  • Page 1 3G GPS Vehicle Tracker User Manual PL630 iPhone App Download QR Code Android App Download QR Code...

  • Page 2: Packing List

    Packing list GPS Tracker LED Indicator OBD Interface SIM Card Holder Specification  OBD interface, DIY no installation;   Diagnostic Car Status(reply by SMS);   Auto download & config APN & GPRS setting;   Listen sound around tracker; ...
  • Page 3 Press the yellow switch button beside the tracker with a tool, the SIM card holder will come out. Pull it out and put the SIM card in the holder and then push the holder into the tracker again is OK (Pay attention to that the SIM card metal contact pin can not face down to the holder).

  • Page 4: How To Install

    IP/APN/GPRS name & password/TIMEZONE are changed, and you need set these again by sending SMS. How to Install 1. First to buy a 2G GSM or 3G WCDMA mobile phone SIM card, which needs SMS service and incoming caller ID display and GPRS function, and please disable the PIN code of the SIM card, this SIM card phone number is the tracker number and all the operations (calling and sending SMS) to the tracker is this number.
  • Page 5 the GPRS & APN setting, if the APN or GPRS user name & password are not right, you can set APN and GPRS username & password sending SMS, you can check the APN & GPRS username password by sending SMS “CHECK*123456” to tracker, Sending SMS “APN*123456*apnname” to the tracker can set the APN, and sending SMS “USERNAME*123456*username*password”...
  • Page 6 telephone number you want preset, the following is same) to tracker is OK, “ADDPHONE” is a command; “123456” is password; “A” is authorized number location, every tracker have 3 authorized phone number locations, A and B, and C, so you can set 3 phone numbers, if the add operation is success, the tracker will send back the information ”Add Preset Phone OK”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”.
  • Page 7 sending information to platform when the alarm is triggered. 4. Alarm Notice by SMS ON/OFF: Send SMS “SMSON*123456” to tracker, in which, “SMSON” is the fixed command and “123456”is the password. Having successfully been made, there will be a reply sms to indicate the alarm will be noticed by sending a sms.
  • Page 8 time, which can be set from 30 to 999 seconds. The tracker will send back information “Set Interval xxx OK”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”. 30 seconds is the default interval time. Longer upload interval time can save battery and GPRS data cost, but this will make the total mileage to more error.
  • Page 9 Notice: The tracker IP address has been set to default : 58.64.155.133,8011 in factory, it is not necessary to set again, unless our IP address has been changed or user need upload the location to other server, If our server IP is changed, we will notice on the website. 11.

  • Page 10: Locate Operation

    CMNET, ;APN name User, ;GPRS user name Password, ;GPRS password 46000, ;Sim Card MCC+MNC e1d/24a0, ;Current Cell ID Battery:88% ;Battery Note: This command usually be used to check the tracker current status & configuration, if the tracker can not work well, this command can check what the problem is. 13.
  • Page 11 The SMS information sample is as follow: 2. Sending SMS to trigger report location by text description Send SMS “LOCATE*123456” to the tracker, “LOCATE” is a command, “123456” is password. If the operation is success, the tracker will send back the information as above. If the authorized number have been set, use the authorized phone number to send SMS “123#”...
  • Page 12 base station), and reply a location with Google map link to the caller or sender. User click the link, the location in google map will display like above, the SMS example is as follow: No GPS signal, Just Cell ID Location: http://maps.google.com/maps?q=+22.6775,+114.1518 Note: this location is locate by GSM base station ID, the precision is not very high, in the city maybe 30-50 meters, in the country mabe over 1 km, so the location is only used for reference.
  • Page 13 Shock alarm notice by sending SMS & calling can be enabled ON or OFF, please refer Tracker Setting Command 3 &4. 6. Set Over Speed Alarm by Sending SMS Send SMS “OVERSPEEDALARMON*123456*xxx” (Enable over speed alarm xxx km/h) or “OVERSPEEDALARMOFF*123456” (Disable over speed alarm) to the tracker, “OVERSPEEDALARMON” or “OVERSPEEDALARMOFF”...

  • Page 14: Platform Operation

    8. Check Alarm Setting Send SMS “ALARM*123456” to the tracker number, “ALARM” is command, “123456” is password, the tracker will send back the information of the alarm setting, for example: Shock Alarm:OFF,Geo-Fence Alarm:OFF,Over Speed Alarm:OFF,Power Down Alarm: ON, Calling:ON,SMS:ON, Battery:88%. 9.

  • Page 15: Troubleshooting

    or 3G WCDMA network, then this kind of 4G SIM card can be used in this tracker. The antenna of GSM and GPS is built in tracker, please note that the install location of the tracker must can receive the GPS signal, if the OBD socket place can not receive GPS, please add an external OBD wires to install the tracker to other place.
  • Page 16 Working Voltage 7-36V DC GSM Frequency 850/900/1800/1900Mhz (global band) GSM/WCDMA Chip set Inter (USA) WCDMA Frequency 850(800)/900/1900/2100 (global band ) GPS Chip Set Antenna Built in Locate Precision 5-10 Meters Recharging Current 5V/300-500mA Standby Current < 3 mA 5V DC Locating Current <...
