TFortis PSW-2G4F Operation Manual

Multifunctional gigabit managed switch for ip- video surveillance systems, version 7
Hide thumbs Also See for PSW-2G4F:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Configuration Manual
Operation Manual
PSW-2G4F
PSW-2G4F-UPS
Multifunctional Gigabit Managed Switch for IP- video
surveillance systems
Version 7
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSW-2G4F and is the answer not in the manual?

Questions and answers

Related Manuals for TFortis PSW-2G4F

Summary of Contents for TFortis PSW-2G4F

  • Page 1 Operation Manual PSW-2G4F PSW-2G4F-UPS Multifunctional Gigabit Managed Switch for IP- video surveillance systems Version 7...
  • Page 2 • use of shielded twisted pair with shielded connectors RJ45; • minimization of twisted pair and power cable length; Modifications • PSW-2G4F • PSW-2G4F-UPS (with built-in uninterruptible power supply) Note. The text describes the PSW-2G4F, the distinctive features of the PSW-2G4F- UPS are specified separately.

  • Page 3: Table Of Contents

    6.1.1. Installation of the unit on the wall ..............26 6.1.2. Installation of the unit on the support ............. 26 6.1.3. Installation of the unit into TFortis-CrossBox cabinet ........27 6.2. Optic connection .................... 27 6.3. Power connection ..................27 6.4.

  • Page 4: Designation

    1. Designation Device PSW-2G4F is an Outdoor Multifunction Gigabit Managed Switch designed for networking of IP- video surveillance systems. Figure 1. Connection scheme for the PSW-2G4F Weatherproof version The body of the device is made of a techno-polymer that is resistant to Stringent Operating Conditions.
  • Page 5 PoE, the whole system is reserved for power. Resistance to the voltage 380V When 380V is applied, the switch PSW-2G4F-UPS will switch to the battery and keep the entire system working from the backup power source.

  • Page 6: Description

    2. Description 2.1. Appearance Figure 2.1-1. PSW-2G4F outside view Figure 2.1-2. PSW-2G4F inside view...
  • Page 7 Figure 2.1-3. PSW-2G4F-UPS outside view Figure 2.1-5. PSW-2G4F-UPS inside view...

  • Page 8: Element Arrangement

    2.2. Element arrangement Figure 2.2-1. Element arrangement of the PSW-2G4F During normal operation of the processor, a CPU indicator must light intermittently with a frequency of 2s. (1 sec. - on, 1 sec. - off.) DEFAULT Indicator is on, when the device is in factory settings (IP 192.168.0.1).
  • Page 9 Thermorelay Figure 2.2-2. Element arrangement of the PSW -2G4F-UPS...

  • Page 10: Power Supply Over Poe

    A and the second - mode B. Power is supplied to video cameras installed into TFortis TH camera housing using mode A and mode B simultaneously (I). When you connect other devices (not PoE), remove jumpers for relevant port (IV).
  • Page 11 Figure 2.3 Power supply scheme over PoE in different cases...

  • Page 12: 220V Power Supply Backup

    2.4. 220V power supply backup There are two power supply units in PSW-2G4F switch. Left PSU is designed to power the switch and the camera housing over PoE. Right PSU has two operation modes, which are selected by RES_PWR jumper according to 2.4 table.
  • Page 13 Degree of rigidity according to Voltage pulse value, kW the table 1 of standard GOST Port + 10% R 51317.4.5 Power lines of the switch “wire- wire” Power lines of the switch “wire- ground” Symmetrical communication lines 2/3* 1/2* of the switch “wire-ground” * - with installed board ESP-1 Table 2.6-2.

  • Page 14: Additional Functions

    WEB-interface in the section Special Function. Restart the video camera when there is no response to Ping. The PSW-2G4F switch constantly (1 time per minute) polls the IP camera. If the switch does not receive a response, then starts a one-minute timer, during which the poll is repeated every 10 seconds.

  • Page 15: Diagnostic Functions

    10 meters. See detailed information in 7.7.2. 3.8.2 Remote polling of video cameras With the PSW-2G4F it is possible to ping any device in the network via the WEB-interface, which is convenient when solving network problems. 3.9 Built in UPS (PSW-2G4F-UPS) 3.9.1...

  • Page 16: Description Of The Ups Operation

    Table 2.9 -Indicators of voltage control relay Indicator Description NORM Switch is powered by mains voltage ALARM Mains voltage is not supplied to the switch due to high or low voltage. ATTENTION! When the power is turned on, the ALARM indicator always lights up.
  • Page 17 batteries will go into the standby mode. In practice, at first, the whole system is assembled and only then, when everything is checked, the 220V power is supplied. Sometimes this process is stretched. If there is no delayed start mechanism, then after connecting the battery, the switch and video cameras will start working immediately.
  • Page 18 Table 2.9-2 - state indication of the uninterruptible power supply unit VBAT VOUT Description The switch is powered by the network, battery is present, voltage at the battery is normal. The switch is powered by the network, battery failure (battery is not connected, polarity is not correct or terminals are closed) The switch is powered by the battery (voltage at the battery is higher than 46V), mains voltage is...

  • Page 19: Estimating The Time Of Uninterrupted Operation

    As a rule, cameras without heating consume from 3W to 5W. The main power is consumed by the camera housing. Please note that the TFortis PSW-2G4F- UPS switch turns off the power of the camera housing when switching to the battery.

  • Page 20: Battery Installation

    capacity testers). It is recommended to evaluate the battery condition once a year. Using a battery with a small residual capacity reduces the time of uninterrupted operation of the switch. The switch battery operates in a buffer mode. The service life of the batteries supplied in this kit (if included) is 5 years under normal conditions.

  • Page 21: Monitoring The Fan Operation

    3.9.6 Monitoring the fan operation Fans are installed into PSW-2G4F-UPS unit. They are switching on only at high temperature inside the unit. To check the serviceability of the fan control circuits, it is necessary to apply 220V to the switch and press the control button (figure 2.9.6).

  • Page 22: Technical Parameters

    – ~ 220V (from 187V to 246V); • Max power consumption (for more details see section 8.1) - for PSW-2G4F not more than 120W. - for PSW-2G4F-UPS not more than 190W. • battery characteristics (if included) of the PSW-2G4F-UPS - Rated voltage 12V;...

  • Page 23: Operation Conditions

    5. Operation conditions The switch PSW-2G4F is intended for 24-hour outside operation at ambient temperature according to the table 4 using industrial SFP modules. Table 4. Operation temperature range Switch type Operation temperature range -55 .. +65 °C* (-67 .. +149 F)* PSW-2G4F -45 ..

  • Page 24: Restore Switch To Factory Settings

    PSW-2G4F using the HTTP protocol. Connect any port on the PSW-2G4F to an Ethernet network. Keep in mind that if the device is configured over a network, then the IP address of the management workstation must belong to the same IP network.

  • Page 25: Configuring Poe On Ports

    Special Function tab in the Comfort Start section and enable the option. By default, it is disabled. This function is available only with camera housings TFortis TH. IMPORTANT! When this option is enabled, after the power is applied to the switch, the cameras will only turn on after time of Soft Start Time.

  • Page 26: Device Installation

    There are two power supply units in PSW-2G4F switch. Left PSU is designed to power the switch and the camera housing over PoE. Right PSU has two operation modes. If the 200V power supply backup is needed, place the RES_PWR jumper in YES position.

  • Page 27: Installation Of The Unit Into Tfortis-Crossbox Cabinet

    Switches TFortis PSW-2G4F are made from techno-polymer with IP66 protection rating in a hermetic casing. This is quite enough to install devices in the open air. However, it is recommended to place PSW-2G4F switches into the cabinet because they can accommodate additional equipment (Optical Distribution Frame, Circuit Breakers and other user equipment).

  • Page 28: Optic Connection

    It is recommended to use External Optical Distribution Frames. 6.3. Power connection The PSW-2G4F is connected to an AC source of 220V. The supply cable is brought into the unit through the cable gland, where it is connected to the terminal block of the power supply unit (Figure 6.3-1).
  • Page 29 Figure 6.3-1. Power connection to the PSW-2G4F. Please note that there are two power supply units in PSW-2G4F. Left PSU is designed to power the switch and cameras. Right PSU is designed either to power TFortis TH camera housings or to left PSU backup. The operating mode depends on the RES_PWR jumper (see 2.4 section).
  • Page 30 Figure 6.3-2. Power connection to the PSW-2G4F-UPS. IMPORTANT! Grounding of the device is required. The ground resistance must be no more than 4 ohms. IMPORTANT! Do not allow printed circuit boards touching high voltage live wires. Failure in this case entails a loss of warranty.

  • Page 31: Connection Of Video Cameras

    To the ports 1 to 4, connect cameras using a twisted pair. It is recommended to use a 4-pair shielded cable no worse than Category 5. The PSW-2G4F switch allows you to connect PoE video cameras with one cable, which drastically reduces the complexity of system installation.

  • Page 32: Appendix

    8. Appendix 8.1 Calculation of the power consumption The consumption of the TFortis PSW switch is calculated by the formula: + ∑ (�� �� + �� + �� ���� ������ ���� ���� �� = �� For the PSW-2G4F, the power consumption of the commutator board is not more than 5W.
  • Page 33 Example It is required to calculate the power consumption of the TFortis PSW-2G4F switch when 3 AV1310 cameras in TFortis TH-02 camera housings are connected to it.
