Sony HT-CT390 Startup Manual

Sound Bar
Startup Guide
HT-CT390
Bar Speaker
Subwoofer
1
Connecting with a TV
Is the HDMI input jack on your TV labeled "ARC" ?
NO
Optical digital cable (supplied)
High Speed
HDMI cable (not
supplied)
Note
Make sure that the HDMI cable is firmly inserted.
2
Setting up the remote control
3
Turning on the TV
Change the input of the TV to the input which the Bar Speaker is connected.
Supplied accessories
4-586-112-71(1)
Remote control (1) R03 (size AAA) batteries (2)
Wall mounting brackets (2) Speaker pads for the subwoofer (4)
and screws (2) Refer to the supplied Operating Instructions on
installing the subwoofer horizontally.
To mount the Bar Speaker on a wall
Refer to the supplied Operating Instructions.
YES
High Speed HDMI cable (not supplied)
Power
Input
4
Turning on the system
Optical digital cable (1)

Connect the AC power cords (mains leads).
 Press  (power).
The top panel display lights up.
When the power indicator of the subwoofer turns green, wireless connection of Bar Speaker and subwoofer is completed. If it does not turn on, the wireless transmission is not activated.
Refer to "No sound is heard from the subwoofer." of "Troubleshooting" in the supplied Operating Instructions.
5
Listening to the sound
Press INPUT repeatedly until the device you want appears in the top panel display. Then, press
repeatedly to adjust the volume of the subwoofer.
Setup completed! Enjoy!
Listening to music from a BLUETOOTH device
When pairing a BLUETOOTH device
To pair the system with a BLUETOOTH device (Pairing)

Place the BLUETOOTH device within 1 meter from the Bar Speaker.
 Press PAIRING on the Bar Speaker.
The blue LED indicator on the Bar Speaker flashes quickly (
 Turn on the BLUETOOTH function, and then select "HT-CT390" after searching for it on the BLUETOOTH device.
Perform this step within 5 minutes, otherwise pairing mode may be canceled. When the BLUETOOTH connection is established, the blue LED indicator lights up ( ).
If passkey is required on the BLUETOOTH device, enter "0000".
To listen to music from the paired device

Turn the BLUETOOTH function of the paired device to on.
 Press INPUT repeatedly to select "BT".
The system automatically reconnects to the BLUETOOTH device it was most recently connected to. When the BLUETOOTH connection is established, the blue LED indicator lights up ( ).
 Start playback on the BLUETOOTH device.
 Adjust the volume.
When using One-touch connection (NFC)

Hold the remote device near to the N-Mark on the Bar Speaker until the remote device vibrates.
When the BLUETOOTH connection is established, the blue LED indicator on the Bar Speaker lights up ( ).

Start playback of audio source on the remote device.
• Compatible remote devices
Remote devices with a built-in NFC function
(OS: Android™ 2.3.3 or later, excluding Android 3.x)
SongPal
A dedicated App for this model is available on both Google Play™ and App Store.
Search for "SongPal" and download the free App to find out more about the convenient features.


+/– repeatedly to adjust the volume of the system and press SW
Please refer to the supplied Operating Instructions about the sound
mode, and other functions.
INPUT PAIRING
Blue LED indicator
) during BLUETOOTH pairing.
Blue LED indicator
INPUT

+/–

SW +/–

+/–
Operating Instructions
BLUETOOTH device
© 2016 Sony Corporation Printed in Malaysia
