FujiFilm AUYA36LATU Service Manual

FujiFilm AUYA36LATU Service Manual

Split type air conditioner cassette type (50 hz)
Hide thumbs

Advertisement

Table of Contents

SPLIT TYPE
AIR CONDITIONER
CASSETTE TYPE (50 Hz)
Indoor unit
AUYA36LATU
AUYA45LATU
CONTENTS
. . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . . . . . . . . . . . . . 2
. . . . . . . . . . . . . . . . . . .5
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . 25
Outdoor unit
AOYA36LATL
AOYA45LATL
. . . . . 4
. . . . . .
6
. . . .10
13
. . . . . . . . . . . . . . 16
. . . . . . . . . . . . 21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUYA36LATU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FujiFilm AUYA36LATU

Summary of Contents for FujiFilm AUYA36LATU

  • Page 1: Table Of Contents

    SPLIT TYPE AIR CONDITIONER CASSETTE TYPE (50 Hz) Indoor unit Outdoor unit AUYA36LATU AOYA36LATL AUYA45LATU AOYA45LATL CONTENTS ....1 SPECIFICATIONS ..... . . 2 DIMENSIONS .

  • Page 2: Specifications

    SPECIFICATIONS ELECTRICAL DATA COMPRESSOR AND REFRIGERANT TYPE Cooling & Heating Hermetic type, Inverter, TYPE 4 poles, 3 phase, AUYA36LATU AUYA45LATU INDOOR UNIT DC motor, Twin Rotary OUTDOOR UNIT AOYA36LATL AOYA45LATL DISCRIMINATION DA420A3F-21ZA 10.0 kW 12.5 kW COOLING CAPACITY WEIGHT (with oil) 23.7 kg...

  • Page 3: Dimensions

    DIMENSIONS INDOOR UNIT (Unit : mm) Side view Bottom view Panel Bottom view Top view Selection of setting Side view (Standard setting) Side view (Slender setting) 2007.02.27...
  • Page 4 OUTDOOR UNIT (Unit : mm) Air Flow 2007.01.23...

  • Page 5: Refrigerant System Diagram

    REFRIGERANT SYSTEM DIAGRAM OUTDOOR UNIT INDOOR UNIT Pressure Refrigerant Pipe Check Valve Strainer 15.88mm (5/8") High Pressure Charging Switch Valve 4-way Condenser Evaporator Valve Accumulator Compressor Refrigerant Pipe Strainer Strainer 9.52mm (3/8") Expansion Valve Charging Valve Refrigerant direction : Cool : Heat 2007.04.02...

  • Page 6: Circuit Diagram

    OUTDOOR UNIT CIRCUIT DIAGRAM THERMISTOR THERMISTOR ( OUTDOOR TEMP. ) ( PIPE TEMP. ) BLACK BLUE THERMISTOR THERMISTOR BROWN BROWN ( COMPRESSOR TEMP. ) ( DISCHARGE TEMP. ) INDOOR UNIT THERMISTOR THERMISTOR BLACK BLACK ( PIPE MID. TEMP. ) ( HEAT SINK TEMP. ) 1 2 1 2 GRAY THERMISTOR...

  • Page 7: Indoor Pcb Circuit Diagram

    INDOOR PCB CIRCUIT DIAGRAM CONTROL UNIT ROOM TEMP. THERMISTOR AUYA36LATU : EZ-0061KHSE CN8-1 BLACK B02B-XASK-1-A CN8-2 BLACK AUYA45LATU : EZ-0061HHSE WHITE CN2-1 CN7-1 CN2-2 CN7-2 B02B-XAYK-1-A CN2-3 B5P-SHF-1AA YELLOW CN2-4 PIPE TEMP. THERMISTOR ( M I D ) WHITE CN2-5...
  • Page 8 INDOOR UNIT CONTROLLER PCB ASSEMBLY ( MAIN PCB ) AUYA36LATU : K06AK-060BHSE-C1 AUYA45LATU : K06AK-060AHSE-C1 R1 - R3 1SS355 10K <1/10W> x 3 THERMISTOR ( ROOM TEMP. ) I C8 13.5V FLOAT SWITCH B02B-XASK-1-A NJM7812 R4 - R6 1.0K 1.0K <1/10W> x 3 <1/10W>...
  • Page 9 INDOOR UNIT POWER SUPPLY PCB ASSEMBLY K06AL-0604HSE-P0 R103 340V 13.5V D108 D2FL20U <RS-2W> T101 C108 ZFT22B03 4700P <ECQM> R111 I C26-14 C113 R104 1000/ 330K <1/10W> D102 NORMAL COIL <2W> 1SR139-600 C114 F101 CN108 C109 0.01 3.15A - 250V B2P3-VH-B 220P/ <KH>...
  • Page 10 INDOOR UNIT INDICATOR PCB ASSEMBLY K04GN-0402HSE-D0 R201 330 <1/4W> D205 EBR3864X <RED> R202 330 <1/4W> D206 EMPG3863X <GREEN> TO CONTROLLER PCB ASSEMBLY R203 ( OPERATE ) BROWN 330 <1/4W> D207 EMAA3863X <ORANGE> ( TIMER ) ( LOUVER ) ORANGE ( LOUVER ) YELLOW ( 5V ) WHITE...

  • Page 11: Outdoor Pcb Circuit Diagram

    OUTDOOR PCB CIRCUIT DIAGRAM INVERTER ASSEMBLY AOYA36LATL : EZ-00603HUE CHOKE COIL AOYA45LATL : EZ-00604HUE L=0.3MH EMI FILTER 1 F201 TFC-25-15-12A UL1015 TLC 25A - 250V, B AWG12 ( 250V 25A ) WHITE UL1015 UL1015 POWER SOURCE UL1015 UL1015 AWG14 AWG14 EMI FILTER 2 EMI FILTER 3 AWG12...
  • Page 12 OUTDOOR UNIT CONTROLLER PCB ASSEMBLY ( MAIN PCB ) AOYA36LATL : K06DZ-0601HUE-C1 AOYA45LATL : K06DZ-0600HUE-C1 MAIN CURRENT ORANGE YELLOW R201 C116 220K R370, R371, R374 <2W> <HCP> R375, R376, R379 ORANGE 0.018 <2W> x 6 195K <RN-1/2W> x 6 C115 BLACK 660/450WV x 3 BLUE...
  • Page 13 OUTDOOR UNIT POWER SUPPLY PCB ASSEMBLY K04BA-0401HUE-P0 TM100 N200500K1D7C RCH3818-022PF07 RCH3818-022PF07 TM101 BLACK VA101 C104 BLACK 470V 0.033 C107 C111 C101 <TNR> <YE> POWER SOURCE C105 VA102 <LE> <LE> <LE> 230V 470V 0.033 50Hz <TNR> <YE> TM102 WHITE C106 WHITE SA100 <LE>...

  • Page 14: Error Contents

    ERROR CONTENTS INDOOR UNIT TROUBLESHOOTING Troubleshooting with the indoor display Troubleshooting at the display is possible either on the wired or wireless remote control. FILTER lamp (Orange) TIMER lamp (Green) OPERATION lamp (Red) The OPERATION, TIMER and FILTER lamp operate as follows table ac- cording to the error contents.
  • Page 15 ERROR CONTENTS REMOTE CONTROL UNIT OUTDOOR UNIT LEDS Troubleshooting at the remote control LCD Make a TEST RUN in accordance with the installation instruction sheet for the indoor unit. This is possible only on the wired remote control. If an error occurs, the following display will be shown. When a malfunction occurs in the outdoor unit, ("EE"...
  • Page 16 SPECIAL INSTALLATION SETTING PUMP DOWN (Refrigerant collecting operation) Perform the following procedures to collect the refrigerant when moving the indoor unit or outdoor unit 1. When the product is stopped: PUMP DOWN SW (SW2) Press the PUMP DOWN switch on the outdoor unit. (The LED on the outdoor unit circuit board starts flashing.) (1 sec.

  • Page 17: Parts (Indoor Unit)

    PARTS INDOOR UNIT Intake grille sub assy Ref. Description Parts number Decoration Plate 9378017016 Intake Grille Sub Assy 9362818131 Intake Grille 9362767019 Filter 9362766005 Grille Reinforcement-T (A) 9362738002 Grille Reinforcement-T (B) 9362739009 Grille Reinforcement-T (C) 9362740005 Grille Reinforcement-T (D) 9362741002 Grille Reinforcement-T (E) 9362742009 Insulation (Grille)-A...
  • Page 18 INDOOR UNIT Panel base Ref. Description Part number Panel Frame Holder 9362758017 Panel Base 9362759014 Joint A 9362773003 Joint Shaft 9362771009 Louver Supporter 9362770019 Joint Gear 9362772006 Rubber Support Holder 9362799003 Step Motor 9900362027 Motor Gear 9362764001 Motor Holder 9362765008 Panel Frame Holder 9362761017 Panel Base Holder...
  • Page 19 INDOOR UNIT Evaporator Drain pan Ref. Description Parts number Evaporator A Assy 9373799047 Evaporator B Assy 9373800040 Distributor Assy 9371325101 Coupling Pipe Assy 9373038290 Separate Wall 9362737005 Clamp No.1219 313361271706 Pipe Thermistor 9703297021 Thermistor Spring-A 313728262708 Evaporator Holder Assy 9362802017 Wind Guide Board 9373444015 Reinforcement (Eva.
  • Page 20 INDOOR UNIT Fan motor Ref. Description Parts number Panel Top 9362732048 Cabinet A 9362800013 Cabinet B 9362801010 Cabinet C 9362733007 Cabinet D 9362734004 Inner Box 9362768009 Fan Motor Assy 9602486014 Fan Motor Holder 9378019010 Motor Rubber 9378020016 Turbo Fan Assy 9362803014 Washer (Turbo Fan) 9362756006 Cabinet-E...
  • Page 21 INDOOR UNIT Control unit Ref. Description Parts number Control Box 9368523015 Bellmouth B 9362774000 Control Box Assy 9368533007 Controller PCB Assy (36) 9707393101 Controller PCB Assy (45) 9707393095 Power Supply PCB Assy 9707398052 Spacer 0600118075 Reactor Assy 9707457018 Clamp NK-4N 313714328805 Terminal-3P 9703345012...

  • Page 22: Parts (Outdoor Unit)

    PARTS OUTDOOR UNIT Ref. Description Parts number Top Panel Sub Assy 9374417025 Front Panel 9374094028 Fan Guard 9374330010 Grip Side 9374173013 Service Panel Sub Assy 9374415069 Right Panel Sub Assy 9374416141 Valve Cover 9374174010 Emblem Rear 9351355005 2007.02.02...
  • Page 23 OUTDOOR UNIT Ref. Description Parts number Propeller Fan Assy 9366378020 Motor DC Brushless 9601882015 Condenser A Assy 9374433018 Condenser B Assy 9374434015 Sepa Wall 9374629015 Cap Foot 9374345014 Base Assy 9374166046 Coil Choke 9703458019 2007.10.25...
  • Page 24 OUTDOOR UNIT Ref. Description Parts number 3-Way Valve Assy 9377958013 3-Way Valve Assy 9377959010 Compressor Assy 9378035010 Accumulator Assy 9375250034 Solenoid 9900165055 Pressure Switch 9900186012 4-Way Valve 9970035029 Check Valve Assy 9374274017 Coil (Expansion Valve) 9900197025 Strainer Assy 9372524039 Expansion Valve Assy 9370947175 Compressor Cover A 9374430109...
  • Page 25 Ref. Description Parts number Inverter Box A 9374603015 OUTDOOR UNIT Inverter Box B 9374625017 Inverter Box C 9374605026 Inverter Box Duct 9374609017 Inverter Box Cover 9374608010 Heat Sink B 9374607020 ACTPM 9707592016 Posistor 9704265012 Inverter PCB Assy (36) 9707537024 Inverter PCB Assy (45) 9707537017 Power PCB Assy 9705647022...

  • Page 26: Accessories

    ACCESSORIES INDOOR UNIT Name and Shape Q’ty Application Coupler heat For indoor side pipe joint insulation Tapping Screw For installing the remote (flush heads) controller (option) Special nut A For installing indoor unit (large flange) Special nut B For installing indoor unit (small flange) Template For ceiling hole cutting...
  • Page 27 0708G3258...
