U M F SC10E4I
SER ANUAL OR
1. LED for P.O.E. and system status. When the P.O.E. power connected, the green LED will be
light on.. (SC10E4I-P and SC10E4I-IP)
2. LED for PWR1 and system status. When the PWR1 links, the green LED will be light on.
3. LED for PWR2 and system status. When the PWR2 links, the green LED will be light on.
4. LED for fault indicator. When fault occurred, this red LED will be light on.
5. LED for Serial ports status. When data transmitted, the green LED will be light on. When
data received, the red LED will be light on.
6. LED of 10Base-T connection on Ethernet port.
7. LED of 100Base-TX connection on Ethernet port.
8. 10/100Base-T(X) Ethernet port. (P.O.E. PD port, SC10E4I-P and SC10E4I-IP)
9. 10/100Base-T(X) Ethernet port.
10. RS-422/485 serial port with 2KV isolation. Mode configured by Serial Management Tool.
11. RS-232/422/485 serial port. Mode configured by Serial Management Tool.
1.1 Front Panel LEDs
The following table describes the labels that stick on the SC10E4I.
LED Color
P.O.E. Green/Red
PWR1 Green/Red
Green/Red
PWR2
Fault Red
Green
S1 ~ S4
Red
Green/Amber
ETH1
Green/Amber
ETH2
Connecting. Converting. Leading!
Status Description
Power supplied over Ethernet
On
cable.
Indicates an IP conflict,
Red blinking DHCP or BOOTP server did
not respond properly
On DC power 1 activated.
Indicates an IP conflict,
Red blinking DHCP or BOOTP server did
not respond properly
On DC power 2 activated.
Indicates an IP conflict,
Red blinking DHCP or BOOTP server did
not respond properly
On Fault event occurred.
Blinking Serial port is transmitting data
Blinking Serial port is receiving data
Green On/Blinking 100Mbps LNK/ACT
Amber On/Blinking 10Mbps LNK/ACT
Green On/Blinking 100Mbps LNK/ACT
Amber On/Blinking 10Mbps LNK/ACT
or
or
or
