Freeloader Super Charger Pro SC9002 User Manual

Supercharger
The superfast way to
charge FreeLoader Pro

User Manual

Model - SC9002
B)
F) Electrical Characteristics
A)
Power: 1.8watt
Output current: 300mAh
Output voltage: 6v
Weight: 249gm (411gm when combined
with Freeloader Pro)
Dimensions: 251 x 256 x 6mm
Operating temperature range: –20 to +80
C)
Components Included:
D)
1 x Supercharger Pro Solar Cell
1 x Tough Case
Performance
The charger will fully charge a FreeLoader Pro in
as little as 3 hours* if the charger is facing the sun.
Longer charge-up times should be expected if
E)
G)
facing away from the sun or on a cloudy day.
* Average
A) Charging indicator (GREEN)
B) Power available indicator (RED)
C) Solar cell
D) Tough case
E) Adjustable Velcro strap
F) Fasteners
G) Freeloader Pro connection lead
1
o
C
NOTE – This product is designed for
use with Freeloader Pro ONLY. Use
with any other solar charger may
result in damage to the charger.
2
Operation Instructions:
1. To Fix Supercharger Pro onto bag
Supercharger Pro can be fixed with either with the
fasteners and/or the adjustable Velcro strap, whichever
offers the most secure fixing. Take care when opening
the teeth of the fasteners - always lift up the rear of the
fasteners first.
Lift to open
Open jaws of
fastener, position
around fastening
point, then close
fi rmly
Tip - Supercharger Pro will always perform at its best
if held on a tilted plain (45 degrees or vertical) if facing
the sun or on the horizontal plain if facing away from
the sun.
3
