Page 1: Fast Ethernet Media Converter
EM210 series Fast Ethernet Media Converter Quick Installation Guide EM210 系列 快速以太网光電轉換器 快速安裝指南 Rev 1.0 2015 June... - Page 2 FCC Class A Certification This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 3: Installation
Installation This chapter gives step-by-step installation instructions for the Smart Media Converter. Selecting a Site for the Equipment As with any electric device, you should place the equipment where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference. Specifically, the site you select should meet the following requirements: 1. - Page 4 Installing in a Chassis The Converter can be fit into any of the expansion slots on a special designed chassis. Unscrew and pull out the media converter board First, install the converter onto a carrier supplied with the chassis: Step 1- Unscrew the carrier from the desired expansion slot on the chassis.
- Page 5 Through the optional Media Converter Chassis System via Management Module, you can control the setting of this Smart Media Converter. To set the Fiber and UTP (FDX/ HDX), UTP (Auto negotiation/ Manual), Speed (10M/100M), LLR (Enable/Disable), LLCF (Enable/ Disable) To enable or disable the connection of both UTP Device Link Setup port and Fiber port To enable or disable the LLCF function of the...
- Page 6 LED Indicator The LED indicators give you instant feedback on status of the converter: LEDs Status Indication Lights on Power on (Power) Power off 100M Lights on Runs at 100Mbps on TX port (100Mbps) Runs at 10Mbps on TX port Lights on Connection in full duplex mode Lights off...
- Page 7 安裝 本章節將介紹智能光电轉換器的安装。 選擇设备安装站点 设备安装地点要求： 1. 温度： 32 至 104 华氏度（ 0 至 40 攝氏度）。 2. 相對濕度：應小于 90 ％，非冷凝。 3. 周圍的电气设备不應該超過电磁場（ RFC ） IEC 801 3, Level 2 (3V/M) 的磁場强度標准 4. 确保设备足够的通风。不要堵塞在设备的側面或背面的排气口。 5. 电源插座應在相距 1.8 米以內。 接上電源 1. 該轉換器是即插即用设备。 2. 將 AC/DC （ 5V/1A ）电源适配器的直流插头連上轉換器并將 AC 插 头插上插座。...
- Page 8 管理光电轉換器 可選管理机箱，可以通過管理系统控制該智能光电轉換器，這个智能光 电轉換器可以通過 Web 瀏覽器， SNMP 管理实用程序和終端仿真程序來 控制。 管理模塊上能檢測 DIP 開關的默認复位，并能顯示出狀態；管理模塊也 可以通過管理系统控制 DIP 開關的功能。 通過光纤收发器模塊系统，可 以设置這种智能光纤收发器。 设置光纤和 UTP （ FDX/ HDX ） ， UTP （自动協商 / 手动），速 度（ 10M/100M ）， LLR （启用 / 禁用）， LLCF （启用 / 禁用） 启用或禁用 UTP 端口和光纤端口的連接 鏈接設置...
- Page 9 LED 指示燈 LED 指示灯即時反饋轉換器的工作狀態 : LED 指示灯 狀態 含义 燈亮 电源開启 PWR ( 电源 ) 燈滅 电源關閉 100M TX 端口以 100M 傳输 燈亮 (100Mbps) TX 端口以 10M 傳输 燈滅 燈亮 全雙工工作 燈滅 半雙工工作 閃爍 端口阻塞 燈亮 已经建立一个有效的网絡連接 LINK/ACT 燈滅 網路无連接 閃爍...
