Note: 1. PSAM card is not supported.
2. The device does not support the card hot plug, and you must
reset the card after plugging and unplugging it.

4.7 Installing the battery

➢
Please install the SIM card as instructed below
➢ Slide the battery cover switch to the unlock side (right side);
➢ Place thumbnail at the battery notch and lift the battery cover;
➢ Put the battery into the battery compartment at an appropriate
angle;
➢ Make sure the battery contacts are aligned with the battery
compartment and press the battery downward;
Figure 4-3 Remove the battery cover
10
：
