Galaxy Audio CM-170 Quick Start Manual

GAL A X Y AUDIO
Included Components
1. CM-170 x1 1.
2. Windscreen
3. Software CD x1
4.
USB/MicroUSB Cable x1
5.
Carry Case
6. Quick Start Guide x1
Setup
1
Open the battery cover and insert four
AAA batteries.
4
Min/Max: Press this to enter max/min
recording mode. Pressing once will
display the maximum reading, pressing
again will display the minimum reading.
Press & hold to exit Min/Max mode.
9
Date/Time: There is an on board clock
to record the time along with data during
logging. Enter set mode by turning off
the meter, then press and hold the A/C
button and press the Power button.
2. 3.
2
After inserting four AAA batteries, press
the Power button to turn on the screen.
Battery indicator will show battery
strength. Press and hold Power button
to turn off.
5
Logging: Pressing the Rec button starts
the logging feature, pressing again
stops logging. The data can be retrieved
using the included software.
10
Set: Press Clock (MIN/MAX). The
display will show:
year-month-day-hour-minute-second,
in the 24 hour clock format.
4. 5.
Operation
1
A/C Weighting: Pressing the A/C button
toggles between (A) and (C) weighting:
Use (A) weighting for general noise.
Use (C) weighting for high level sounds
with a lot of bass content.
6
Logging Interval: Can be set in 1 sec
increments from 1 sec to 1 min. While
turned off, press and hold the A/C button
and power on the meter. Press the INTV
(Fast/Slow) button.
11
Date: Press Up/Down to adjust the year.
Press Clock again. Press Up/Down to
adjust the month. Press Clock again.
Press Up/Down to adjust the day.
6.
GAL A X Y AUDIO
Quick Start Guide
Included Components What May be Needed
(Not Included)
1. CM-170 x1 1. 2. 3. 4. 5. 6.
2. Windscreen
3. Software CD x1 1. 4x "AAA" Batteries
4. USB/MicroUSB Cable x1
5. Carry Case
6. Quick Start Guide x1
1.
Setup Operation
1 2 1 2 3
Open the battery cover and insert four After inserting four AAA batteries, press A/C Weighting: Pressing the A/C button Fast/Slow: Pressing the Fast/Slow Level: Press the Level button to select
AAA batteries. the Power button to turn on the screen. toggles between (a) and (c) weighting: button to select the integration time. Use the measurement range, if it is too low
Battery indicator will show battery Use (a) weighting for general noise. Slow to get average levels, use Fast to or too high a warning will flash at the top
strength. Press and hold Power button Use (c) weighting for high level sounds get peak levels. of the meter, press the button again to
to turn off. with a lot of bass content. move to a suitable range.
4 5 6 7 8
Min/Max: Press this to enter max/min Logging: Pressing the Rec button starts Logging Interval: Can be set in 1 sec The display will show the interval in Clearing Stored: Power the meter off.
recording mode. Pressing once will the logging feature, pressing again increments from 1 sec to 1 min. While hr:min:sec. Use the up(Rec) and down Press and hold the Rec button, then
display the maximum reading, pressing stops logging. The data can be retrieved turned off, press and hold the A/C button (Level) buttons to change the interval. press and also hold the Power button for
again will display the minimum reading. using the included software. and power on the meter. Press the INTV Press the INTV again to set. at least 5 secs. The display will show a
Press & hold to exit Min/Max mode. (Fast/Slow) button. ' ' countdown, and then display ' '.
9 10 11 12 13
Date/Time: There is an on board clock Set: Press Clock (MIN/MAX). The Date: Press Up/Down to adjust the year. Time: Press Clock, then press Up/Down The CM170 can be stand mounted on a
to record the time along with data during display will show: Press Clock again. Press Up/Down to to adjust the hour (in 24 hour format). standard camera tripod for long term
logging. Enter set mode by turning off year-month-day-hour-minute-second, adjust the month. Press Clock again. Press Clock again. Press Up/Down to measuring. There is a threaded insert
the meter, then press and hold the A/C in the 24 hour clock format. Press Up/Down to adjust the day. adjust the minute. Press Clock again. on the rear of the CM170 for this.
button and press the Power button. Press Up/Down to adjust the second.
Press Clock to exit setup.
2
Fast/Slow: Press the Fast/Slow
button to select the integration time. Use
Slow to get average levels, use Fast to
get peak levels.
7
The display will show the interval in
hr:min:sec. Use the up(Rec) and down
(Level) buttons to change the interval.
Press the INTV again to set.
12
Time: Press Clock, then press Up/Down
to adjust the hour (in 24 hour format).
Press Clock again. Press Up/Down to
adjust the minute. Press Clock again.
Press Up/Down to adjust the second.
Press Clock to exit setup.
Quick Start Guide
What May be Needed
(Not Included)
1. 4x "AAA" Batteries
1.
3
Level: Press the Level button to select
the measurement range, if it is too low
or too high a warning will flash at the top
of the meter, press the button again to
move to a suitable range.
8
Clearing Stored: Power the meter off.
Press and hold the Rec button, then
press and also hold the Power button for
at least 5 secs. The display will show a
' ' countdown, and then display ' '.
13
The CM170 can be stand mounted on a
standard camera tripod for long term
measuring. There is a threaded insert
on the rear of the CM170 for this.
