XCell 303582 Instruction Manual

CHARGER INSTRUCTION MANUAL
Model: 303582
This battery charger is not suitable for Univolt batteries.
It should not be used to charge Li-ion batteries.

Charger Specifications

The separate universal AC adaptor (power supply) can be used with world
wide AC voltage of 100V~240V, 50~60Hz. It has an output of 36 volts DC
2Amp and is plugged into the charger unit.
Charger Output: 7.2V to 18V DC 1.5A and has an automatic three stage
mode of: Pre-charge > Constant charge > Trickle charge
CHARGE TIMES: Nickel Cadmium
Capacity(Ah) 1.3Ah 1.5Ah 2.0Ah
Time in Mins 52 60
Charging Temperature Batteries should be cool before charging commences
and the ambient temperature should be less than +40ºC (104ºF) and more
than -10ºC (-14ºF).
Charging Protection The charger has built-in circuit protection to prevent
overheating, short circuits, extended time charging and detection of damaged
batteries.

SUITABLE FOR

DEWALT
BATTERIES
7.2volt to 18volt
NiCd and NiMH
Nickel Metal Hydride
2.1Ah 2.5Ah 3.0Ah 3.3Ah
80 84 100 120 132

Charging Procedure

1. Connect the power supply output plug to the input socket on the charger, and then plug
the other side cord into an appropriate AC wall socket. The red & yellow charger light
will blink together for 0.5 seconds then extinguish, indicating that the charger is ready.
2. Insert the battery pack into the charger, making sure the pack is fully seated in the
battery cavity. The red charging light will blink at one second intervals indicating the
charging process has begun.
3. The charger will show a steady red light when the battery pack is fully charged.
If the battery is left in the charger after the battery is fully charged it will automatically
switch to trickle charge mode
4. After charging is complete unplug the charger from the power source.

Light Indicators

PACK CHARGING (red light blinks)
FULLY CHARGED (red light steady)
FAULTY BATTERY (red light blinks 3 times per sec).
SHORT CIRCUIT (red light blinks 3 times per sec)
TEMPERATURE DELAY (yellow light steady and red light blinks once per second)

Charging Advice

To obtain the best performance and lengthen the life of the battery pack it should be charged
correctly. DO NOT charge the battery pack in an air temperature below +0ºC (32ºF), or
above +40ºC (104ºF). This is important and will prevent serious damage to the battery pack.
It is normal for the charger and battery pack to become warm to the touch while charging.
The battery pack should be recharged when it fails to produce sufficient power to operate
the tool - (when it loses its "grunt"). DO NOT CONTINUE to use a battery with low voltage or
capacity. Immediately charge the battery.
Always keep the charger battery cavity clear. DO NOT put any metal objects into battery
cavity as it may short circuit the charger.
Always unplug the charger from the power supply or turn off the power supply when there is
no battery pack in the cavity. Unplug the charger before attempting to clean it.
To assist in the cooling of the battery pack after use, avoid placing the charger or battery
pack in a warm environment such as in a metal shed, or an un-insulated vehicle or trailer.
... ... ... ... ... ... ... ...
