Dome WR01Z Manual

On/Off Plug-In Switch
Thank you for purchasing the DOME
On/Off Plug-In Switch, which works with your
Z-Wave Certified Controller to turn on and off
any plugged in electronic device and monitor its
power consumption.
DEVICE PORT
PLUG
Connect Button
Including/Connecting into the Z-Wave Network:
Follow the instructions for your Z-Wave certified Controller
to enter inclusion mode.
When prompted by the Controller:
1. For proper inclusion, bring the On/Off Plug-In Switch
to within 10 feet of your Controller and plug it in. After
inclusion, the device can be moved to any desired
location.
2. Press the Connect Button quickly 3 times in a row.
The LED Indicator will flash five times indicating inclusion.
Excluding/Disconnecting from the Z-Wave Network:
Follow the instructions for your Z-Wave certified Controller to
enter exclusion mode.When prompted by the Controller:
1. Plug in the On/Off Plug-In Switch within range of your
Z-Wave Controller.
2. Press the Connect Button quickly 3 times in a row.
The LED Indicator will flash five times indicating exclusion/dis-
connection.
Resetting the On/Off Plug-In Switch to Factory Default
Settings:
To disconnect from the Z-Wave Network and restore factory default
settings:
1. Plug in the On/Off Plug-In Switch.
2. Hold the Connect Button for 10 seconds until the LED Indicator
blinks once, then release the button.
Only do this if the controller is disconnected or otherwise unreach-
able!
Overload Protection:
The On/Off Plug-In Switch shuts off power and the LED Indicator
will turn red when a current higher than 13 Amps passes through.
To restore power after a current overload, power cycle the plug
either by pressing the physical button or through your Z-Wave
controller. You can also reboot the plug by unplugging it from the
outlet.
