Page 8 optoNCDT 1420...
Page 9: Safety
Safety Safety Sensor operation assumes knowledge of the operating instructions. Symbols Used The following symbols are used in this operating instructions: Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury. Indicates a situation that may result in property damage if not avoided. Indicates a user action.
Page 10: Notes On Ce Marking
Products which carry the CE mark satisfy the requirements of the EU directives cited and the European harmonized standards (EN) listed therein. The EU Declaration of Conformity is available to the responsible authorities according to EU Directive, article 10, at MICRO-EPSILON MESSTECHNIK GmbH & Co. KG Königbacher Straße 15 94496 Ortenburg / Germany The sensor is designed for use in industrial environments and meets the requirements.
Page 11: Intended Use
Safety Intended Use - The optoNCDT 1420 system is designed for use in industrial and laboratory applications. - It is used ƒ for measuring displacement, distance, position and thickness ƒ for in-process quality control and dimensional testing - The sensor must only be operated within the limits specified in the technical data, see Chap. 3.3.
Page 12: Laser Safety
Laser Safety Laser Safety ILD1420 The optoNCDT 1420 sensors operate with a semiconductor laser with a wavelength of 670 nm (visible/red). The sensors fall within Laser Class 2 (II). The laser is operated on a pulsed mode, the average power is ≤ 1 mW. The pulse frequency depends on the adjusted measuring rate (0.25 ... 4 kHz). The pulse duration ...
Page 13 Laser Safety Fig. 2 Laser warning labels on the sensor housing During operation of the sensor the pertinent regulations acc. to IEC 60825-1 on „radiation safety of laser equipment“ must be fully observed at all times. The sensor complies with all applicable laws for the manufac- turer of laser devices.
Page 14: Ild1420 Cl1
Laser Safety ILD1420 CL1 The optoNCDT 1420 CL1 sensors operate with a semiconductor laser with a wavelength of 670 nm (visible/ red). The maximum optical power is ≤ 0.39 mW. The sensors fall within Laser Class 1 (I). The accessible radiation is harmless under predictable conditions. Impairment of color vision and incon- venience may not excluded for class 1 laser devices, e. g. through glare. The following warning labels are attached to the sensor cable: CLASS 1 LASER PRODUCT Laser Klasse 1...
Page 15: Functional Principle, Technical Data
Functional Principle, Technical Data Functional Principle, Technical Data Short Description The optoNCDT 1420 uses the principle of optical triangulation, that is, a visible, modulated point of light is projected onto the target surface. The diffuse part of the reflection of this point of light is displayed depending on distance on a position-resolv- ing element (CMOS) by an receiver optic which is arranged to the optical axis of the laser beam in a defined angle.
Page 16: Auto Target Compensation (Atc)
Functional Principle, Technical Data Auto Target Compensation (ATC) The Auto Target Compensation (ATC) enables stable compensation independent of color and brightness of the measuring object. Also small objects can be detected reliably thanks to the small measuring spot. optoNCDT 1420 Page 16...
Page 17: Technical Data Ild1420
Functional Principle, Technical Data Technical Data ILD1420 Model ILD1420-10 ILD1420-25 ILD1420-50 ILD1420-100 ILD1420-200 ILD1420-500 Measuring range 10 mm 25 mm 50 mm 100 mm 200 mm 500 mm Start of measuring range 20 mm 25 mm 35 mm 50 mm 60 mm 100 mm Midrange...
Page 18 Functional Principle, Technical Data Shock 15 g / 6 ms / 3 axes (acc. to IEC 60068-2-29) approx. 145 g (with cable 3m) Weight approx. 60 g (with Pigtail) laser on/off; input functional input: trigger / zero-setting / mastering / teaching Control I/O output digital output...
Page 19: Technical Data Ild1420-Cl1
Functional Principle, Technical Data Technical Data ILD1420-CL1 Model ILD1420-10CL1 ILD1420-25CL1 ILD1420-50CL1 Measuring range 10 mm 25 mm 50 mm Start of measuring range 20 mm 25 mm 35 mm Midrange 25 mm 37.5 mm 60 mm End of measuring range 30 mm 50 mm 85 mm...
Page 20 Functional Principle, Technical Data Schock 15 g / 6 ms / 3 axes (acc. to IEC 60068-2-29) appr. 145 g (with cable 3 m) Weight appr. 60 g (with Pigtail) laser on/off; input funktional input: trigger / zero-setting / mastering / teaching Control I/O output digital output...
Page 21: Delivery
Delivery Delivery Unpacking, Included in Delivery - 1 Sensor ILD 1420 - 1 Assembly instruction - 1 CD with program <ILD1420 DAQ Tool.exe> and instruction manual - 1 Calibration protocol - Accessories (2 pieces screw M2 and 2 pieces washer) Carefully remove the components of the measuring system from the packaging and ensure that the goods are forwarded in such a way that no damage can occur.
Page 22: Installation
Installation Installation Instructions for Installation 5.1.1 Reflection Factor of the Target Surface In principle the sensor evaluates the diffuse part of the reflected laser light. Laser beam Laser beam Laser beam 2  Ideal diffuse reflection Direct mirror reflection Real reflection Fig.
Page 23: Color Differences
Installation 5.1.2.2 Color Differences Because of intensity compensation, color difference of targets affect the measuring result only slightly. How- ever, such color differences are often combined with different penetration depths of the laser light into the material. Different penetration depths then result in apparent changes of the measuring spot size. Therefore color differences in combination with changes of penetration depth may lead to measuring errors.
Page 24: Surface Roughness
Installation 5.1.2.6 Surface Roughness Laser-optical sensors detect the surface using an extremely small laser spot. They also track slight surface unevenness. In contrast, a tactile, mechanical measurement, e.g. using a caliper, detects a much larger area of the measurement object. In case of traversing measurements, surface roughnesses of 5 µm and more lead to an apparent distance change.
Page 25: Angle Influences
Installation 5.1.2.7 Angle Influences Tilt angles of the target in diffuse reflection both around the X and the Y axis of less than 5 ° only have a disturbing effect with surfaces which are highly reflecting. These influences have to be explicitly considered when scanning profiled surfaces. Basically the angle be- havior of triangulation is liable to the reflectivity of the measuring object surface.
Page 26: Optimizing The Measuring Accuracy
Installation 5.1.3 Optimizing the Measuring Accuracy In case of rolled or polished metals that are moved Color strips Direction of movement past the sensor the sensor plane must be arranged in the direction of the rolling or grinding marks. The l l a a s s e e r r o o f f f f i i n n r r a a n n g g e e m m i i d d r r a a n n g g e e...
Page 27: Mounting, Dimensions
Installation Mounting, Dimensions The optoNCDT 1420 sensor is an optical system for measurements with micrometer accuracy. The laser beam must be directed perpendicularly onto the surface of the target. In case of misalignment it is possible that the measurement results will not always be accurate. Make sure it is handled carefully when installing and operating.
Page 28 Installation 46 (1.81) 20 (.79) ILD 1420- 50 100 200 500 mm 10 50 100 200 500 SMR mm 20 60 100 EMR mm 30 85 150 260 600 40 (1.57) (.12) mm 10 70 190 7.50 The indicated free space in the reception (.31) (.24) (.3)
Page 29: Indicator Elements At Sensor
Installation Indicator Elements at Sensor LED State Meaning green Measuring object within sensor range yellow Mid range LED state Error - e.g. Poor target or out of range Select key Laser off LED Output Meaning green RS422 measurement value output RS422 and current output are switched off.
Page 30: Electrical Connections
Installation Electrical Connections 5.4.1 Connection Possibilities Source Cable/Supply Interface End device PCF1420-x/I and PCF1420-x/U PC1402-x/CSP PCF1420-x/I and PCF1420-x/U Extension clamp RS422 IF2001/USB PCF1420-x/IF2008 (IF2008-Y) PS 2020 IF2004/USB PCF1420-x/IF2008 and IF2008-Y-adap- ter cable Sensor supply is done by IF2008 peripheral Fig. 15 Connection examples on ILD 1420 The different periphery devices can be connected by the illustrated connection cables to the 14-pin sensor plug, see Fig.
Page 31 Installation Peripheral Sensor channels Interface IF2001/USB, RS422 USB converter IF2004/USB four RS422 IF2008, PCI interface card four SPS, ILD 1420 or the like Functional input: trigger Switch, key, PLC or the like Switching input laser On/Off Fig. 16 Max. sensor channels on the peripheral devices optoNCDT 1420 Page 31...
Page 32: Pin Assignment
Installation 5.4.2 Pin Assignment The shielding of the cable is 0.3 m connected to the sensor hous- ing. The sensor cable is not cable carriers suitable. One end is molded on the sensor, the other end has free leads with ferrules or a pigtail with a M12 male connector.
Page 33: Supply Voltage
Color similar sources of pulse interference at the 11 ... same time. 30 VDC ILD1420 MICRO-EPSILON recommends using an optional available power supply unit PS2020 for the sensor. blue Ground Fig. 17 Connection of supply voltage 5.4.4 Laser on The measuring laser on the sensor is activated via an HTL switch input.
Page 34: Analog Output
Installation 5.4.5 Analog Output The sensor provides a current output 4 ... 20 mA. The output may not be continuously operated in short circuit operation without load resistor. The short circuit operation leads to durable thermal overload and thus for automatic overload shutdown of the output.
Page 35: Multifunctional Input
Sensor End device (converter) Symmetric differential Type IF2001/USB signals acc. to EIA- 12-pin M12 Sensor from MICRO-EPSILON 422, not galvanically cable connector cable isolated from supply Tx + (Pin 5) grey Rx + (Pin 3) voltage.
Page 36: Digital Output
Installation 5.4.8 Digital Output The switching characteristic (NPN, PNP , Push-Pull, Push-Pull negated) of the digital output (Error) depends on the programing. The NPN output is e.g. suitable for adjustment to TTL logics with an auxiliary voltage U = +5 V. The digital output is protected against reverse polarity, overloading (<...
Page 37: Connector And Sensor Cable
Unused open cable ends must be insulated to protect against short circuits or malfunction of the sen- sor. MICRO-EPSILON recommends to use the cable carriers suitable standard connection cable of the optional accessories, see Chap. Mount the 12-pin M12 cable connector if you use a cable carriers suitable sensor cable PCF1420.
Page 38: Operation
Operation Operation Getting Ready for Operation Install and assemble the optoNCDT 1420 in accordance with the instructions set out, see Chap. Connect the sensor with the indicator or monitoring unit and the power supply. The laser diode in the sensor can only be activated if at the input Laser on/off Pin 8 is connected with Pin 12, see Chap.
Page 39: Operation Via Web Interface
Operation Operation via Web Interface 6.2.1 Preconditions In the sensor, dynamic Web pages are created that contain the current settings of the sensor and the periph- ery. The operation is only possible as long as an RS422 connection to the sensor exists. The sensor is connected to a PC/notebook via a RS422 converter, supply voltage persists.
Page 40 Operation Choose the desired sensor. Click on the button Connect. Choose Configuration in the menu Extras. Choose the browser type in dialog Configuration and click on the button Fig. 25 Dialog configuration web interface optoNCDT 1420 Page 40...
Page 41: Access Via Web Interface
Operation 6.2.2 Access via Web Interface Start the web interface of the sensor, see Chap. 6.2.1 Interactive websites for programming the sensor now appear in the web browser. In the top navigation bar other auxiliary functions (settings, measurement chart etc.) are available.
Page 42 Operation Standard Ceramics, metal Multi-surface Printed circuit boards (PCB), hybrid material Light penetration Plastics (Teflon, POM), Materials with large penetration depth of the laser In the area Signal quality you can switch between four given basic settings (static, balanced, dynamic and no averaging).
Page 43: Measurement Presentation Via Web Browser
Operation 6.2.3 Measurement Presentation via Web Browser Start the measurement value display (Measurement chart) in the horizontal navigation bar. Fig. 27 Website measurement (distance measurement) Stop stops the diagram; data selection and zoom function are still possible. Pause interrupts recor- ding.
Page 44 Operation For scaling the measurement value axis (y-axis) of the graphics you can either choose Auto (= auto- scaling) or Manual (= manual setting). The search function enables time-saving access to functions and parameters. In the text boxes above the graphics current values for distance, exposure time, current measuring and display rate and timestamp are displayed.
Page 45: Video Signal Via Web Browser
Operation 6.2.4 Video Signal via Web Browser Start the video signal display with the function Video in the area Diagram type. The diagram in the big graphic window on the right displays the video signal of the recipient filed. The video signal in the graphic window displays the intensity distribution above the pixels of the recipient field.
Page 46 Operation The video curves to be displayed while or after measurement can be switched on or off in addition in the left window. Non active curves are highlighted in gray and can be added by clicking the hook. If you only want to see a single signal, then click on its name.
Page 47: Programming Via Ascii Commands
Operation By displaying the video signal, you can detect effect of the adjustable measurement task (target material), choice of peak and possible interfering signals by means of reflections. There is no linear relationship between the position of the peaks in the video signal and the output measure- ment value.
Page 48: Set Sensor Parameter
Set Sensor Parameter Set Sensor Parameter Preliminary Remarks to the Adjustments You can program the optoNCDT 1420 simultaneously in two different ways: - using a web browser via the ILD 1420 DAQ Tool and the Web interface - ASCII command set and a terminal program via RS422. If you do not save the programming permanently in the sensor, you lost the settings after turning off the sensor.
Page 49: Inputs
Set Sensor Parameter Inputs Go to the menu Inputs in the menu Settings. Laser on/off On / Off Laser on/off is only effective when pin 8 is connected to GND. Multifunctional Zeroing (Mastering) High / Low Sets the function of the digital input. The Trigger influ- input ences capture and export of a measurement value.
Page 50: Measurement Task
Set Sensor Parameter 7.4.2 Measurement Task The measurement task contains choice of the measuring object (target). The choice of a target loads a pre- defined sensor configuration which achieves the best results for the chosen material. Measurement Standard Suitable for materials made of ceramics, metal or filled plastics task Changing surfaces 1 Suitable e.g.
Page 51: Measuring Rate
Set Sensor Parameter 7.4.3 Measuring Rate The measuring rate indicates the amount of measurements per second. Choose the desired measuring rate. Measuring rate 250 Hz / 500 Hz / 1 kHz / Use a high measuring rate with light and matt measuring ob- 2 kHz / 4 kHz jects.
Page 52: Triggering
- Triggering does not influence the measuring rate resp. the timing so that between the trigger event (level change) and the start of output always lie 3 cycles + 1 cycle (Jitter). - Micro-Epsilon recommends the abdication of data reduction, for example, by sub-sampling when the triggering is used.
Page 53 Set Sensor Parameter Implemented trigger conditions: Level triggering with high level / low level. Continuous measurement input resp. output, as long as the selected level is applied. Then stops the data output. The pulse duration must be at least one cycle time. The sub- sequent break must also be at least one cycle time.
Page 54: Signal Processing - Trigger For Acquiring Values
Set Sensor Parameter 7.4.4.2 Signal Processing - Trigger for Acquiring Values The current field signal is processed only after a valid trigger event, and it is used to calculate the measure- ment values. The measurement values are then forwarded for further calculation (e.g. averaging) and for output via an analog or a digital interface.
Page 55: Mask Evaluation Area, Roi
Set Sensor Parameter 7.4.5 Mask Evaluation Area, ROI Masking limits evaluation area (ROI - Region of interest) for distance calculation in the video signal. This func- tion is used to suppress e.g. disturbing reflections or extraneous light. Evaluation range Measuring range Fig.
Page 56: Peak Selection
Set Sensor Parameter 7.4.6 Peak Selection Peak selec- First peak / Defines, which signal is used close Sensor faraway tion highest peak / for the evaluation in the line last peak signal. Highest peak First peak: nearest peak to the First Last sensor.
Page 57: Averaging
Set Sensor Parameter 7.4.8 Averaging 7.4.8.1 General The averaging is recommended for static measurements or slowly changing values. Averaging Inactive Measurements are not averaged. Moving N values 2 / 4 / 8 ... 128 Value Indication of averaging mode. The averaging number N indicates the number of consecu- Recursive N values 2 ...
Page 58: Moving Average
Set Sensor Parameter 7.4.8.2 Moving average The selected number N of successive measurement values (window width) is used to generate the arithmetic average value M on the basis of the following formula: MV = Measurement value, MV (k) N = Averaging number, k = Running index = Averaging value respectively output value Mode:...
Page 59: Recursive Average
Set Sensor Parameter 7.4.8.3 Recursive Average Formula: MV = Measurement value, + (N-1) x (n) = rek (n-1) N = Averaging number, n = Measurement value index = Averaging value respectively output value Mode: Each new measurement value MV(n) is added, as a weighted value, to the sum of the previous measurement values M (n-1).
Page 60: Zeroing And Mastering
Set Sensor Parameter 7.4.9 Zeroing and Mastering By zeroing and mastering you can set the measurement value to a set point in the measuring range. The out- put range is moved thereby. This function makes sense, for example, for several adjacent measuring sensors or in the case of the thickness and planarity measurement.
Page 61: Zeroing, Mastering With Select Key
Set Sensor Parameter 7.4.9.1 Zeroing, Mastering with Select Key The key Select is Measuring locked according to select select factory settings after 30 ms ... <3 s expiry of 5 min. You can unlock the keylock e.g. via the web interface, LED state see Chap.
Page 62: Zeroing, Mastering With Hardware Input
Set Sensor Parameter 7.4.9.2 Zeroing, Mastering with Hardware Input A pulse on the function- Measuring Pin 9 Pin 9 al input can be made (violet) (violet) via pin 9 pigtail resp. 30 ms ... <3 s via the violet wire on the sensor cable resp.
Page 63: Data Reduction, Output Data Rate
Set Sensor Parameter 7.4.10 Data Reduction, Output Data Rate Data reduction Value Instructs the sensor, which data are excluded from the output, and thus the amount of transmitted data is reduced. Reduction applies RS422 / Analog The interfaces, which are provided for the sub-sampling, are to be selected with the checkbox.
Page 64: Outputs
Set Sensor Parameter Outputs 7.5.1 Overview RS422 Baud rate 9.6 / 19.2 / 56.0 / 115.2 / 230.4 ... / Transmission rate with binary data 1000 kBps format. Output data Distance / Shutter time / Intensity / The data which are provided for the Sensor state / Measurement counter / transmission are to activate with Non-linearized focal point /...
Page 65: Digital Output, Rs422
Set Sensor Parameter 7.5.2 Digital Output, RS422 7.5.2.1 Values, Ranges The digital measuring values are being output as unsigned digital values (raw values). 16 resp. 18 bits per value are being transmitted. Subsequently you can find a compilation of output values and the conversion of the digital value. Value Length Variables Value range...
Page 66 Set Sensor Parameter Sensor status 18 bits x = digital value [0; 242143] Bit 0 (LSB): peak starts before ROI Bit encoding [0; 1] Bit 1: peak ends after ROI Bit 2: no peak found SMR = Start of measuring range Bit 5: distance before SMR (extended) EMR = End of measuring range Bit 6: distance after EMR (extended)
Page 67: Characteristics Digital Output
Set Sensor Parameter 7.5.2.2 Characteristics Digital Output Measurements are coded with 18 bit, if the based on zero setting or mastering. The master value itself can accept the double measu- ring range. The examples below show the digital output behavior of an ILD1420-50 with 50 mm measuring range. Target at 16 % measuring range Target at 60 % measuring range Target at 60 % measuring range...
Page 68 Set Sensor Parameter Set target at 80 % measuring range (40 mm), set master value 100 mm 225465 Digital 174720 174077 161230 109843 65520 109200 64877 96995 52031 Dig. Reserve Reserve 32760 measuring Measuring Distance after range range MP‘ mastering 32760 [mm] 50 %...
Page 69: Analog Output Scaling
Set Sensor Parameter 7.5.3 Analog Output Scaling 20 mA Default characteristic Analog 7.5.3.1 Output Scaling output - Max. output range: 4 mA ... 20 mA - Output gain D I : 16 mA = 100 % MR - Error value: 3.0 mA (±10 µA) 4 mA The teaching scales the analog output (4 to 3 mA...
Page 70: Output Scaling With Key Select
Set Sensor Parameter 7.5.3.2 Output Scaling with Key Select Measuring Position the Position the select select select measuring measuring object to 4 mA object to 20 mA min. min. 30 ms 30 ms LED state Green, red, yellow flashes red yellow flashes green yellow...
Page 71: Output Scaling Via Hardware Input
Set Sensor Parameter 7.5.3.3 Output Scaling via Hardware Input Scaling of the analog output can be made via an impulse at the functional input, pin 9 pigtail resp. via the violet wire on the sensor cable resp. PCF1420-x. Measuring Start Position the Teach-in 1 Positon the...
Page 72: Calculation Of Measuring Value Using Analog Current
Set Sensor Parameter 7.5.3.4 Calculation of Measuring Value using Analog Current Current output (without mastering, without teaching) Variables Value range Formula [3,8; <4] SMR reserve = current [mA] [4; 20] measuring range [mA] - 4) [>20; 20,2] EMR reserve [mm] * MR [mm] MR = measuring range [mm]...
Page 73 Set Sensor Parameter Current output (with teaching) Variables Value range Formula [3,8; <4] SMR reserve = current [mA] [4; 20] measuring range [>20; 20,2] EMR reserve [mA] - 4) [mm] [mm] - m [mm]| MR = measuring range [mm] {10/25/50/100/200/500} m, n = teaching area [mm] [0;...
Page 74: Characteristics Distance Value And Analog Output
Set Sensor Parameter 7.5.3.5 Characteristics Distance Value and Analog Output The mastering and zero setting function set the analog output on half of the output range independent on the master value, thus 12 mA. The examples below show the current output and the distance value behavior of an ILD1420-50 with 50 mm measuring range. Target at 16 % measuring range Target at 60 % measuring range 8.00 mm...
Page 75 Set Sensor Parameter 20.2 mA Master point Master value Out min Out max 20 mA 16 % 9.44 mA 20.0 mA 0 mm (8 mm) (-8 mm) (33 mm) Analog 60 % 4.00 mA 18.40 mA Out max 10 mm (30 mm) (-15 mm) (30 mm)
Page 76: Mastering And Teaching Analog Output
Set Sensor Parameter 7.5.3.6 Mastering and Teaching Analog Output With n < m generates an inverse characteristic. Proceed as follows: 1. Mastering or zero setting, menu signal processing 20 mA 2. Teach putput, menu Outputs The mastering and zero setting function set the analog output on half of the output range, see Chap.
Page 77: System Settings
Set Sensor Parameter System Settings 7.6.1 General After programming all the settings are to be stored permanently in a set of parameters. The next time you turn on the sensor they are available again. 7.6.2 Unit, Language The web interface promotes the units millimeter (mm) and inch when displaying measuring results. You can choose German or English in the web interface.
Page 78: Keylock
Set Sensor Parameter 7.6.3 Keylock The function keylock for the key Select, see Chap. prevents unauthorized / unintended performing of the key functions. Keylock is always activated when user level User is chosen. Keylock can only be deacti- vated in user level Expert. If an expert logs in the system, keylock on the sensor is automatically unlocked. Key lock Automatic Range from 1 ...
Page 79: Load, Save
Set Sensor Parameter 7.6.4 Load, Save All settings to the sensor can be saved permanently in application programs, so called setups. Fig. 47 Administration of applica- tion programs Administer setups in the sensor, possibilities and procedure Save settings Activate existing setup Save changes in active setup Define setup after booting Menu New setup...
Page 80 Set Sensor Parameter Exchange setups with PC/notebook, possibilities Save setup on PC Load setup from PC Menu Load & Save Menu Load & Save Click on Create setup with the left mouse but- Click on the desired setup with the left mouse button, area A.
Page 81: Import, Export
Set Sensor Parameter 7.6.5 Import, Export A set of parameters covers current settings, setup(s) and the initial setup when booting the sensor. The menu Import & Export enables easy exchange of sets of parameters with a PC/notebook. Exchange set of parameters with PC/notebook, possibilities Save set of parameters on PC Load set of parameters from PC Menu Import &...
Page 82: Access Authorization
Set Sensor Parameter 7.6.6 Access Authorization The assignment of a password prevents unauthorized changing of settings on the sensor. When delivered, the password protection is not enabled. The sensor operates in the user level Professional. The password protection should be enabled after configuration of the sensor. The default password for the expert level is 000.
Page 83: Sensor Reset
Specifies the user level, with which the sensor starts after the re- restarting Professional starting. For this purpose, MICRO-EPSILON recommends the selection user. After configuration of the sensor the password protection is to be activated. Please note the password for later reference.
Page 84: Digital Interfaces Rs422
Digital Interfaces RS422 Digital Interfaces RS422 Preliminary Remarks The interface RS422 has a maximum baud rate of 1 MBaud. The factory-set baud rate is 921.6 kBaud. The maximum measuring rate is 4 kHz. Data format: Measurement values in binary format, commands as an ASCII string. Interface parameter: 8 Data bits, no parity, one stop bit (8N1).
Page 85: Conversion Of The Binary Data Format
The sensor continues to deliver measurement values to the RS422 output even while communicating with the sensor. For the data transmission with a PC the MICRO-EPSILON IF2008 PCI BUS interface card is suitable. This can be connected to the sensor via the PCF1420-x/IF2008 interface cable, which is also available as an option.
Page 86: Cleaning
Cleaning Cleaning Cleaning of the protective screens is recommended periodically. Dry Cleaning Therefore an optics anti-static brush is suitable or bleeding the screen with dehumidified, clean and oil-free compressed air. Wet Cleaning For cleaning the protective screen use a clean, soft, lint-free cloth or lens cleaning paper with pure alcohol (isopropyl).
Page 87: Software Support With Medaqlib
- works independent of the used interface type, - features by identical functions for the communication (commands), - provides a consistent transmission format for all MICRO-EPSILON sensors. For C/C++ programmers MEDAQLib contains an additional header file and a library file. You will find the lat- est driver / program routine at: www.micro-epsilon.de/download...
Page 88: Liability For Material Defects
The liability for material defects is 12 months from delivery. Within this period, defective parts, except for wearing parts, will be repaired or replaced free of charge, if the device is returned to MICRO-EPSILON with shipping costs prepaid. Any damage that is caused by improper handling, the use of force or by repairs or modifications by third parties is not covered by the liability for material defects.
Page 89: Appendix
Appendix| Optional Accessories Appendix Optional Accessories IF2001/USB Converter RS422 to USB, type IF2001/USB, useable for cable PCF1420-x/I or PCF1420-x/U, inclusive driver, connections: 1× female connector 10-pin (cable clamp) type Würth 691361100010, 1x female connector 6-pin (cable clamp) type Würth 691361100006 IF2004/USB 4 channel converter RS422 to USB useable for cable PCF1420-x/IF2008 (IF2008-Y), inclusive...
Page 90 Appendix| Optional Accessories Extension clamp EtherCAT extension clamp to connect two RS422 ILD1420 sensors with a EtherCAT master. Necessary cable: PC1402-x/CSP . IF2008-Y adapter Used to connect two sensors with interface cable cable PCF1420-x/IF2008 to a port of the IF2008. optoNCDT 1420 Page 90...
Page 91: Factory Setting
Appendix| Factory Setting Factory Setting Password „000“ Measurement averaging Median 9 Measuring rate 2 kHz Output Analog current 100 % FSO: I = 20 mA , digital 64877 RS422 921.6 kBaud Measuring range 0 % FSO: I = 4 mA, digital 643 Trigger mode No trigger Peak selection...
Page 92: A 3 Ascii Communication With Sensor
Appendix| ASCII Communication with Sensor ASCII Communication with Sensor A 3.1 General The ASCII commands can be sent to the sensor via the RS422 interface. All commands, inputs and error messages are effected in English. One command always consists of a command name and zero or several parameters, which are separated by blanks and are completed with LF.
Page 93 Appendix| ASCII Communication with Sensor „<a>“ The value of the parameter lies in a value range of “... to …“, see parameter description. Parameter values without peak brackets can only assume discrete values, see parameter description. Parantheses are to be understood as a grouping, that is, for a better articulation „P1 P2 | P3“ is written as „(P1 P2)|P3“.
Page 94: Overview Commands
Appendix| ASCII Communication with Sensor A 3.2 Overview Commands Group Chapter Command Short description General Chap. A 3.3.1 HELP Help on commands Chap. A 3.3.2 GETINFO Request sensor information Chap. A 3.3.3 LANGUAGE Determine language of website Chap. A 3.3.4 RESET Reboot sensor Chap.
Page 95 Appendix| ASCII Communication with Sensor Interfaces Chap. A 3.3.10.1 BAUDRATE RS422 setting Chap. A 3.3.10.2 UNIT Selection of measuring unit web interface Chap. A 3.3.10.3 MFIFUNC Selection of function multifunctional input Chap. A 3.3.10.4 ERROROUT1 Activate digital output Chap. A 3.3.10.5 ERRORLEVELOUT1 Output level digital output Chap.
Page 96 Appendix| ASCII Communication with Sensor Measurement General Chap. A 3.4.1 TARGETMODE Choice of measurement algorithms Chap. A 3.4.2 MEASPEAK Choice of the peak in the video signal Chap. A 3.4.3 MEASRATE Selection of measuring rate Chap. A 3.4.4 LASERPOW Selection of laser power Chap.
Page 97: A 3.3 General Commands
Appendix| ASCII Communication with Sensor A 3.3 General Commands A 3.3.1 HELP HELP [<Command>] Issues a help for every command. If no command is specified, a general help is output. A 3.3.2 GETINFO, Sensor Information GETINFO Request of sensor information. Output see example below: ->GETINFO Name: ILD1420-10...
Page 98: A 3.3.4 Reset, Boot Sensor
Appendix| ASCII Communication with Sensor A 3.3.4 RESET, Boot Sensor RESET The sensor is rebooted. A 3.3.5 RESETCNT, Reset Counter RESETCNT [TIMESTAMP] [MEASCNT] Sets back internal counters in the sensor. - TIMESTAMP: sets back timestamp - MEASCNT: sets back measurement counter A 3.3.6 ECHO, Switching the Command Reply, ASCII Interface ECHO ON|OFF...
Page 99: A 3.3.7 Print, Sensor Settings
Appendix| ASCII Communication with Sensor A 3.3.7 PRINT, Sensor Settings PRINT Print serves the output of all sensor settings. Example of an answer: GETUSERLEVEL PROFESSIONAL OUTPUT ANALOG STDUSER PROFESSIONAL OUTREDUCEDEVICE NONE BAUDRATE 921600 OUTREDUCECOUNT 2 UNIT MM OUTVIDEO_RS422 NONE LANGUAGE DE OUTADD_RS422 NONE MFIFUNC NONE GETOUTINFO_RS422 DIST1...
Page 100: A 3.3.8 User Level
Appendix| ASCII Communication with Sensor A 3.3.8 User Level A 3.3.8.1 LOGIN, Change of the User Level LOGIN <Password> Enter the password to change user level. The following user levels are available: - USER (standard user): “read-only” access to all elements and graphical display of output values of web surface - PROFESSIONAL (expert): “read-only”...
Page 101: A 3.3.9 Triggering
Appendix| ASCII Communication with Sensor A 3.3.9 Triggering The multifunctional input also serves as trigger input. A 3.3.9.1 TRIGGER, Selection TRIGGER NONE|EDGE|PULSE|SOFTWARE - NONE: no triggering - PULSE: level triggering - EDGE: edge triggering - SOFTWARE: software triggering A 3.3.9.2 TRIGGERAT, Effect of the Trigger Input TRIGGERAT INPUT|OUTPUT - INPUT: triggers the measurement value recording.
Page 102: A 3.3.9.5 Triggersw, Software Trigger Pulse
Appendix| ASCII Communication with Sensor A 3.3.9.5 TRIGGERSW, Software Trigger Pulse TRIGGERSW Creats a trigger pulse. Error message is displayed if “SOFTWARE” is not selected in trigger selection. A 3.3.10 Interfaces A 3.3.10.1 BAUDRATE, RS422 BAUDRATE 9600|19200|56000|115200|128000|230400|256000|460800|691200|921600| 1000000 Set the baud rate for the RS422 interface. A 3.3.10.2 UNIT, Web Interface UNIT MM|INCH Change the measurement display on the websites.
Page 103: A 3.3.10.5 Errorlevelout1, Output Level Digital Output
Appendix| ASCII Communication with Sensor A 3.3.10.5 ERRORLEVELOUT1, Output Level Digital Output ERRORLEVELOUT1 NPN|PNP|PUSHPULL|PUSHPULLNEG Choice of output level for ERROROUT1. - NPN: digital output is active in case of an error - PNP: digital output is active in case of an error - PUSHPULL: digital output with high level in case of an error - PUSHPULLNEG: digital output with low level in case of an error Wiring of digital output ERROR1, see Chap.
Page 104: A 3.3.11 Handling Of Setups
Appendix| ASCII Communication with Sensor A 3.3.11 Handling of Setups A 3.3.11.1 IMPORT IMPORT [FORCE] [APPLY] <Data> Import of data in JSON format to the sensor. First, the import command returns a prompt (->). Afterwards, data can be sent. After importing a prompt (->) is returned. - FORCE: overwriting of measurement settings (= MEASSETTINGS) with the same name (otherwise an error message is returned when using the same name).
Page 105: A 3.3.11.4 Basicsettings, Load / Save Device Settings
Appendix| ASCII Communication with Sensor ƒ PRESETMODE: Returns the set signal quality ƒ PRESETMODE <Mode>: Setting the signal quality. Setting the signal quality is possible only, if a preset was loaded. • <mode> = STATIC|BALANCED|DYNAMIC|NOAVERAGING|NONE A 3.3.11.4 BASICSETTINGS, Load / Save Device Settings BASICSETTINGS READ | STORE - READ: Loads the stored device settings from the senosr.
Page 106: A 3.3.13 Key Function
Appendix| ASCII Communication with Sensor A 3.3.13 Key Function A 3.3.13.1 KEYFUNC, Choose Key Function KEYFUNC NONE | MASTER | TEACH Choice of key function. - NONE: key has no function - MASTER: key is used for mastering - TEACH: key is used for teaching A 3.3.13.2 KEYLOCK, Set Keylock KEYLOCK NONE|ACTIVE|AUTO <time>...
Page 107: A 3.4.4 Laserpow, Laser Power
Appendix| ASCII Communication with Sensor A 3.4.4 LASERPOW, Laser Power LASERPOW FULL|OFF - FULL: laser power is set to 100 % - OFF: laser is switched off 1) Available for the sensor models ILD1420-10/25/50. A 3.4.5 ROI, Video Signal, Masking the Region of Interest (ROI) ROI <Start>...
Page 108: A 3.4.6.2 Mastermv, Mastering / Zeroing
Appendix| ASCII Communication with Sensor A 3.4.6.2 MASTERMV, Mastering / Zeroing MASTERMV NONE|MASTER <MV> - NONE: completes mastering - MASTER: sets the current measurement value as a master value - MV: master value in millimeters; MV = (0 ... 2) * measuring range, i.e. master value must be within measuring range In case of master value is 0, the mastering has the same functionality as the zeroing.
Page 109: A 3.5.3 Outreducecount, Output Data Rate
Appendix| ASCII Communication with Sensor A 3.5.3 OUTREDUCECOUNT, Output Data Rate OUTREDUCECOUNT <n> Reduces measurement value output of the chosen interfaces. - 1: outputs each measurement value - 2 ... 3000000: output of each n-th measurement value A 3.5.4 OUTHOLD, Error Processing OUTHOLD NONE|INFINITE|<n>...
Page 110: A 3.5.5.3 Outvideo_Rs422, Adjust Video Output
Appendix| ASCII Communication with Sensor A 3.5.5.3 OUTVIDEO_RS422, Adjust Video Output OUTVIDEO_RS422 NONE|VIDEO_RAW Defines the data to be transmitted at a video image transmission via RS422. - NONE: no video images - VIDEO_RAW: output of uncorrected video signal (raw signal) A 3.6 Example Command Sequence During Selection of Measurement Value Command...
Page 111: A 3.7 Error Messages
Appendix| ASCII Communication with Sensor A 3.7 Error Messages If an error occurs with a command, the error message is listed. Error message Description E100 Internal error Internal error code E104 Timeout Timeout while mastering. E200 I/O operation failed Cannot write data to the output channel. E202 Access denied Access denied: Login as expert is necessary.
Page 112 Appendix| ASCII Communication with Sensor E332 Error during import Error during processing the import data E333 No overwrite during import allowed No overwrite of measurement and device settings allowed through import, set the checkbox. E350 The new passwords are not identical Password and verification password do not match.
Page 113: A 4 Control Menu
Appendix| Control Menu Control Menu A 4.1 Tab Home Measurement Presets Standard Suitable for materials made of ceramics, metal or filled plastics task Changing surface Suitable for e.g. PCB or hybrid materials Material with penetration Suitable for plastics (POM, Teflon), materials with strong pen- etration of the laser Setups Setup 1 ...
Page 114: Signal Processing
Appendix| Control Menu A 4.2.2 Signal Processing Measurement task Standard Suitable for materials made of ceramics, metal or filled plastics Multi-surface Suitable for e.g. Printed circuit boards (PCB) or hybrid materials Light penetration Suitable for plastics (POM, Teflon), materials with strong penetration of the laser Measuring rates 250 Hz / 500 Hz / 1 kHz /...
Page 115 Appendix| Control Menu Selection of peak First peak / Defines which signal is used close Sensor faraway Highest peak / for the evaluation in the line Last peak signal. Highest First peak: Nearest peak to peak First Last sensor. peak peak Highest peak: standard, peak with the highest intensity.
Page 116: Outputs
Appendix| Control Menu A 4.2.3 Outputs RS422 Baud rate 9.6 / 19.2 / 56.0 / 115.2 / 230.4 ... / 1000 kBps Transmission speed, binary data format Output data Distance / Exposure time / Intensity / Date to be transmitted are to be activated via the Sensor status / Measurement value counter / checkbox.
Page 117 Appendix| Control Menu Web interface LED Output RS422 Current output Parametrization Measurement chart Web inteface yellow • • Selected output RS422 green • • interface Analog • • • optoNCDT 1420 Page 117...
Page 118: A 4.2.4 System Settings
Appendix| Control Menu A 4.2.4 System Settings Unit on website mm / inch Unit in measurement value display Keylock Automati- Range 1 ... 60 [min] Value The keylock starts after expiry of the defined time. Click- ing the button Refresh extends the interval until keylock cally Refresh starts.
Page 119 Button starts change of access permission. Sets the user level the sensor starts with after re- User level reboot Professional / User boot. In this case MICRO-EPSILON recommends the selection user. Old password Value Case-sensitive rules are observed for all passwords.
Page 120 Appendix| Control Menu Measurement settings The settings for measuring rate, trigger, evaluation range, selection of peak, error handling, averaging, Zeroing/Mastering, reduction of data and setups are deleted. The 1st preset is loaded. Reset sensor Device settings The settings baud rate, language, unit, keylock and echo mode are deleted and the default parameters are loaded.
Page 122 MICRO-EPSILON MESSTECHNIK GmbH & Co. KG X9751351-B021088MSC Königbacher Str. 15 · 94496 Ortenburg / Germany MICRO-EPSILON MESSTECHNIK Tel. +49 (0) 8542 / 168-0 · Fax +49 (0) 8542 / 168-90 *X9751351-B02* info@micro-epsilon.de · www.micro-epsilon.com...

This manual is also suitable for:

Ild 1420-100 Ild 1420-50 Ild 1420-500 Ild 1420-25 Ild 1420-25 cl1 Ild 1420-10 cl1 ... Show all

MICRO-EPSILON ILD 1420-10 Instruction Manual

1 Safety

2 Laser Safety

3 Functional Principle, Technical Data

4 Delivery

5 Installation

6 Operation

7 Set Sensor Parameter

8 Digital Interfaces RS422

9 Cleaning

10 Software Support with Medaqlib

11 Liability for Material Defects

12 Decommissioning, Disposal

13 Service, Repair

Appendix

Quick Links

Need help?

Questions and answers

Related Manuals for MICRO-EPSILON ILD 1420-10

Summary of Contents for MICRO-EPSILON ILD 1420-10

This manual is also suitable for:

Table of Contents
