- Page 1 EM220 series Gigabit Ethernet Media Converter Quick Installation Guide EM220 系列 千兆以太网光電轉換器 快速安裝指南 Rev 1.0 2015 June...
- Page 2 FCC Class A Certification This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 3: Installation
Installation This chapter gives step-by-step installation instructions for the Smart Media Converter. Selecting a Site for the Equipment As with any electric device, you should place the equipment where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference. Specifically, the site you select should meet the following requirements: 1. - Page 4 Installing in a Chassis The Converter can be fit into any of the expansion slots on a special designed chassis. Unscrew and pull out the media converter board First, install the converter onto a carrier supplied with the chassis: Step 1- Unscrew the carrier from the desired expansion slot on the chassis.
-
Page 5: Led Indicator
NOTE : To control the function in a working station, need to collocate together with optional Chassis System and Management Module. LED Indicator The LED indicators give you instant feedback on status of the converter: LINK/ACT EM220 Series EM220-SFP LEDs Status Indication... -
Page 6: Dip Switch
There is a two pin DIP switch on the module which define as switch 1 and switch 2: Fiber mode switch EM220 series in Switch1, EM220-SFP in Switch 2 When the switch was turned to “On”, it means that the fiber was turned to forced mode, and “Off” for auto-negotiation mode. - Page 7 安裝 本章節將介紹智能光電轉換器的安裝。 選擇设备安装站点 设备安装地点要求： 1. 温度： 32 至 104 华氏度（ 0 至 40 攝氏度）。 2. 相對濕度：應小于 90 ％，非冷凝。 3. 周圍的电子设备不應該超過电磁場（ RFC ） IEC 801 3, Level 2 (3V/M) 的磁場强度標准 4. 确保设备足够的通风。不要堵塞在设备的側面或背面的排气口。 5. 电源插座應在相距 1.8 米以內。 接上電源 1. 該轉換器是即插即用设备。 2. 將 AC/DC （ 5V/1A ）电源适配器的直流插头連上轉換器并將 AC 插 头插上插座。...
- Page 8 管理光电轉換器 可選管理机箱，可以通過管理系统控制該智能光电轉換器，這个智能光 电轉換器可以通過 Web 瀏覽器， SNMP 管理实用程序和終端仿真程序來 控制。 管理模塊上能檢測 DIP 開關的默認复位，并能顯示出狀態；管理模塊也 可以通過管理系统控制 DIP 開關的功能。 通過光纤收发器模塊系统， 可以设置這种智能光纤收发 器。 LLCF （启用 / 禁用） LED 指示燈 LED 指示灯即時反饋轉換器的工作狀態 : LINK/ACT EM220 系列 EM220-SFP LED 指示灯 狀態 含义 燈亮 电源開启 PWR ( 电源 ) 燈滅...
- Page 9 當開關打向 “ 開 ” 表明光纤设置成强迫模式開關打向 “ 關 ” 表明光纤设 置成自适應模式。 注意 : 确定相反端用同样的设置（强迫或者自适應）。當用 2 个轉換器時必須设置成 强迫模式。 LLR (Link Loss Return) EM220 series 開關 2 LLCF (Link Loss Carry Forward) EM220-SFP 開關 1 當開關打向 “ 開 ” 表明 LLR/LLCF 被開啟，開關是 “ 關 ” 表明 LLR/LLCF 被 關閉。...
- Page 10 SOARNEX Technology Corp. support@soarnex.com http://www.soarnex.com 29072466EM220*0...
