Mopec 5000 User Manual

Autopsy saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
www.mopec.com
(800) 362-8491
info@mopec.com
MOPEC 5000
User Manual
INSTRUCTIONS FOR YOUR SAFETY
Please read carefully and retain for future reference. It is a requirement
of IEC/EN 60601-1 that these instructions are made available to the
operator and qualified maintenance staff at all times.
The Mopec 5000 System has been examined
and found to be in compliance with the
standard for Medical Electrical Equipment IEC/
EN60601-1
AUTOPSY SAW
TM
O
Clamp
the
the
not to
the Captive Blade

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5000 and is the answer not in the manual?

Questions and answers

Related Manuals for Mopec 5000

Summary of Contents for Mopec 5000

  • Page 1 Please read carefully and retain for future reference. It is a requirement of IEC/EN 60601-1 that these instructions are made available to the operator and qualified maintenance staff at all times. The Mopec 5000 System has been examined the Captive Blade Clamp...
  • Page 2 CONTENTS +44 ( 0 ) 114 257 6002 Medezine Limited F +44 ( 0 ) 114 257 6222 Churchill Way Chapeltown Sheffield England E sales@medezinesaws.c S35 2PY W www.medezinesaws.com 2002/289...

  • Page 3: Equipment Classification

    EQUIPMENT CLASSIFICATION Type B Equipment - Protection against electrical shock Saw Unit Watertight Equipment IP67 Power Supply Splash Proof Equipment IP65 Mode of Operation:- Continuous with Intermittent Loading up to 3 mins. Duty Cycle 50% +44 ( 0 ) 114 257 6002 Medezine Limited F +44 ( 0 ) 114 257 6222 Churchill Way Chapeltown...
  • Page 4 +44 ( 0 ) 114 257 6002 Medezine Limited F +44 ( 0 ) 114 257 6222 Churchill Way Chapeltown Sheffield England E sales@medezinesaws.c of the Captive Blade Clamp S35 2PY W www.medezinesaws.co not to 2002/289...

  • Page 5: General Description

    GENERAL DESCRIPTION The M 5000 Oscillating Saw has been developed to help minimize the risk of cross infection in sensitive areas, providing it is used in accordance with the manufacturer’s instructions. The complete system comprises three basic units. THE SAW UNIT This unit is fed from the power supply.
  • Page 6 5000 SAW UNIT Captive Blade Clamp Square Drive +44 ( 0 ) 114 257 6002 Medezine Limited F +44 ( 0 ) 114 257 6222 Churchill Way Chapeltown Sheffield England On/Off (I/O) E sales@medezinesaws.c Momentary Button S35 2PY W www.medezinesaws.co...
  • Page 7 Status Indicator Filtration Unit Output energized when lit. Status Indicator Status Indicator Saw Unit Output Saw Unit overload detected energized when lit. when flashing. Complete system will shut down. Then Auto-reset to “System off” status in approx. 20 seconds. +44 ( 0 ) 114 257 6002 Medezine Limited F +44 ( 0 ) 114 257 6222 Churchill Way Chapeltown...
  • Page 8 Handle Vacuum Hose Hose/Filtration Unit Connector Vacuum Filtration Unit Cowelling Top Cover Hose/Cowling Connector Toggle Clamp Saw Unit Supply Lead Saw Unit ON/OFF Button Full System Cable Clip Status Indicator lights Filtration Unit Powe +44 ( 0 ) 114 257 6002 Medezine Limited F +44 ( 0 ) 114 257 6222 Churchill Way Chapeltown...

  • Page 9: Blade Replacement

    FITTING OF ACCESSORIES AND DETACHABLE PARTS BLADE REPLACEMENT Untighten the Captive Blade Clamp with Allen wrench provided and remove. Replace or index blade as required, ensuring it is seated properly on the square drive shaft. If not discard, or resulting damage or inefficiency of the saw could result. the Captive Blade Clamp with Allen wrench overtighten, as this will cause the blade to seat improperly and prevent the saw from operating properly.

  • Page 10: Fuse Replacement

    FUSE REPLACEMENT ISOLATE FROM ELECTRICAL SUPPLY BEFORE REMOVING COVER The third fuse is an anti surge fuse. Fuse type and ratings are marked adjacent to the fuse holders or alternatively see page 14. Undo the four captive retaining screws to remove the cover. Prior to replacement ensure that the rubber seal set into the underside cover has not been disturbed.

  • Page 11: Troubleshooting

    TROUBLESHOOTING The information contained in this section covers common problems and suggests solutions. If your system’s problem is not covered here, or you still need help, please contact the agent/manufacturer. Note. Disconnect equipment from the electrical supply before attempting to implement any solutions of an electrical nature Symptom Possible Cause Solution...
  • Page 12 TROUBLESHOOTING- continued Symptom Possible Cause Solution Check the power supply connection Saw unit status Faulty connection. indicator lit but not is properly engaged. running although filtration unit does. Defective motor. Contact manufacturer. blade. Excessive noise from Distorted blade. saw unit. Check blade is fitted in accordance Badly fitting or loose blade.

  • Page 13: Disinfection And Sterilization

    CUTTING HINTS The M 5000 oscillating saw has been designed and constructed to provide effortless and highly efficient cutting in its appropriate areas of usage. We suggest a trial cutting period applying the least pressure possible to the workpiece until fully accustomed with the efficiency.
  • Page 14 ACCESSORIES AND DETACHABLE PARTS Order Code Description Bone 240V Dust Collector Filter Service Kit Segmented Circular 2.5" Segmented 3" Circular Blade Nut Driver Depth Gauge 64mm Depth Gauge 76mm Vacuum Hoods (10Pack) Vacuum Pipe with QR Fittings Captive Blade Clamp Kit Inc Allen Wrench +44 ( 0 ) 114 257 6002 Medezine Limited F +44 ( 0 ) 114 257 6222...
  • Page 15 5000 SCHEMATIC WIRING +44 ( 0 ) 114 257 6002 Medezine Limited F +44 ( 0 ) 114 257 6222 Churchill Way Chapeltown Sheffield England E sales@medezinesaws.c S35 2PY W www.medezinesaws.co 2002/289...
  • Page 16 FILTER SERVICE RECORD This page is provided to document your filter service history to meet the requirements of the C.O.S.H.H. legislation. Although the complete filter service kit includes Vacuum Cowellings and Paper Filters, provision for these are not included in the service record as they are regarded more consistent with the day to day servicing of the equipment.

  • Page 17: Conditions Of Warranty

    Sheffield England E sales@medezinesaws.c S35 2PY W www.medezinesaws.co EQUIPMENT RATINGS Equipment Serial No. Supply Voltage Auxiliary Socket Output 2002/289 5000 Power Supply V-50/60HZ 75VA V-50/60HZ 750 W 5000 Saw Unit Not Applicable 5000 Filtration Unit V-50/60HZ 750 W Not Applicable...

  • Page 18: Technical Information

    Weight – 1.3kg Churchill Way Chapeltown F +44 Sheffield England E sale S35 2PY W ww Technical Requirements 93/42/EEC IEC/EN 60601-1 EMC 2004/108/EC 2002/289 21750 Coolidge Hwy. T +1 248-291-2040 Oak Park, Michigan 48237 F +1 248-291-2050 E Info@Mopec.com W www.mopec.com...
