Mytee ESCAPE ETM-LX-115 User Manual

Electric truckmount
Hide thumbs Also See for ESCAPE ETM-LX-115:
Table of Contents

Advertisement

Quick Links

User Manual
ESCAPE
Model: ETM-LX-115
Electric Truckmount
REV. 5/30/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESCAPE ETM-LX-115 and is the answer not in the manual?

Questions and answers

Related Manuals for Mytee ESCAPE ETM-LX-115

Summary of Contents for Mytee ESCAPE ETM-LX-115

  • Page 1 User Manual ESCAPE Model: ETM-LX-115 Electric Truckmount REV. 5/30/18...
  • Page 2 If there are questions regarding maintenance, replacement, or ordering parts please contact an authorized Mytee Products Service Center. To see an updated list please visit our website at http://www.mytee.com/support/service-centers. Before using your Mytee product, please read this manual thoroughly.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INFORMATION AT A GLANCE 1.1 - Technical Specifications 1.2 - Included with the Escape™ 1.3 - Escape™ Front View 1.4 - Escape™ Rear View 1.5 - Switch Plate MACHINE OPERATION 2.1 - Powering the Escape™ 2.2 - Connecting Hoses &...

  • Page 4: Important Safety Information

    When and if calling Mytee for support, please grounding plug. The plug must be plugged into an appro- have your Model and Serial Number available for faster priate outlet that is properly installed in accordance with assistance.
  • Page 5 IMPORTANT SAFETY INFORMATION product is intended for commercial use only. national regulations may apply to the safe disposal of liquids which may contain: chemicals, grease, oil, acid, To reduce the risk of fire, electrical shock, or injury: alkalines, or other dangerous liquids. 1.

  • Page 6: At A Glance

    1 - AT A GLANCE 1.1 - Technical Specifications Solution Tank 12 Gallons Recovery Tank 12 Gallons Vacuum Dual Mytee® Hybrid Ametek vacuum motors Water Lift 182” Pump PSI Pump GPM Pump-Out GPM Cord one: 19 amps @ 115V 60Hz...

  • Page 7: Escape™ Front View

    1 - AT A GLANCE 1.3 - Escape™ Front View 1. Switch Plate 8. Auto Fill 2. Dual Circuit Indicator Light 9. Recovery Tank Drain Valve 3. Electrical Power Ports 10. Pump-Out Cam-Lock Hose Connection 4. Solution Tank Opening for Bucket Fill 11.

  • Page 8: Escape™ Rear View

    1 - AT A GLANCE 1.4 - Escape™ Rear View 1. Rear Vacuum Exhaust 2. 10” Foan-Filled Wheels 3. Transport Cart 4. 4” Locking Front Casters...

  • Page 9: Switch Plate

    1 - AT A GLANCE 1.5 - Switch Plate 1. Wash Out Hose 4. Pressure Regulator Use to wash out the recovery tank after use. Regulates the pressure (PSI) of solution output. 2. RUN/PRIME Valve 5. Pressure Gauge Set to the PRIME position to prime the pump and use the wash out Displays the current pressure the solution pump is set to.

  • Page 10: Machine Operation

    Mytee recommends the use of a 10,000 watt generator with this unit. This will supply ample power for the ETM. Method 2 - 3-prong or 4-prong dryer outlet.

  • Page 11: Connecting Hoses & Cleaning Tools

    2 - MACHINE OPERATION However, the Escape™ can be run on some 6,000 watt generators, depending on the manufacturer. Generators are rated differently, so if using 6,000 watt generator the rating must represent continuous running watts, not peak watts. In any case, check with the generator manufacturer to ensure the unit can provide 40 amps at 115 volts continu- ously.

  • Page 12: Preparing The Escape™ For Cold Weather

    2 - MACHINE OPERATION 2.5 - Preparing the Escape™ for Cold Weather Freezing temperatures can cause any water in the solution pump to freeze, causing damage to the pump. The ETM- LX-115 Escape™ features a drain valve which can be used to drain remaining water or solution from the pump before storing.

  • Page 13: Machine Maintenance

    3.3 - System Maintainer The Escape™ has a small mesh screen filter on the end Weekly flushing of the solution system with Mytee® of the solution intake hose in the solution tank. This filter System Maintainer helps keep lines clean and prevents should be checked and cleaned after each use.
  • Page 14 3 - MACHINE MAINTENANCE How to use System Maintainer: 1. Mix 1-quart 3601 System Maintainer with 1-quart of warm water. 2. After thoroughly mixing, pour this solution into the solu- tion tank. 3. Turn the pump on FIRST, and run solution through your cleaning tool.

  • Page 15: Accessories For Your Escape

    4 - AVAILABLE ACCESSORIES T-80R - Recovery Tank T-80S - Recovery Tank A500 - Stackable Van Shelving System Set 240-120 - Mytee® Hot Turbo In-Line Heater...
  • Page 16 4 - AVAILABLE ACCESSORIES 8903 - Wand Style Spinner® 8904 - T-Handle Spinner® 8908 - Counter Spinner® T-REX Jr. 12” Total Rotary Extractor T-REX 15” Total Rotary Extractor...

  • Page 17: Troubleshooting

    Solution Possible Causes Solutions Vacuum may not be getting Check the electrical con- Foam building up in the Use Mytee’s Auto Defoam- power. nections and the switch. recovery tank. er Kit (Part # A688). Look for loose or damaged wires.
  • Page 18 5 - TROUBLESHOOTING Pump pulsates when spraying. Possible Causes Solutions Filter is clogged. Clean the filter. Pump valves are clogged Rebuild pump. or damaged. Leaks seen under pump. Possible Causes Solutions Worn pump seals. Rebuild pump. Abrasives in solution have Mix chemical thoroughly damaged pump seals.
  • Page 19 NOTES...
