- Page 1 Digital Video Security Systems USER MANUAL HIGH RESOLUTION TVI CAMERA Rev. 02 HIGH RESOLUTION TVI CAMERA...
-
Page 2: Contents
Digital Video Security Systems CAUTION RISK OF ELECTRIC SHOCK CAUTION DO NOT OPEN CAUTION RISK OF ELECTRIC SHOCK CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NOT OPEN DO NOT OPEN DO NOT REMOVE COVER(OR BACK). CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK NO USER-SERVICEABLE PARTS INSIDE. -
Page 3: Table Of Contents
Digital Video Security Systems Contents Contents General Features Precautions Safety Instructions Menu Set Up Set Up Menu ▶ Menu Set Up ▶ Lens ▶ Exposure ▶ White Bal ▶ Backlight ▶ ▶ Day&Night ▶ Image ▶ Motion ▶ System ▶ Exit ▶... - Page 4 Digital Video Security Systems General Features Transfer Video Interface ● The combination of a 2MP CMOS image sensor and TVI DSP provides an excellent resolution of TVI picture. ● 3D-DNR Smart 3DNR prevents the image blurring of moving object and activates only if moving objects are appearing on the scene.
-
Page 5: Precautions
Digital Video Security Systems Safety Instructions Precautions for use ◑ This camera should be installed by qualified personnel only ◑ There are no user serviceable parts inside ◑ Do not disassemble this camera other than to make initial adjustments ◑ Use appropriate low voltage power cable to prevent fire or electrical shock ◑... -
Page 6: Menu Set Up
Digital Video Security Systems How to Set Up the camera menu ● Setup Menu - 6 - HIGH RESOLUTION TVI CAMERA... - Page 7 Digital Video Security Systems How to Set Up the camera menu ● Setup Menu - 7 - HIGH RESOLUTION TVI CAMERA...
-
Page 8: Menu Set Up
Digital Video Security Systems Menu Set Up Menu setting can be selected by the button inside the camera. 1. Press the set button. * The Set Up menu will be displayed on the monitor. MENU 1.LENS DCAUTO 2.EXPOSURE 3.WHITE BAL AUTO 4.BACKLIGHT 5.DNR... -
Page 9: Lens
Digital Video Security Systems 3. Change menu settings using the Left or Right button. * Available values or Status are displayed by pressing the Left or Right buttons. Press the button until desired value / status is displayed. 4. After Changing the setting move the arrow indicator to EXIT and press the SET button to EXIT. -
Page 10: Exposure
Digital Video Security Systems NOTE MODE MODE INDOOR RETURN * When you select the mode setup, you can select INDOOR, OUTDOOR or DEBLUR depending on the installation environment. *On manual mode, you can select NORMAL or DEBLUR depending on the installation environment. - Page 11 Digital Video Security Systems ◆ BRIGHTNESS : The brightness can be adjusted. The brightness control range is 1~20. ◆ SHUTTER : DC lens is launched with the setting of 1/30 and the manual lens is launched with the setting of Auto shutter, but the shutter speed can be adjusted from 1/30 to 1/30,000. →...
- Page 12 Digital Video Security Systems ◆ AUT0 : Use this mode when the color temperature is from 2,500k to 9,500k. ◆ AWB : The function to search for the color which is matched well with the ambient environment. ◆ AWC→SET : After letting camera focus on the blank white paper to the best condition of current lighting environment, press the SET button.
-
Page 13: Backlight
Digital Video Security Systems BACKLIGHT On this menu, backlight image can be compensated by users selecting one of modees. (HLC, BLC, WDR) 1. Move the triangular indicator to BACKLIGHT on the SETUP menu screen using the Up and Down button. 2. - Page 14 Digital Video Security Systems ◆ BLC : This fuction is used to counterbalance the screen image by increasing the brightness so that a subject which appears dark due to a strong backlight can be displayed in more detail. If you select BLC, a submenu appears where you can make finer adjustments.
-
Page 15: Day&Night
Digital Video Security Systems This fuction is used to improve the picture quality by filtering the noise which is generated under low brightness conditions. You can set different levels here. 1. Move the triangular indicator to DNR by useing the Up and Down button. 2. - Page 16 Digital Video Security Systems ◆ AUTO : Automatically, It shifts into the color mode in the bright environment and the B/W mode in the low light condition. It can adjust the delay time, starting brightness and end brightness according to the ambient conditions by pressing the Set button.
-
Page 17: Image
Digital Video Security Systems - EXTERN S/W [LOW/HIGH] : Set the external signal for switching between COLOR and B/W. - DELAY [LOW/MIDDLE/HIGH] : Set the delay time for switching between color and B/W . IMAGE When selecting, the following submenu will appear. MENU 1.LENS 2.EXPOSURE... - Page 18 Digital Video Security Systems - D-ZOOM : You can use the digital zoom with x1~x8 magnification. The higher the digital zoom magnification is, the lower the resolution is. - ACE [LOW/MIDDLE/HIGH/ON] : Intelligent lighting level control to over come even strong backlight conditions.
-
Page 19: Motion
Digital Video Security Systems MOTION This function is used to detect moving objects in the monitored area. When choosing ON, the following submenu will appear where you can adjust the settings for the MOTION function. MENU 1.LENS 2.EXPOSURE 3.WHITE BAL AUTO 4.BACKLIGHT 5.DNR... -
Page 20: System
Digital Video Security Systems SYSTEM This can be used when you want to select the additional function control. 1.When the SETUP menu is displayed, select SYSTEM using the Up and Down button. 2. Select one of the mode using the Up and Down button. MENU 1.LENS 2.EXPOSURE... -
Page 21: Exit
Digital Video Security Systems - COLOR BAR [OFF/ON] : Check current condition with color bar. - RESET [ON] : All settings will be restored to factory default. Exit Press the Set button in the exit menu to save the current settings and exit the Set Up menu. - 21 - HIGH RESOLUTION TVI CAMERA... -
Page 22: Trouble Shooting
Digital Video Security Systems Trouble Shooting PROBLEM POSSIBLE CAUSE ☞Check the power cable, power supply output and video Nothing appears on connection between the camera and monitor. the screen. ☞Are the camera lens or the lens glass dirty? Clean the lens / glass with a soft clean cloth. The image on the ☞Adjust the monitor controls, as required. - Page 23 Digital Video Security Systems - MEMO - - 23 - HIGH RESOLUTION TVI CAMERA...
