Summary of Contents for TizzBird Stick N1
- Page 1 TIZZBIRD™ N1 Quick Installation Guide Smart TV Stick...
-
Page 2: Safety Notice
Do not try to disassemble the unit. It may cause malfunction or fire. Magnets Keep away the unit from magnetized devices. It may erase the data stored in Tizzbird Stick N1. Humidity Do not place the unit in places that are exposed to oil, water, dust, humidity, rain or wind. - Page 3 Quick Installation Guide 2.Features Tizzbird N1 is so small that let you install it directly to HDMI port of any TV. The power will be supplied by USB port of TV, so no need to install another power adapter. Tizzbird playbacks various full HD movie contents including DVD backup formats as well as AVI, MKV, XVID and TS formats on TV.
-
Page 4: Specifications
Quick Installation Guide 3.Specifications Model TizzBird Stick N1 System TCC8925 Cortex-A5 800Mhz CPU/ 256KB L2 Cache, 512M RAM (N1M Model), 1GB RAM (N1G Model) / 4GB T-flash Android Rev 4.0 Ice cream Sandwich Video Format: AVI/ MKV/ MPG/ WMV/ VOB/ TP/ TRP/ M2TS/ MOV/ FLV/ IFO/ ISO Codec: MPEG 1/2/4, H264, XVID, WMV9(MP@HL4.1) VC-1(AP@L3) -
Page 5: Description Of Each Part
Please connect MOUSE or KEYBOARD on the USB OTG port. * USB host DOES NOT PROVIDE enough POWER to drive 2.5” HDD. Please use HDD drive with external power supply. * USB OTG port only allows connection of MOUSE or KEYBOARD. TizzBird N1... -
Page 6: Package Contents
Quick Installation Guide 5.Package Contents The TizzBird package contains the following items. The shape of items described below may slightly different from the actual contents. Components Main Unit Remote Controller Y Cable Quick Guide Power Adapter TizzBird N1... -
Page 7: Installation And Connection
Quick Installation Guide 6.Installation and Connection Connecting to TV The TizzBird supports HDMI audio and video output for connection to a TV. Connection to HDMI Out Power Cable Connection Connect the TizzBird N1 HDMI to your TV. HDMI Connect the power cable of TizzBird N1 to the can also transfer the audio signal and no need to TV USB port like below. - Page 8 Quick Installation Guide Connecting to AV Receiver Tizzbird N1 can be connected to HDMI input AV receiver. Please select the appropriate input at the audio receiver using remote controller after connection. Connect the Tizzbird N1 HDMI to your AV receivers’ HDMI input. Then connect the AV receivers’ HDMI output to the TV input.
-
Page 9: Connecting Usb Device
Quick Installation Guide Connecting USB Device TizzBird provides two USB 2.0 host ports to connect various external devices, such as FLASH MEMORY drive, external USB HDD enclosure, digital camera/camcorder, keyboard & mouse, or USB video-cam & microphone. Caution!! To connect any external 2.5” HDD drive, please DO USE EXTERNAL POWER SUPPLY of HDD or Y-CABLE for that. -
Page 10: Initial Setup Wizard
PREV/ NEXT step. 1) Language Setup The first step is setup the menu language. The setup wizard will enumerate all the languages available at this moment. Please select one of the menu languages for your use. TizzBird N1... -
Page 11: Video Output Setup
The video resolution selection screen will appear as above. Please select the appropriate video output for the display. If you select, the pop-up will ask you keep resolution change or not. If the pop-up screen will appear, please select “Keep It”. TizzBird N1... -
Page 12: Screen Fitting Setup
Press OK when done. 4) Network Setup The 4th step is setting up network. Wi-Fi can be configured here. If Wi-Fi button were pressed, the following screen will enumerate all available Wi-Fi AP. Select one of them and click it. TizzBird N1... - Page 13 Quick Installation Guide The next page screen will pop up to configure the Wi-Fi. Typing the password will finalize the Wi-Fi setup and Internet connection will be made. TizzBird N1...
- Page 14 5) Time Zone & Weather Location Setup The next step is setting up time zone and weather location. Tizzbird provides automatic setup for those as long as network is connected. To setup the time-zone, select the Time-Zone button as above screen. Then select “AUTO”...
-
Page 15: Theme Setup
6) Theme Setup The final step is setting up theme. Tizzbird N1 provides two type of theme, one is the Android theme, the other is Tizzbird classic theme. If you are familiar with smart phone user interface, please choose “Android”. -
Page 16: Using Remote Controller
Quick Installation Guide 7.Using Remote Controller The TizzBird package contains the following items. The shape of items described below may slightly different from the actual contents. Turn power ON/OFF Go to HOME screen Mouse ON/OFF Search Delete Bookmark the current scene...
