32° – 120°F (0° – 49°C)
WEIGHT 12 oz. (370g)
DIMENSIONS 6" x 3" x 0.875" (152 x 76 x 17.53 mm)
ACCESSORIES INCLUDED 120V AC Charger
• Input = 120V AC 50/60Hz
• Output = 12V DC/1A
12V DC Charger
• Input = 12/24V DC
• Output 12V DC/1A
10 Laptop adapter tips
Laptop Connection Cable
12V Barrel Power Adapter
Multifunction USB Cable
RoHS
COMPLIANT
CHARGING & OPERATING TIMES Estimate only. Actual times depend on available
sunshine, Power Center battery level, and device
battery condition.
Charge Power Center 120V AC Wall Charger, 6-8 hours
12V DC Vehicle Charger, 8-10 hours
Solar (#9510 not included), 12-16 hours
Recharge portable electronic iPhone 6, up to 6 times
devices from a fully charged Power Galaxy 5, up to 5 times
Center
Tablets will charge up to 75% of battery capacity
depending on model and size
Laptops using a 40-60Wh battery, up to 4 hours. Will
also depend on number of programs running.

LAPTOP TIP REFERENCE GUIDE

Tip Label Brand Color ID
HP HP Black
DELL Dell Black
A Sony/Panasonic/ Black
Fujitsu
B Toshiba Green
C Toshiba/Panasonic/ White
Acer
D IBM Blue
E Acer Yellow
G Toshiba Yellow
H Panasonic Red
K Lenovo Sony Yellow
#9509 Sold Apple MacBook Pro White
separately & MacBook Air
Aervoe Industries, Inc.
Gardnerville, NV 89410 • (800) 227-0196
www.aervoe.com • mailbox@aervoe.com
Sierra Wave is a registered trademark of Aervoe Industries, Inc.
9654inst CS:10/15
Dimensions
7.45 x 5 mm
7.45 x 5 mm
Multi-Volt
6 x 1 mm
Power Center
6.3 x 3 mm
5.5 x 2.5 mm
(13,200mAh/50Wh)
5.5 x 2.1 mm
5.5 x 1.7 mm

OPERATING INSTRUCTIONS

4 x 1.7 mm
3.5 x 1.3 mm
7.9 x 5.4 mm
Apple MagSafe 2 x
5.4mm. 36" cord.
