Summary of Contents for Duplex STEAMTECH 12000
- Page 1 STEAMTECH 12000/4000 ENGLISH DUPLEX U K– 01/17...
- Page 2 STEAMTECH INTERPRETATION OF THE SYMBOLS PLACED ON THE UNIT BEFORE USING THE STEAM GENERATOR, READ AND FOLLOW THIS INSTRUCTION MANUAL. IT IS RECOMMENDED TO KEEP THIS INSTRUCTION MANUAL TO CONSULT IT LATER OR TO GIVE IT TO THE FOLLOWING OWNERS. PLEASE READ THE SAFETY INSTRUCTIONS ON THIS HANDBOOK BEFORE PROCEEDING ON THE FIRST USE.
- Page 3 RECICLING CENTERS AND MUST NOT BE LEFT IN THE ENVIRONMENT. SUBSTANCES SUCH AS OIL FOR MOTORS, DIESEL OIL, PETROL MUST NOT BE LEFT IN THE ENVIRONMENT AND MUST BE RECICLED IN THE PROPER RECICLING CENTERS ACCORDING TO THE ENVIRONMENTAL REGULATIONS. DUPLEX UK– 01/17...
-
Page 4: Table Of Contents
24 hours of usage. On the contrary, if you know the hardness level and it is between 0 and 4 French degrees , the boiler cleaning can be carried out after 100 hours of usage. ATTENTION. Do not use the appliance within the range of persons unless they wear DUPLEX UK– 01/17... - Page 5 Please be careful with the detergent to be used, as some in commerce, if heated above 100°C , taken to the gaseous state, could emanate highly toxic steams. Be aware to control the technical schedule and to consult the supplier. DUPLEX UK– 01/17...
-
Page 6: Technical Characteristics
The STEAMTECH is the ideal solution when it comes to cleaning and disinfecting. With the various accessories available, it cleans, disinfects, and removes dirt eliminating completely even the bacterial flora hidden in those areas most difficult to reach. DUPLEX UK– 01/17... -
Page 7: Technical Drawings
STEAMTECH 5. TECHNICAL DRAWINGS DUPLEX UK– 01/17... - Page 8 STEAMTECH DUPLEX UK– 01/17...
- Page 9 STEAMTECH DUPLEX UK– 01/17...
- Page 10 STEAMTECH DUPLEX UK– 01/17...
-
Page 11: Parts List
40) Locking latches for accessories 87) Round nozzle 40A) Hand wheel screw (only for 10 bar models) 88) Triangular stainless steel brush 41) Steam & vac Extension tube 89) Flat nozzle 4 cm 90) Stainless steel brush DUPLEX UK– 01/17... -
Page 12: Operating Instructions
Add diluted detergent in the tank (8). Activate the switch (35 or 35A, it depends if your machine is equipped with the hot water injection option) until detergent comes out of the accessory. The machine is now ready for use. DUPLEX UK– 01/17... - Page 13 Once the cleaning is finished it is recommended to vacuum approx. 3-5 litres of clean water to rinse the inside of the hose (33) and the suction conduits. Wash and dry all accessories used. Remove the vacuum drum (4) and, after emptying and rinsing it, let it dry before storing it away. DUPLEX UK– 01/17...
- Page 14 Insert the desired lance (84-85-86) onto the Geyser handgrip (80) and screw onto the lance the nozzle (87) or the various optional accessories (88-89-90) according to the type of cleaning to be carried out. Now your lance is ready for use. DUPLEX UK– 01/17...
-
Page 15: Maintenance
Wait until the refilling system has finished (approx. 3 minutes). The maintenance of the boiler is completed. MAINTENANCE OF THE VACUUM CLEANER Specific filter for non soluble powders. Clean the filter periodically (2A optional). DUPLEX UK– 01/17... - Page 16 STEAMTECH MAINTENANCE OF THE ACCESSORIES Grease occasionally joints on the accessories and hose extensions. PG5123 OR 29.82x2.62 PG5106 OR 9.25x1.78 PG5116 OR 6.75x1.78 DUPLEX UK– 01/17...
-
Page 17: Before Referring To The Technical Service
Accessories do not fit perfectly. There is dirt build up in the joints and Clean and lubricate the joints. lock/release latches (40). DUPLEX UK– 01/17... -
Page 18: Declaration Of Conformity
(For the checking of conformity to the above directives, the following standards have been used): Riferimento alle norme armonizzate: (Reference to harmonized standards): EN 60335-1 EN 60335-2-2 EN 60335-2-79 EN 55014-1 EN 55014-2 EN 61000-3-2 EN 61000-3-3 PESCANTINA – VERONA (ITALY)02-02-2010 FRANCHINI Giuliano (Managing Director) DUPLEX UK– 01/17... - Page 19 STEAMTECH Extraordinary maintenance procedure Generator Date of Intervention description, replaced components etc. working hours intervention THE MANUFACTURER RESERVES THE RIGHT TO PRODUCE TECHNICAL AND STRUCTURAL IMPROVEMENTS WITHOUT PRIOR NOTICE. DUPLEX UK– 01/17...
- Page 20 STEAMTECH DUPLEX UK– 01/17...
