The TekTouchPad is preconfigured for the replacement of the TEK 1201 Version 1 and 2 TekKeypads. To identify the
Tektouchpad a device number is shown in the bottom right corner of the Logo Page.
When the TekTouchPad has been idle for more than 30 minutes, the screen will go black. Touching the screen will first
display the LSCS Logo for 10 seconds unless it is pressed again where it will go to Page 1. Buttons will actually get
their feedback from the TEK 1201. Buttons that are on have brighter background colors.
Pressing the NEXT button displays Page 2. This page has the selection for the VCR. Use the PREV button to go back
to Page 1.
Logo Page
Supplied with the TekTouchPad and Wedge are the following:
1 TekTouchPad top assembly
1 TekTouchPad Subbase plate
1 80014 TekTouchPad Cable harness
1 12 volt AC wall adaptor
1 3.5mm Mono Phono Plug
2 4/40 Subbase mounting screws
Button Video Input Assignment
PC .............................................................................VGA 1
Laptop VGA ..............................................................VGA 2
Laptop HDMI .............................................................HDMI 2
Doc Camera ..............................................................HDMI 1
DVD ..........................................................................Component
VCR ..........................................................................Video 2 (Audio to VCR side)
Contact us for additional information or to find an Authorized TEKVOX Dealer in your area.
11831 Radium Street, San Antonio, TX 78216 | 210.348.6565 o | 713.490.3135 f | tekpatrol@TEKVOX.com | www.TEKVOX.com
TekTouchPad/TEK 1201 Upgrade
Page 1
Installation Guide
