EL-USB-1
Temperature Data Logger
with USB Interface
FEATURES
• -35 to +80°C (-31 to +176°F) measurement range
• USB interface for set-up and data download
• User-programmable alarm thresholds
• Status indication via red, green and orange LEDs
• Supplied with replaceable internal lithium
battery and Windows control software
• Environmental protection to IP67
This standalone data logger measures and stores up to 16,382
temperature readings over a -35 to +80°C (-31 to +176°F) range. The user can easily
set up the logging rate and start-time, and download the stored data by plugging the data logger
into a PC's USB port and running the purpose designed software under Windows 2000, XP and Vista (32-bit).
Data can then be graphed, printed and exported to other applications. The data logger is supplied complete with a
long-life lithium battery which can typically allow logging for 1 year. Correct functioning of the unit is indicated by flashing red, green and
orange LEDs. The data logger is protected against moisture to IP67 standard when the protective cap is fitted.
Specifications
Measurement range
Internal resolution
Accuracy (overall error)
Logging rate
Operating temperature range
1/2AA 3.6V Lithium Battery Life
*
At 25°C and 1 m logging rate.
EL-WIN-USB (CONTROL SOFTWARE)
Lascar's EasyLog USB control software is supplied free of charge with each data logger. Easy to install and use, the control software runs
under Windows 2000, XP, Vista & 7. The software is used to set-up the data logger as well as download, graph and export data to Excel.
The software allows the following parameters to be configured:
•
Logger name (up to 16 characters)
•
ºC or ºF
•
Logging Rate (10s, 1m, 5m, 30m, 1hr, 6hr, 12hr)
•
High and low alarm levels
•
Start date and time
The latest version of the control software
may be downloaded free of charge from
www.lascarelectronics.com
Specifications liable to change without prior warning
Minimum
-35 (31)
every 10s
-35 (-31)
www.lascarelectronics.com
Issue 12
07/2012
ORDERING INFORMATION
Standard Data Logger
(Data Logger, Software on
CD, Battery)
Replacement Battery
Typical
Maximum
+80 (+176)
0.5 (1)
±1 (±2)
every 12hr
+80 (+176)
1*
S.L
Applies to EL-USB-1
EL-USB-1
BAT 3V6 1/2AA
Unit
°C (°F)
°C (°F)
°C (°F)
-
°C (°F)
Year
Page 1 of 4
