IC-232 Converter Operation Manual (Preventing thunder)
System Features
IC-232
1.
is a converter to change the RS232/RS485 data format. Can be used to
exchange the data format between PC and the controllers.
2.
USB port to get power, easy to be connected.
IC-232
3.
1 set of
same time.
Note: Do not use the same source of power supply for the
lock to avoid electrical sparkle interference.
Technical Specifications
Speed: 0-115200bps
Transmitting range: 1200m.
Support 1 to 127 nodes.
Power: 5-12AC/DC
Operating Current: 200mA (for one reader) / 250mA (for two readers)
Operating temperature: -50 ~ +70 .
Humidity: 5%~95%
Size: 63mm x 93mm x 20mm
3 LEDs to display the status.
Preventing thunder.
Keyking International Limited
Suite 3, 12/B Wissotzky St., Tel Aviv, 62338, Israel
Tel: (972)-3-5464256 Fax: (972)-3-5464259 Website:
IC-232 Converter Operation Manual (Preventing thunder)
IC-232
can be used to support 32 -128 sets of controllers to the network at the
and the electrical door
IC-232
www.key-king.com
Page 1
Advertisement
Table of Contents
Related Manuals for KEYKING IC-232
Summary of Contents for KEYKING IC-232
- Page 1 IC-232 Converter Operation Manual (Preventing thunder) IC-232 Converter Operation Manual (Preventing thunder) IC-232 System Features IC-232 is a converter to change the RS232/RS485 data format. Can be used to exchange the data format between PC and the controllers. USB port to get power, easy to be connected.
- Page 2 IC-232 Converter Operation Manual (Preventing thunder) Pin definitions Switch setting and baud rate regulation A) DIP 1-3: the switch 1, 2, 3 is used to set the baud rate, which to set based on the terminal that connecting with the converter (TC3x0 supports 9600bps only).
