SAB SABIP1400 Quick Installation Manual

Quick Installation Guide

HD Wireless PTZ Dome IP Camera with P2P
Model: SABIP1400
2

Software Installation

1. Insert the CD into the CD drive of your computer.
2. Find the folder "Equipment Search Tool"" , then go to the folder
"For Windows OS"or "For Mac OS". Copy and paste the Equipment
Search Tool" le to your computer, or drag it onto your desktop.
Note:
If your computer doesn't have CD drive, you can download the IP
camera tool from our website for free.

Package Contents

IP Camera Power Adapter
Ethernet Cable Wi-Fi Antenna
Quick Installation Guide
HD Wireless PTZ Dome IP Camera with P2P
Model: FC8513PZ
Resource CD Quick Installation Guide
V1.0
3

Access the Camera

1. Enable the DHCP feature of your router (Enabled by default
normally), then open the IP Camera Tool program. It should
display the camera's IP address in your LAN (Local Area Network).
2. Double click the camera listed here, and your default browser
will open up to the camera's login page. When logging in for the
rst time, you will need to download and install the
IPCWebComponents. We will use Internet Explorer as an
example. For Google Chrome, MAC OS Safari, or Mozilla Firefox,
please refer to the User Manual.
Note：
It does not support 64-bit browser.
1

Hardware Introduction

Physical Description
Antenna
Infrared LED
LENS
Power
Alarm in/out
Reset Button
Click Install
3. After installing the IPCWebComponents, refresh the
browser and click Login.
Default username is admin
with no password.
Main stream o ers the highest
quality video while Sub stream
o ers less quality, but also less
delay when viewing.
Hardware Connection
LAN
WPS
Audio in/out
1. Mount the antenna and make it stand vertically.
2. Connect the camera to the LAN network (Router or Switch)
via ethernet cable.
3. Connect the power adapter to the camera.
4. When setting up your camera for the rst time, it will request
that you modify the default username and/or password if both
are still set to default. Input the New username, New password
and Con rm the password, click Modify to complete the
modi cation. You will now use the new username and
password to log in to the camera in the future.
Input the New username,
New password and
Con rm the password.
