Vivid™ Intraoral Video Camera
Installation and User Guide
Progeny Dental
675 Heathrow Drive
Lincolnshire, Illinois 60069 U.S.A.
Phone: (888) 924-3800, (847) 415-9800, Fax: (847) 415-9801
www.progenydental.com
techsupport@progeny-inc.com
PN 00-02-1591
ECN: P1630
REV. B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vivid and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Progeny Vivid

Summary of Contents for Progeny Vivid

  • Page 1 Vivid™ Intraoral Video Camera Installation and User Guide Progeny Dental 675 Heathrow Drive Lincolnshire, Illinois 60069 U.S.A. Phone: (888) 924-3800, (847) 415-9800, Fax: (847) 415-9801 www.progenydental.com techsupport@progeny-inc.com PN 00-02-1591 ECN: P1630 REV. B...
  • Page 2 Vivid™ Intraoral Video Camera The entire contents of this guide are Copyright © 2008 Progeny Dental. The Progeny name, logo, and Vivid names and logos are registered trademarks or trademarks pending. Other trademarks are the property of their respective owners. No part of this guide may be reproduced by any method without the express written permission of Progeny...

  • Page 3: Table Of Contents

    Testing Vivid Camera Video and Image Capture..............24 Installing the Vivid Camera with Progeny Imaging..............28 Installing the Vivid Camera with Patterson Eagle Soft Imaging ..........30 Installing the Vivid Camera with the DENTRIX Clarity Imaging Module .........33 Adjusting Color........................36 Color Calibration with a Blue-only Switch ................40 Infection Control..........................44...

  • Page 4: Regulatory Information

    Regulatory and Safety Vivid™ Intraoral Video Camera Regulatory Information Indications for Use The Vivid Intraoral Video Camera is intended to provide a dentist with the ability to view the oral cavity prior to and subsequent to dental procedures. ContraIndications: None Warnings &...
  • Page 5 For complete information, refer to Infection Control on page 44. Do not heat sterilize or autoclave any part of the VIVID camera as such cycles will damage the optics and void the warranty. If any of the following conditions occur, disconnect the system and refer servicing...

  • Page 6: Product Description

    The Vivid Intraoral Video Camera is a state-of-the-art dental video camera. When used with a compatible software application, the operator will be able to capture and store video images into a patient’s file. The Vivid camera consists of the components shown on the following pages.
  • Page 7 Regulatory and Safety Vivid™ Intraoral Video Camera Figure 2 USB Video Converter Figure 3 USB Cables...
  • Page 8 2 years. Please refer to your warranty card for complete details. The Vivid Intraoral Video Camera should only be installed and serviced by Installation and approved Progeny dealer personnel. For assistance, contact Progeny:...

  • Page 9: Installation Procedures

    PC requirements have been met. System Requirements The Vivid Intraoral Video Camera is intended to be connected to a desktop or laptop computer system via USB. Successful computer integration can only be accomplished by ensuring that the system meets the following requirements.

  • Page 10: System Configurations

    Vivid™ Intraoral Video Camera System Configurations The Vivid Intraoral Video Camera is intended to be connected to a USB hub that is connected to a computer’s USB port (Figure 6) or to be directly connected to a computer’s USB ports (Figure 7).

  • Page 11: Installing The Vivid Camera With A Usb Hub

    2. Connect the hub power supply to the hub. USB Hub 3. Plug the power supply into a wall outlet. Note: Do not connect the Vivid camera or cables to the hub until told to do so by Insert the the installation program.
  • Page 12 • Install Progeny Vivid Camera Hardware—This option installs the Vivid camera hardware on the computer • Testing Video and Capture Button—This option permits verification of the Vivid camera basic function prior to integration with a dental office application...
  • Page 13 Installation Procedures Vivid™ Intraoral Video Camera 1. Click Install Progeny Vivid Camera Driver. The Vivid Camera Driver Installing the installation screen will appear. Vivid Camera Driver to the Computer 2. Click Install Drivers. The EULA (End User License Agreement) will appear.
  • Page 14 Installation Procedures Vivid™ Intraoral Video Camera 4. Click Next. A software installation warning will appear. 5. Click Continue Anyway. The InstallShield Wizard will complete. 6. Click Finish. An option to restart Windows will appear. 7. Select Yes and click OK. The computer will shutdown and restart.
  • Page 15 Hardware 2. Click Next. The list of installation options will appear. 3. Click Install Progeny Vivid Camera Hardware. The Install Progeny Vivid Camera Hardware screen will appear. 4. Connect the two USB cables to the USB ports on the USB hub and to the USB ports on the USB video converter.
  • Page 16 Installation Procedures Vivid™ Intraoral Video Camera 5. Select No, not this time and click Next. 6. Select Install the software automatically and click Next. A hardware installation warning will appear.
  • Page 17 7. Click Continue Anyway. It may take several minutes for the system to install the driver files. Note: The screen above may vary depending on your system. 8. Click Finish. 9. In the Progeny Vivid Camera Setup screen, click Next.
  • Page 18 1. Connect the Vivid camera cable to the Vivid camera handpiece. Connect the 2. Connect the other end of Vivid camera cable to the USB video converter. The Vivid Camera light head on the Vivid camera handpiece should light up at this time.

  • Page 19: Installing The Vivid Camera Directly To The Computer

    If the computer’s USB ports are needed for other devices, install the Vivid camera using a USB hub as described on page 8. Note: Do not connect the Vivid camera or cables to the computer until told to do Insert the so by the installation program.
  • Page 20 • Install Progeny Vivid Camera Hardware—This option installs the Vivid camera hardware on the computer • Testing Video and Capture Button—This option permits verification of the Vivid camera basic function prior to integration with a dental office application...
  • Page 21 Installation Procedures Vivid™ Intraoral Video Camera 1. Click Install Progeny Vivid Camera Driver. The Vivid camera Driver Installing the installation screen will appear. Vivid Camera Driver to the Computer 2. Click Install Drivers. The EULA (End User License Agreement) will appear.
  • Page 22 Installation Procedures Vivid™ Intraoral Video Camera 4. Click Next. A software installation warning will appear. 5. Click Continue Anyway. The InstallShield Wizard will complete. 6. Click Finish. An option to restart Windows will appear. 7. Select Yes and click OK. The computer will shutdown and restart.
  • Page 23 Hardware 2. Click Next. The list of installation options will appear. 3. Click Install Progeny Vivid Camera Hardware. The Install Progeny Vivid Camera Hardware screen will appear. 4. Following the instructions on the screen, connect the two USB cables to the USB ports on the computer and to the USB ports on the USB video converter.
  • Page 24 Installation Procedures Vivid™ Intraoral Video Camera 5. Select No, not this time and click Next. 6. Select Install the software automatically and click Next. A hardware installation warning will appear.
  • Page 25 Vivid™ Intraoral Video Camera 7. Click Continue Anyway. It may take several minutes for the system to install the hardware. Note: The screen above may vary depending on your system. 8. Click Finish. 9. In the Progeny Vivid Camera Setup screen, click Next.
  • Page 26 1. Connect the Vivid camera cable to the Vivid camera handpiece. Connect the 2. Connect the other end of Vivid camera cable to the USB video converter. Vivid Camera The light head on the Vivid camera handpiece should light up at this time.

  • Page 27: Testing Vivid Camera Video And Image Capture

    Verify Video The Vivid camera consists of a DirectShow compatible USB video device. To verify that the video is working correctly, the Vivid camera uses the AMCap application, a small video capture and preview application compatible with Microsoft DirectShow. 1. Click Video in the Progeny Vivid Camera Driver Installation screen, or from the Start menu, select Progeny Vivid >...
  • Page 28 Installation Procedures Vivid™ Intraoral Video Camera 2. From the Devices menu, select Progeny Vivid USB Camera. 3. From the Options menu, select Preview. The image from the camera will appear in a window like the one above. 4. After verifying that an image appears, close the AMCap window by clicking the...
  • Page 29 Verify the game pad interface. Use the Progeny Vivid Camera Testing screen or, from the Capture Start menu, select Progeny Vivid > Test Capture Button to verify that the image Button capture button is working. 1. On the Progeny Vivid Camera Testing screen, click Game Port, or from the Start menu, select Progeny Vivid >...
  • Page 30 Installation Procedures Vivid™ Intraoral Video Camera 3. While this window is in the foreground, press and release the capture button on the Vivid Camera Handpiece. The "1" button should flash 4. When you are finished, click OK.

  • Page 31: Installing The Vivid Camera With Progeny Imaging

    2. In the Progeny Imaging Device menu, select Progeny Vivid USB Camera. with Progeny Imaging Device Video Menu Button 3. Click the Video button. The Video window will appear. 4. Position the Vivid camera so that the region to image appears in the Video window.
  • Page 32 Installation Procedures Vivid™ Intraoral Video Camera 5. To capture the image, press then release the button on the Vivid camera, or click the Capture button in the Video window. The image will appear in the image area of the patient folder.

  • Page 33: Installing The Vivid Camera With Patterson Eagle Soft Imaging

    Installation Procedures Vivid™ Intraoral Video Camera Installing the Vivid Camera with Patterson Eagle Soft Imaging In order to use the Vivid camera with Patterson Imaging, the Vivid camera must be integrated with Patterson’s video capture functionality. 1. Log into Patterson Imaging.
  • Page 34 Installation Procedures Vivid™ Intraoral Video Camera 3. Click the X-ray tab.
  • Page 35 Patterson Imaging 2. Select a patient. 3. Position the Vivid camera so that the region to image appears in the image viewer. 4. Press then release the button on the Vivid camera. The image will freeze in the image viewer.

  • Page 36: Installing The Vivid Camera With The Dentrix Clarity Imaging Module

    Installation Procedures Vivid™ Intraoral Video Camera Installing the Vivid Camera with the DENTRIX Clarity Imaging Module In order to use the Vivid camera with the DENTRIX Clarity Imaging Module, the Vivid camera must be integrated with DENTRIX Clarity’s video capture functionality.
  • Page 37 Vivid™ Intraoral Video Camera 4. In the drop-down menu, select Progeny Vivid USB Camera. 5. Select the Camera tab. Live video from the Vivid camera will appear in the Preferences screen. 6. Select the Footswitch tab. The Preferences screen will display options for...
  • Page 38 Installation Procedures Vivid™ Intraoral Video Camera 7. Set the following Footswitch options. Option Setting Footswitch Dentrix Joystick 1 Delay Times Custom 240 ms Function Capture Only...

  • Page 39: Adjusting Color

    Computer monitors vary widely in their colors settings, so you must adjust the color settings on your computer, in order to obtain the most realistic patient images. The Vivid camera comes with a Color Test Chart for use in this procedure. With the Vivid camera connected and operating, you will use the AMCap software and the Color Test Chart to adjust the computer’s color...
  • Page 40 Installation Procedures Vivid™ Intraoral Video Camera 1. From the Options menu, select Video Capture Filter…. Adjust Color Settings 2. Click on the Video Proc Amp tab.
  • Page 41 Installation Procedures Vivid™ Intraoral Video Camera 3. Click, hold, and drag each slider to the left or right while looking at the Color Test Chart. Since some settings depend on others, settings should be adjusted in the following order, repeating the steps below as necessary. At any time click Default to return to the original settings.
  • Page 42 Installation Procedures Vivid™ Intraoral Video Camera...

  • Page 43: Color Calibration With A Blue-Only Switch

    For precise color calibration of the Vivid camera, use a VGA Blue-only switch (technician supplied). The Vivid camera comes with a Color Test Chart for use in this procedure. With the Vivid camera connected and operating, you will use the AMCap software and the Color Test Chart to adjust the computer’s color...
  • Page 44 Installation Procedures Vivid™ Intraoral Video Camera 1. From the Options menu, select Video Capture Filter…. Calibrate Color Settings 2. Click on the Video Proc Amp tab.
  • Page 45 Installation Procedures Vivid™ Intraoral Video Camera 3. Click, hold, and drag the Brightness and Contrast sliders to the left or right while looking at the Color Test Chart. Since some settings depend on others, settings should be adjusted in the following order, repeating the steps below as necessary.
  • Page 46 Installation Procedures Vivid™ Intraoral Video Camera 4. Place the Blue-only Switch in the ON position. The entire computer monitor display will appear in shades of blue. 5. Click, hold, and drag the Hue and Saturation sliders to the left or right while looking at the Color Test Chart.

  • Page 47: Infection Control

    Infection Control Vivid™ Intraoral Video Camera Infection Control...

  • Page 48: Cleaning And Disinfecting

    2. Remove and dispose of the sheath. Consider the sheath to be contaminated with bio-burden. Dispose of the sheath in accordance with state and local laws. 3. Disconnect the Vivid camera from its cable or cable from the Interface Module. 4. Consider the camera to be contaminated with bio-burden. Wipe the handpiece and cable with a gauze sponge moistened with sterile water to remove gross bio-burden.
  • Page 49 Infection Control Vivid™ Intraoral Video Camera Sanitary sheaths are essential to prevent infection. Follow the procedure below Use Sanitary to use sanitary sheaths. Sheaths 1. Insert handpiece between the second and third layers with the light source and lens facing towards the white paper backing.

  • Page 50: Specifications

    Specifications Vivid™ Intraoral Video Camera Specifications Vivid Intraoral USB Camera Power Input 5 Volts supplied by USB port 50-60 Hz PAL or NTSC format Light Source 8 high intensity, color balanced LEDs Light Intensity 1120-1400 mCD Glass Optics Focus Type...

  • Page 51: Warranty And Service

    Extended Warranty Options are available. For more details, contact Progeny or Extended your dealer. Warranty Save all original boxes and packing materials. In the event that you must return Returning the Vivid camera for service, always ship the system in the original boxes to Equipment for prevent damage. Service...

  • Page 52: Regulatory Compliance

    Note: Only peripherals complying with EN 550022 Class A limits may be attached to this intraoral video unit. Operation with non-compliant peripherals or peripherals not recommended by Progeny is likely to result in interference to radio or TV reception. Changes or modifications to this equipment not expressly approved by Progeny or parties authorized by Progeny could void the user’s authority to operate the equipment.
