PulseWorx AM1 Installation Manual And Owner's Manual

FUNCTION
The AM1 Appliance Module is a high quality plug-in home
automation load controller that is capable of turning 120VAC
appliances and fluorescent lamps ON and OFF based on
digital commands received over the power wiring from a
remote UPB (Universal Powerline Bus) controller. UPB
controllers and modules can be freely located anywhere
throughout the home. No additional wiring is required and
no radio frequency signals are used for communication.
IMPORTANT SAFETY INSTRUCTIONS
When using electrical products, basic safety precautions
should always be followed, including the following:
1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
2. Keep away from water. If the product comes in contact
with water or other liquid, turn off the circuit breaker and
unplug the product immediately.
3. Never use products that have been dropped or
damaged.
4. Do not use this product outdoors.
5. Do not use this product for other than its intended
purpose.
6. Do not connect multiple lamps or appliances that, when
combined, exceed the maximum load ratings of the
product.
7. To avoid any risk of fire, burns, personal injury or electric
shock, install this product out of the reach of small
children.
8. Do not cover this product with any material when in use.
9. This product uses grounded plugs and sockets to reduce
the risk of electric shock. These plugs and sockets fit only
one way. If they do not fit, consult an electrician.
10. SAVE THESE INSTRUCTIONS.
Model: AM1
Appliance Module
INSTALLATION
The Appliance Module is designed for indoor use with devices
that plug into a grounded power outlet. To install the AM1
module:
1. Locate the device to be controlled and unplug it from the
2. Plug the controlled device into the socket on the bottom of
3. Plug the AM1 into the wall outlet (see illustration below).
4. Turn the device's power switch to its ON position.
If desired, another device can be plugged into the pass-thru
outlet socket on the front of the appliance module, which is
always powered.
CAUTION: Do not insert metal objects into the module while it is
connected to power.
The Inventors Of:
Installation Guide and
wall outlet.
the appliance module. The appliance/device current rating
must not exceed 12 Amps.
Wall
Outlet
Program
Button
Status
LED
Controlled
Outlet
19201 Parthenia St. Suite J
Northridge, CA 91324
(Phone) 818-701-9831 (Fax) 818-701-1506
sales@pcslighting.com www.pcslighting.com
Owner's Manual
Pass-Thru
Outlet
(always on)
