QUICK START GUIDE

Quick Start Set Up Guide. For full instructions please refer to the user guide (available to download from the website).
For stand installation, there is one type of screw
provided as shown below.
To complete the stand installation you will require a
cross head screw driver.
Place the TV set on a fl at and clean surface with the
panel facing downwards to avoid damage.
4 x
Used for attaching the stand
to the TV set (fi g.2)
1.
(fi g.1) Place the TV set on a fl at and clean surface with the panel facing downwards to avoid damage. (fi g.2) Secure the stand feet to the underside of the TV set using the 4 screws provided. The stand feet are marked L (left) and R (right).
Power
Cable RF Cable
Cables shown are detachable
2.
Using the RF cable supplied, connect the TV to the
TV Aerial wall socket. Connect the power cable to
the rear of the TV and the electrical outlet.
HOME MODE is the mode for end users, by default
it is set to a power saving mode which reduces the
energy used by up to 25% (by reducing the power
to the LED/LCD panel). This can be changed in the
picture mode settings in the TV operation menu.
When in STORE MODE
a brighter setting. The shop demonstration will
appear on the screen automatically after 2 minutes.
NOTE: In Home Mode, the TV will switch itself to Standby mode after 4-5 hours in the event that the
TV buttons or remote control buttons are not pressed.
5.
You will be welcomed with the fi rst time installation screen. Select your
chosen options and press OK on the remote control and tuning will begin.
Hotline: UK. 0871 097 1163 ROI. 01443 3940 |
Model Number: LC-40CUG8052K, LC-40CUG8062K, LC-43CUG8052K, LC-43CUG8062K, LC-49CUG8052K, LC-49CUG8062K, LC-55CUG8052K, LC-55CUG8062K,
LC-65CUG8052K and LC-65CUG8062K
UK: Calls cost 12p per minute plus your phone company's access charge.
SHA/QSG/0071
1
3.
The TV should power on automatically once the TV
is connected to the mains. In the event this does
not happen, please refer to the 'Pairing the remote
control' section of the Quick Start Guide.
the picture is adjusted to
6.
If the TV fi nds some, but not all of the channels you would expect to receive, the signal
being received by the TV is inadequate. In most circumstances this can be corrected with
the simple addition of a Signal Booster between the TV and the TV aerial wall socket, as
shown. Once the signal booster is connected, retune the TV in order to receive all of
the channels.
Internet: www.umc-uk.co.uk
ROI: Calls are charged at a local rate.
R
L
2
4.
Insert the batteries supplied into the remote
control. The remote control should automatically
be paired with the TV set. If this is not the case,
please refer to the 'Pairing the remote control'
section of the Quick Start Guide.
3
4
R
1
2
4 x
L
To receive Freeview channels, in particular Freeview HD channels,
you will need a Digital TV aerial and be in a good Freeview
coverage area. You can check coverage for your postcode
at www.freeview.co.uk.
Please note that any Freeview HD channels found during tuning
will be placed in channel positions above 100.
For example, 101 (BBC1 HD) 102 (BBC2 HD) etc.

Pairing the remote control

1) If the TV turns on automatically and the fi rst time installation
screen appears but the TV does not react to remote control, press
and hold the YELLOW and BLUE buttons on the remote control for
a few seconds. The power light will blink 5 times to confi rm the TV
and remote control are paired.
2) If the TV does not automatically turn on, you will need to
manually turn the TV on by pressing the TV control stick once, this
is located on the back of the TV in the left bottom corner. Once
switched on, press and hold the TV control stick on the TV set for
a few seconds. This will prompt the 'pairing menu' to appear, scroll
through and highlight the 'Pair your remote' option by pressing the
TV control stick up or down, then press the control stick to confi rm
your selection. Then with the remote control, press and hold the
YELLOW and BLUE buttons for a few seconds, the power light
will blink 5 times to confi rm the TV and remote control are paired.
