* Synchronizing Multiple Cameras
Multiple OptiTrack cameras may be synchronized for greater precision, via RCA Wired Sync.
* When using V120:SLIM cameras, all cameras in the sync chain must be of the same type.
Mixed sync environments are not supported.
* Plug in Sync Break-Out Cable for each camera.
* Connect master device's "out" connector to slave camera's "in" connector using Sync Cable
(sold separately).
Sync Out
Note: Break-Out Cable connectors required for camera-to-camera sync.
Friendly Customer Service
If you have any difficulties after reviewing the
documentation, visit our website or call
1.541.753.6645 between 9AM-5PM PT.
Visit www.OptiTrack.com for the latest software
support, sample code and product news.
P-OT-105.1002
(Master)
Sync In
V120 Sync Break-Out Cable
© 2010 NaturalPoint, Inc. All rights reserved.
All other company and or product names are the trademarks of their respective owners.
(Slave)
V120: S L IM
quick start guide
Advertisement
Summary of Contents for optitrack V120:SLIM
-
Page 1: Quick Start Guide
* Synchronizing Multiple Cameras Multiple OptiTrack cameras may be synchronized for greater precision, via RCA Wired Sync. * When using V120:SLIM cameras, all cameras in the sync chain must be of the same type. Mixed sync environments are not supported. -
Page 2: Install Software
* PCB-only V120:SLIM cameras (no case) only support M12 lenses. * Mounting an M12 lens on a V120:SLIM camera with the case requires a CS to M12 adapter. * OptiTrack M12 lenses should be installed with the included Wave Spring for secure focusing.
