- Page 2 ZOTAC AMP BOX User’s Manual No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except by the purchaser for backup purposes, without the express written permission of ZOTAC.
-
Page 3: Table Of Contents
Package contents --------------------------------------------------------------------------------- 5 Getting to know your ZOTAC AMP BOX ------------------------------------------------------ 6 Front view ------------------------------------------------------------------------------------------- 6 Rear view-------------------------------------------------------------------------------------------- 7 Installing add-on card inside the ZOTAC AMP BOX ------------------------------------- 8 Setting up your ZOTAC AMP BOX ------------------------------------------------------------13 Approving Thunderbolt Devices ------------------------------------------------------------14... -
Page 4: Product Specifications
Product specifications Product dimensions • 271mm x 146mm x 257.3mm System requirements • Thunderbolt 3 host system Operating system • Windows 10 USB ports • Three USB 3.0 ports • One QC 3.0 port 40Gb/s Thunderbolt 3 support • Four lanes of PCI Express Gen3 •... -
Page 5: Safety Information
Safety information Your ZOTAC AMP BOX is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system Read and follow all instructions in the documentation before you operate your system. -
Page 6: Welcome
Welcome Congratulations on your purchase of the ZOTAC AMP BOX. The following illustration displays the package contents of your new ZOTAC AMP BOX. Please contact your retailer if any of the below items are damaged or missed. Package contents • 1 x ZOTAC AMP BOX •... -
Page 7: Getting To Know Your Zotac Amp Box
Getting to know your ZOTAC AMP BOX Front view 1. Power button The power button allows powering ON and OFF the system. The ring LED will be lit while system is On. 2. USB 3.0 port The USB 3.0 port supports the SuperSpeed USB 3.0 devices and is backwards compatible with USB 2.0/1.1 devices. -
Page 8: Rear View
Rear view 1. Thunderbolt 3.0 port Connect this port and your computer’s TB3 port with qualified TB3 cables. 2. USB 3.0 ports The USB 3.0 port supports the SuperSpeed USB 3.0 devices and is backwards compatible with USB 2.0/1.1 devices. Use this port for USB 3.0 devices for maximum performance with USB 3.0 compatible devices. -
Page 9: Installing Add-On Card Inside The Zotac Amp Box
Installing add-on card inside the ZOTAC AMP BOX 1. Remove the three screws at the rear panel. 2. Gently push the cover and remove as shown below. - Page 10 3. Remove the screw and the bracket from the rear panel. 4. Remove the two screws and brackets.
- Page 11 5. Connect the other end of the PCI-E power cable to the add-on card. 6. Insert the add-on card into the PCI-e slot.
- Page 12 7. Install the screws to secure the add-on card. 8. Install the bracket to the rear panel with screw.
- Page 13 9. Install the cover with the three screws.
-
Page 14: Setting Up Your Zotac Amp Box
Setting up your ZOTAC AMP BOX Please connect your peripherals before using your ZOTAC AMP BOX. 1. Connecting to Thunderbolt 3 Host 2. Connecting the power cable and turning on the ZOTAC AMP BOX... -
Page 15: Approving Thunderbolt Devices
Approving Thunderbolt Devices When connecting the ZOTAC AMP BOX to Thunderbolt Host for the first time, follow the below steps to approve Thunderbolt™ devices. 1. When the following dialog box appears, click and select “Always Connect”. 2. Click “OK” to complete installation. - Page 17 291-MH129-00...
