Blaupunkt Miami 100 USB 24V Operating And Installation Instructions

Safety notes

www.blaupunkt.com
The car sound system was manufactured according to the state of the art and
established safety guidelines. Even so, dangers may occur if you do not observe
Radio CD MP3 WMA USB
the safety notes in these instructions.
These instructions contain important information to easily and safely install and operate
the car sound system.
• Read these instructions carefully and completely before using the car sound system.
• Keep the instructions at a location so that they are always accessible to all users.
• Always pass on the car sound system to third parties together with these instructions.
In addition, observe the instructions of the devices used in conjunction with this car sound
system.

Road safety

Observe the following notes about road safety:
• For the front AUX-IN socket, use only the angled jack plug from Blaupunkt (7 607 001 535).
24V
Miami 100 USB
All protruding parts, incl. straight plugs or adapters, can lead to an increased injury risk in
case of an accident.
• Use your device in such a way that you can always safely control your vehicle. In
case of doubt, stop at a suitable location and operate your device while the vehicle is
standing.
• Always listen at a moderate volume to protect your hearing and to be able to hear
acoustic warning signals (e.g. police sirens).

General safety notes

Observe the following notes to protect yourself against injuries:
• Do not modify or open the device. The device contains a Class 1 laser that can cause
injuries to your eyes.
Use as directed
This car sound system is intended for installation and operation in a vehicle with 24 V
vehicle system voltage and must be installed in a DIN slot. Observe the performance lim-
its in the technical data. Repairs and installation, if necessary, should be performed by a
specialist.
Installation instructions
You may only install the car sound system yourself if you are experienced in installing car
sound systems and are very familiar with the electrical system of the vehicle. For this pur-
pose, observe the installation instructions overleaf.
Operating and installation instructions
Declaration of conformity
The Blaupunkt AudioVision GmbH declares that the car sound system Miami 100 com-
plies with the basic requirements and the other relevant regulations of the directive
89/336/EEC.

General functions

Function Action
•
Switch device on. Press the ON/OFF button briefl y.
•
Switch device off . Press the ON/OFF button for more than 2 seconds.
•
Adjust the volume (levels 0 – 50) Turn the ON/OFF button.
•
Mute the device or return to the previous volume level. Press the ON/OFF button briefl y.
When the device is muted, "MUTE" is displayed.
•
Select audio source FM1/FM2 1 /FMT 1 /MW 1 /LW 1 /AM 1 /AMT 1 /CD 2 /USB 2 /FRONT AUX 2 . Press the SRC button once or repeatedly.
•
Adjust display brightness for day or night. 3 Enter the System Menu, adjust the Dim Day and Dim Night parameter.
•
Cancel a traffi c announcement. 4 Press DISP button briefl y.
Insert CD. Note
You must not hinder or assist the drive as it automatically draws in the CD.
Risk of severe damage to the CD drive!
•
Noncircular contoured CDs (shape CDs) and CDs with a diameter of 8 cm (mini
Gently insert the CD with its printed side uppermost into the drive until you feel some
CDs) must not be used.
resistance and the CD is drawn in automatically.
•
Remove CD. Press the button.
Note
If a CD is ejected and not removed, the drive will automatically draw it back in again
after approx. 10 seconds.
•
Connect external audio source. Insert the jack plug of the external device into the front AUX IN socket.
Danger! Increased risk of injury from connector.
In case of an accident, the protruding connector in the front AUX-IN socket may
cause injuries. The use of straight plugs or adapters leads to an increased risk of
injury. For this reason, we recommend using angled jack plugs.
•
Connect/disconnect USB stick. Switch off the car sound system so that the data carrier will be correctly registered
and unregistered.
Note
•
The supplied USB cable must be connected to the USB socket on the rear of the unit (see Connect the USB stick to the USB cable or pull the USB stick off .
section "Installation" overleaf ).
1 Only if the memory bank is switched on (BAND submenu in the TUNER menu, see section "Menu settings" overleaf ).
MW, LW, AM or AMT are only available in respective tuner regions.
2 Only if CD is inserted or USB stick is connected or external audio source is connected.
3 If Dimmer line is not connected, default brightness is always set to Dim Day Value.
4 Only if priority for traffi c announcement is switched on (TRAF setting in the TUNER menu, see section "Menu settings" overleaf ).
Cleaning notes Front view of the car sound system
Solvents, cleaning and scouring agents as well as dashboard spray and plastics care prod-
ON/OFF button
uct may contain ingredients that will damage the surface of the car sound system. Use
only a dry or slightly moistened cloth for cleaning the car sound system.
Disposal notes
Do not dispose of your old unit in the household trash!
Use the return and collection systems available to dispose of the old device.

Scope of delivery

The scope of delivery includes:
1 Car sound system
1 Operating/installation instructions
1 Support frame
1 Set of small parts

Features

2 Disassembly tools

RDS tuner

For Miami 100 USB 24V only: This car sound system is equipped with an RDS tuner that supports features such as dis-
1 USB connecting cable play of station names, alternative frequencies, REG (regional programmes), and priority
for traffi c announcements.
Extended scope of delivery (not included in Europe devices):
1 Connecting cable chamber A (power supply)

Audio media

1 Connecting cable chamber B (loudspeaker) This car sound system can play audio CDs (CDDA) as well as MP3 and WMA fi les from CD-R,
CD-RW and USB sticks.
1 Connecting cable chamber C1 (Line-Out)
1 Antenna connection adapter

External audio sources

You can connect external audio sources such as MP3 players or portable CD players to this
Note:
car sound system via the front AUX IN socket.
We recommend the use of original Blaupunkt accessories (www.blaupunkt.com).
Telephone Mute
If a telephone is connected to this car sound system (mute signal of the telephone to
chamber A, pin 2 on the rear of the unit; see section "Installation instructions" overleaf ),
the system is muted automatically when the telephone receives a call. For the period of
the call, "TELEPHONE" is displayed.
1 RDS features are only available in FM waveband. They are not supported in some countries.

Functions in radio mode

Function Action
•
Change frequency stepwise. Press the / button briefl y.
•
Change frequency continuously. Press and hold down the / button.
•
Start automatic station seek tuning. Press the
•
Stop automatic station seek tuning at current frequency. Press the /
•
Store station on the current memory bank. Press a station button 1 – 5 for more than 2 seconds.
•
Store stations automatically on memory bank FMT or AMT 1 . Select the FM or AM
•
Press the SRC button for more than 2 seconds.
•
Play stored station of the current memory bank. Press a station button 1 – 5 briefl y.
•
Scan receivable stations. 2 Press the MENU button for more than 2 seconds.
•
Cancel scanning at current station. Press the MENU button briefl y or any station button 1-5 briefly.
•
Select display mode (display of frequency or, if available, station name). Press the DISP button briefl y.
1 Only in tuner regions USA, S AMERICA and THAI.
2 Each station is played according the menu scan time setting duration (in second).
Notes concerning MP3/WMA fi les and data carriers
Note the following information when preparing an MP3/WMA data carrier:
CD slot Display Front AUX IN socket
• Naming of tracks and directories:
– Max. 16 characters (CD) or 24 characters (USB) incl. the fi le extension ".mp3" or
".wma" (if more characters are used, the number of tracks and folders that are rec-
ognisable by the car sound system is reduced)
– No special characters
• CD formats: Audio CD (CDDA), CD-R/RW, Ø: 12 cm
• CD data formats: ISO 9669 Level 1 and 2, Joliet
• CD burn speed: Max. 16x (recommended)
• USB devices: USB sticks only (no USB hard disks)
• USB format/fi le system: Mass storage device/FAT16, FAT32
• File extension of audio fi les:
– .MP3 for MP3 fi les
– .WMA for WMA fi les
• WMA fi les only without Digital Rights Management (DRM) and created with Windows
Media Player version 8 or later
1
• MP3 ID3 tags: Version 1 and 2
• Bit rate for creating audio fi les:
– MP3: 32 to 320 kbps
– WMA: 32 to 192 kbps
• Max. number of tracks for USB: 27,000

Functions in CD mode (CDDA/MP3/WMA) and USB mode (MP3/WMA)

Function
Select previous/next track.
Select previous/next folder .
/ button briefl y. Fast search backwards/forwards.
Pause or resume playback.
button briefl y.
Select Repeat option:
Repeat current track:
1 waveband.
Repeat current folder : 1
Resume normal playback:
Select Mix option:
Mix current folder : 1
Mix all tracks on CD:
Resume normal playback:
Scan all tracks on CD . 2
Cancel scanning at current track.
Select display mode:
CDDA: CD text (if available)
Track number and elapsed time
MP3/WMA: Filename
Artist (if available)
Album (if available)
Directory (if available)
Elapsed time
1 MP3/WMA only.
2 Each track is played according the menu scan time setting duration (in second).
8 649 041 225
Blaupunkt Malaysia Sdn. Bhd.
Free Industrial Zone 1
11900 Bayan Lepas
Penang Malaysia
http://www.blaupunkt.com
Action
•
Press the / button briefl y.
•
1 Press the / button briefl y.
•
Press and hold down the / button.
•
Press the 3 button.
•
Press the 4 RPT button once or repeatedly.
'RPT TRK'
'RPT DIR'
'RPT OFF'
•
Press the 5 MIX button once or repeatedly.
'MIX DIR'
'MIX ALL'
'MIX OFF'
•
Press the MENU button for more than 2 seconds.
•
Press the MENU button.
•
Press the DISP button once or repeatedly.
(GB) 08/09
